Every year, The NEWS introduces the latest heating equipment that is available for the upcoming winter season. The intent is to help contractors prepare for this busy period by doing the research that will help them to distinguish between brands.
Like last year, this year’s Heating Showcase is split into two parts — residential and commercial. The residential/light commercial information is published in this issue, and the commercial products will be featured in the Oct. 1 issue. Included in the coverage is feature-specific information about each individual product that was submitted by the manufacturers.
The showcase features the product grid, starting on page 8, which includes technical facts, such as unit tonnage, refrigerant type, efficiency rating, and cooling capacity. The accompanying photo feature provides more in-depth information on the features of each individual unit and also includes technical support information from the manufacturer. The manufacturers provided all of the data included in both the product grid and the photo feature. Therefore, any questions should be directed to them via the contact information provided.
![Back button.](/ext/resources/Generic_Images/responsive-images/back-button-white.png)
![4SHP15LE heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Airese-4SHP15LE-heat-pump-ACHR-News.jpg)
Serviceability features: Precision Service™ technology provides thoughtful design and precise part location of each component, allowing technicians to work more efficiently and effectively on every job. Features like simplified fan removal, threaded pressure switches, fewer screws per panel, and corner-post-mounted access panels allow technicians to finish jobs quicker.
Noise-reduction features: Quiet Shift™ technology allows heat pumps to enter defrost mode without excessive noise. Grommet-mounted compressor, heavy-duty sound blanket, and discharge muffler for quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: AirEase’s proprietary heat transfer system, MHT™ technology, uses proven enhanced tube-and-fin design to maximize heat transfer and efficiency. Full metal louvered panel coil guard protection is easily removed for cleaning. Controls located in corner for easy installation. Defrost control features built-in diagnostics for ease of service.
Warranty information: Ten-year limited warranty on compressor, 10-year limited warranty on all parts, extended warranty available. Warranty provides for a total of 10 years of limited warranty coverage (standard five-year limited parts warranty plus an additional five-year limited extended parts warranty). Must be registered online within 60 days of installation.
Special installation requirements: Filter drier shipped loose for installation flexibility. High-pressure switch. Low-pressure switch for loss of charge system protection. Reliable, solid state, time-initiated, temperature terminated defrost system. Accessories include low ambient control kit, thermostatic expansion valve (TXV) kit, crankcase heater, hard start kit, and fossil fuel kit.
Contact: Allied Air Enterprises, 803-738-4138; www.airease.com.
eProduct 160
![ACVC96 gas furnace with ComfortBridge - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Amana-ACVC96-ACHR-News.jpg)
Serviceability features: Integrated communicating ComfortBridge technology, with commissioning and diagnostics via onboard Bluetooth with CoolCloud phone/tablet app. Self-diagnostic control board with constant memory fault code history output to a triple seven-segment display. Designed for multiposition installation. Certified for direct vent (two-pipe) or non-direct vent (one-pipe). Convenient left or right connection for gas/electrical service. Airtight solid bottom or side return with easy-cut tabs for effortless removal in bottom air-inlet applications. Heavy-duty stainless steel tubular heat exchanger adds durability.
Noise-reduction features: The furnace strives to operate on low capacity as often and as long as possible, providing quiet, highly efficient performance. Efficient, quiet, variable-speed airflow system gently ramps up or down according to heating or cooling demand. Multiple continuous fan speed options offer quiet air circulation. A quiet, two-speed induced draft blower and two-stage gas valve provide quiet, economical heating. Fully insulated heat exchanger and blower section helps reduce noise.
IAQ equipment supported: Compatible with Clean Comfort Indoor Air Essentials and a range of other IAQ products. Color-coded, low-voltage terminals provide provisions for electronic air cleaner. Auto-Comfort and enhanced dehumidification modes are available.
Thermostat compatibility: Compatible with any single-stage thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: ComfortBridge off-the-wall communicating technology constantly monitors performance for customized, high-efficiency heating. Integrated inside the system’s indoor unit (not the thermostat), ComfortBridge gathers data to make automatic adjustments, consuming the minimum energy required to create consistent indoor comfort. This frees contractors to use any single-stage thermostat without sacrificing the system’s communicating benefits. It uses Bluetooth technology to commission, configure, and diagnose equipment; it is managed via onboard LED screen or a smartphone, using Cool Cloud HVAC app (Android/Apple).
Warranty information: Lifetime unit replacement limited warranty, plus 10-year parts limited warranty when online registration is completed within 60 days of registration. Complete warranty details available from local dealer or at www.amana-hac.com. Online registration is not required in California or Quebec.
Special installation requirements: Manufacturer did not specify.
Contact: Amana Heating and Air Conditioning, 281-536-6063; www.amana-hac.com.
eProduct 161
![Silver 16 low profile heat pump, 4A6H6 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/American-Standard-Silver-16-ACHR-News.jpg)
Serviceability features: Single-panel access to all components and demand defrost control with integrated diagnostics. The Nexia dealer diagnostic portal provides dealers remote access to system fault codes and alerts.
Noise-reduction features: Operating sound level in the range of 69 to 74 dBA. Utilizes a sound enclosure to reduce noise.
IAQ equipment supported: Compatible with the American Standard AccuClean whole house air cleaner, AccuExchange energy recovery ventilator, and EnviroWise inline ventilators.
Thermostat compatibility: Compatible with most thermostats. Requires a 24 V control.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The draw-through design discharges air away from the home to minimize recirculation and the potential for staining of the home that can occur with blow-through designs. The narrow design is ideal for zero lot line properties, hotels, condos, and other space-constrained installations.
Warranty information: Limited warranty (registered): 10-year compressor, coil, and parts. Limited warranty (nonregistered): five-year compressor, coil, and parts. Extended warranty available.
Special installation requirements: Requires a minimum of 6-inch clearance from the house on the coil side and 20-inch clearance from the fan outlet grille. A minimum of 2 inches is required and allowed when installed beneath a deck or overhang to allow access for removal of the top panel. Epoxy-coated coils can be special ordered for coastal applications.
Contact: American Standard Heating & Air Conditioning, 704-990-3932; www.americanstandardair.com.
eProduct 162
![F9MVE DuraComfort Deluxe 96 furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Arcoaire-F9MVE-DuraComfort-ACHR-News.jpg)
Serviceability features: A bright LED makes diagnostic flash codes easy to read. Allows technicians to see last seven stored fault codes even if power is interrupted. Blower assembly is mounted on rails for easy, upfront installation and removal. Large, robust one-quarter-turn knobs allow for easy door installation and removal.
Noise-reduction features: Quiet, variable-speed, electronically commutated motors (ECMs) minimize operating sound levels. The blower motor is attached with soft-mount rubber grommets that absorb sound and vibration. Insulated heat exchanger and blower compartments muffle sound and absorb vibration noise.
IAQ equipment supported: When coupled with a condensing unit and humidity-capable thermostat, mainline Arcoaire furnaces can control relative humidity during cooling operation. Furnaces have a dehumidification function in cooling mode and can control a humidifier accessory in heating mode.
Thermostat compatibility: Compatible with most thermostats. Communicating and self-configuring functions available only when used with the new Arcoaire Ion™ system control or the Observer® communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Furnaces are built with stainless steel secondary heat exchangers. Two-stage heat and two-stage cooling compatible, the furnace has electronically commutated (EC) variable-speed blower motor. The 35-inch unit is lightweight, and it is designed for four-way multi-position installation. Meets low NOx emissions standards.
Warranty information: Ten-year No Hassle Replacement™ limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoArcoaire.com.
eProduct 163
![PHR5 packaged heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Arcoaire-PHR5-ACHR-News.jpg)
Serviceability features: Installs easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll™ compressor, which operates most of the time in the quieter lower stage. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Enhanced dehumidification is available on high-stage cooling with use of a dehumidistat. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Two-stage Copeland Scroll compressors provide two-stage heating and cooling operation. Units include field convertible airflow for either ground level (horizontal) or rooftop (down) airflow and high-efficiency electronically commutated (EC) indoor blower motors. With cooling efficiencies up to 15.5 SEER and 12.5 EER, these heat pumps are Energy Star® qualified.
Warranty information: Five-year No Hassle Replacement™ limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoArcoaire.com.
eProduct 164
![GEO-DELTA geothermal heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Bard-GEO-DELTA-ACHR-News.jpg)
Serviceability features: Two-stage, step capacity scroll compressor; R-410A green refrigerant; high- and low-pressure switches; and stacking capabilities up to three high when multiple units are needed. Reversible control panel and four field selectable electrical entrance locations for maximum installation flexibility.
Noise-reduction features: Copeland Scroll, step-capacity, two-stage compressor, complete with compressor sound cover and mounted on full floating base.
IAQ equipment supported: Compatible with field-installed electronic air cleaner or high-efficiency media type filters through installing dealers.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Hydronic options include radiant floor heating, domestic water heating, and snow/ice melt. Suitable for ground water or ground loop applications. Features multi-capacity two stage compressor and R-410A refrigerant. Domestic hot water heat exchanger standard on reversible models.
Warranty information: Ten-year parts warranty, 10-year compressor warranty.
Special installation requirements: None.
Contact: Bard Mfg. Co. Inc., 419-636-1194; www.bardhvac.com.
eProduct 165
![Panel radiators - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Beacon-Morris-Panel-Radiator-ACHR-News.jpg)
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Panel radiators perform in all types of applications, including modern low temperature systems. They combine both radiant and convection. By using radiant heating, panel radiators are able to heat objects rather than space for individual comfort at lower temperature settings and increased efficiencies of the entire hydronic system. With over 70 configurations, the right product is available for virtually any hydronic heating application.
Warranty information: The manufacturer warrants to the original owner at the original installation site that the product will be free from defects in material or workmanship for a period not to exceed 10 years from startup or 128 months from date of shipment from the factory, whichever occurs first.
Special installation requirements: All radiators are finished with an attractive decorative grille, rounded edges, and can be installed anywhere with six different connection points.
Contact: Beacon Morris, 413-564-5779; www.beacon-morris.com.
eProduct 166
![Climate 5000 ductless mini-split system - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Bosch-Climate-5000-ACHR-News.jpg)
Serviceability features: Fan motor designed for quick removal and replacement. Universal internal control design reduces maintenance time and component complexity. Easy to detach air handler with simple, pull-out feature. Quick access to system components.
Noise-reduction features: This Energy Star-rated system provides high-efficiency, quiet comfort while lowering energy costs. Provides sound levels as low as 20 dBA when operating in Silent Mode.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Easy installation, with no ductwork required. Multiple systems available for single- and multi-zone applications. Surpasses the U.S. Environmental Protection Agency (EPA) requirement of at least 14 SEER, with a SEER rating of up to 22. With 3-D airflow, deflectors move automatically in all directions for a balanced airflow, covering every corner of the room.
Warranty information: Limited residential warranty up to five years (seven years for the compressor). This standard offering covers all components incorporated into the units at the time of manufacture. Unless otherwise stated, other components or parts that are purchased from Bosch and installed in the field have a one-year replacement parts warranty from proof of certificate of occupancy date or proof of certified start-up date.
Special installation requirements: Simplified installation allows for an easy mounting of the indoor air handler, quick connection of the refrigerant lines and electrical connections, and a 3-inch diameter (or less) opening for running the entire line set. This setup is perfect for tight spaces in a pinch or where ductwork cannot be accommodated. No ductwork is required, which means no messy renovation.
Contact: Bosch Thermotechnology Corp., 312-673-6063; www.bosch-climate.us.
eProduct 167
![Brute FT combi and heating only boiler - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Bradford-White-Brute-FT-ACHR-News.jpg)
Serviceability features: Robust fire-tube heat exchanger; fully modulating to save fuel; and Air-Conditioning, Heating and Refrigeration Institute (AHRI)-certified 95 percent AFUE efficiency rating. Available in natural gas or LP, the unit is offered as a combi unit in 140 and 199 Mbtuh sizes or as a heating boiler in 80, 100, 140, and 199 Mbtuh sizes.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Easy-to-use advanced control system; a conformal-coated control board protecting it from moisture; for added safety, a gas leak detection system that will shut the boiler down if a gas leak is detected; outdoor reset; domestic hot water priority (combi only); primeless condensate trap; venting up to 100 feet; and an Energy Star Most Efficient rating.
Warranty information: Limited 10-year warranty, five-year parts.
Special installation requirements: Manufacturer did not specify.
Contact: Bradford White Water Heaters, 215-641-9400; www.bradfordwhite.com.
eProduct 168
![Q7RF dedicated horizontal packaged heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Broan-Q7RF-ACHR-News.jpg)
Serviceability features: All major components are contractor-friendly at the perimeter of the unit: compressor, blower assembly, thermostatic expansion valve (TXV), and electrical. Blower motor operation is a simple, constant, high voltage in and low-voltage input control, so troubleshooting is easy. Two-stage compressor (mechanically loaded) controlled by low voltage — voltage and amperage spikes determine diagnosis. Easy access to TXV for operational confirmation.
Noise-reduction features: Swept-wing fan blade is matched to a condenser fan motor in a highly engineered custom venturi opening. The seamless two-stage switchover and closed cell blanket surrounding the entire compressor reduces objectionable outdoor noise. A five-speed electronically commutated motor (ECM) blower and fully insulated return section provide low vibration and noise-dampening features on the inside of this packaged product.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats. Two-stage heat pump thermostat is recommended to deliver optimum savings and comfort.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This unit is built around the Copeland Ultra Tech II two-stage compressor. Unit runs most of the time in first stage, saving the homeowner money while keeping the home comfortable. Single-pass, all-aluminum coils and no copper transfer tubes make for a more durable coil with greater serviceability.
Warranty information: Five-year limited parts warranty and one-year Quality Pledge to replace the unit if the compressor fails within the first year. If the product is registered within 60 days of purchase, the coverage increases to a 10-year limited parts warranty and a 10-year Quality Pledge. Extended warranties are available through the Contractors’ Preferred Protection Plan.
Special installation requirements: There are no special installation requirements for this product.
Contact: Nortek Global HVAC, 800-422-4328; nortekhvac.com.
eProduct 169
![R6GI convertible packaged gas/electric unit - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Broan-R6GI-ACHR-News.jpg)
Serviceability features: Onboard inverter diagnostics with easy-to-read LED two-digit display for 29 possible faults with log. Inverter mounts on a pull-out bracket for convenient compressor and expansion valve access. Furnace board with simple, two-light LED fault display and single-light flame signal strength. All components lie on the perimeter of the unit for ease of service. Outdoor single-pass, all-aluminum coil allows ease of cleaning and repair.
Noise-reduction features: The swept-wing fan blade matched with the electronically commutated (EC) condenser fan motor assembly, operating within a highly engineered venturi opening and closed-cell blanket surrounding the entire compressor reduces objectionable outdoor noise. The 16-speed selectable variable-speed blower motor, fully insulated return section, and seamless electric expansion valve (EXV) operation provide low vibration and noise-dampening features on the inside of this packaged product.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats. Two-stage thermostat recommended for full operational savings and comfort range.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: All motors (condenser fan, blower, and compressor) are variable speed. Inverter technology starts, runs, and stops the compressor with complete accuracy and monitoring capability during normal and abnormal operation.
Warranty information: Five-year limited parts warranty and one-year Quality Pledge to replace the unit if the compressor fails or heat exchanger fails within the first year. If the product is registered within 60 days of purchase, the coverage increases to a 10-year limited parts warranty and a 10-year Quality Pledge. Extended warranties are available through the Contractors’ Preferred Protection Plan.
Special installation requirements: There are no special installation requirements for this product.
Contact: Nortek Global HVAC, 800-422-4328; www.nortekhvac.com.
eProduct 170
![313ABV Performance Plus 80x furnace. - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Bryant-313ABV-ACHR-News.jpg)
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Compatible with all Bryant IAQ equipment.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This represents a model expansion to better match Southern cooling requirements, which include better flush mount coil matchups, lower heating-to-cooling ratios, and improved high static airflows.
Warranty information: Five-year standard warranty; 10 years with registration.
Special installation requirements: Manufacturer did not specify.
Contact: Bryant, 317-847-6930; www.bryant.com.
eProduct 171
![Evolution heat pump with base pan heater, 38MPRA/619PHA - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Bryant-Evolution-38MPRA-ACHR-News.jpg)
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats. Any thermostat using the 24 V interface.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This Energy Star-qualified ductless system comes with a 42-SEER rating when paired with the 619PHA high wall. Even when temperatures drop to as low as minus 22°F outside, the interior environment stays cozy (when properly sized and matched with specific indoor units).
Warranty information: Manufacturer did not specify.
Special installation requirements: Manufacturer did not specify.
Contact: Bryant, 317-847-6930; www.bryant.com.
eProduct 172
![Infinity heat pump with base pan heater, 38MPRA/40MPHA - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Carrier-Infinity-38MPRA-ACHR-News.jpg)
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats using the 24 interface, and it can use the special thermostat.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: When paired with the 40MPHA indoor unit, this system has a SEER rating of 42 with 15 HSPF, making it Energy Star certified. Its cooling operating range maintains consistent capacity from minus 22° to 122°F, and its heating operating range maintains 100 percent capacity from minus 22° to 86°.
Warranty information: Five-year warranty; 10 years with registration.
Special installation requirements: Manufacturer did not specify.
Contact: Carrier, 317-847-6930; www.carrier.com.
eProduct 173
![Performance Boost 80 furnace, 58PHB - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Carrier-Performance-Boost-80-Furnace-ACHR-News.jpg)
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Compatible with all of Carrier’s IAQ accessories.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This represents a model expansion to better match Southern cooling requirements, which include better flush mount coil match ups, lower heating to cooling ratios, and improved high static airflows.
Warranty information: Standard five-year warranty, with an additional five years upon registration.
Special installation requirements: Manufacturer did not specify.
Contact: Carrier, 317-847-6930; www.carrier.com.
eProduct 174
![Momentum Series HL20 variable-capacity heat pump, HL024-060 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Champion-Momentum-HL20-ACHR-News.jpg)
Serviceability features: Simplified servicing with Charge Guard™. A touchscreen provides a readout of system condition as well as head pressure and suction pressure while calculating superheat and subcooling. A swing-open electrical box provides corner access to unit interior. The Wi-Fi Hx3 thermostat supports a service app for remote service and monitoring.
Noise-reduction features: Features ShadowDrive™ system with attributes such as flat wire fan guard, swept-wing fan blade, sound-absorptive composite base pan, multi-density compressor cloak, and variable-capacity operation to reduce sound as low as 54 dBA.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16.
Thermostat compatibility: Requires a special thermostat. Designed to operate with the Wi-Fi-enabled communicating Hx3 thermostat with consumer and contractor remote access app.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Variable-capacity, inverter-controlled scroll compressor adjusts system capacity from 35 to 100 percent to meet comfort demands. Integration with Champion Momentum Hx3 thermostat provides access and control for maximum comfort and minimum power consumption. Charge Guard provides simplified setup, charging, and evaluation. Refrigerant gauges aren’t needed to evaluate the system during maintenance.
Warranty information: One-year labor limited warranty, limited lifetime compressor warranty, and 10-year parts limited warranty with registration. Extended warranties available to purchase.
Special installation requirements: Climate Mark™ technology simplifies setup with preconfigured profiles, part of a matched communicating system using Champion AVV air handlers and CM coils with factory-mounted electronic expansion valves (EEVs).
Contact: Champion, 405-419-6545; www.championhomecomfort.com/momentum.
eProduct 175
![Momentum Series modulating gas furnace, TP9C060-120 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Champion-Momentum-TP9C060-120-ACHR-News.jpg)
Serviceability features: Rotatable inducer for venting out top or side. Every unit is one- or two-pipe vent compatible. Built-in condensate trap removed from the blower compartment simplifies installation. Toolless entry with quarter-turn knobs. Flexible installation will work with conventional thermostats or the Hx3 Wi-Fi communicating thermostat when a limited number of thermostat wires are available.
Noise-reduction features: Fully insulated cabinet enhances thermal and acoustic performance. Dynamically balanced blower and motor assembly minimize sound. Variable-speed inducers and blowers maximize performance while minimizing sound.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16.
Thermostat compatibility: Compatible with most conventional single-stage thermostats. Added features and functions are available by using the Hx3 Wi-Fi four-wire communicating thermostat, which, with the proper app, supports remote access for the consumer and contractor.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Modulating heating operation can range from 35 to 100 percent capacity to meet comfort needs while saving energy. Integration with Champion Momentum Hx3 thermostat provides unprecedented consumer and contractor control for maximum comfort and minimum power consumption.
Warranty information: Lifetime heat exchanger limited warranty, 10-year parts limited warranty, and 10-year Complete Assurance™ limited warranty pledge: If the heat exchanger fails within 10 years of installation, manufacturer provides optional furnace replacement in lieu of heat exchanger replacement. To take advantage of this offer, customers must register online within 90 days.
Special installation requirements: Multi-position unit for all installed positions — simply rotate the inducer to the desired venting position, whether out the top or side. Integral condensate trap — just connect the drain. Compatible with the various approved venting material. Approved for one- and two-pipe installations. Wide range of accessories include propane conversion kit, IAQ, and vent termination accessories.
Contact: Champion, 405-419-6545; http://bit.ly/ChampionTP9C.
eProduct 176
![Echelon Series modulating gas furnace, CP9C060-120 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Coleman-Echelon-CP9C060-120-ACHR-News.jpg)
Serviceability features: Rotatable inducer for venting out top or side. Every unit is one- or two-pipe vent compatible. Built-in condensate trap, removed from the blower compartment, simplifies installation. Toolless entry with quarter-turn knobs. Flexible installation will work with conventional thermostats or the Hx3 Wi-Fi communicating thermostat when a limited number of thermostat wires are available.
Noise-reduction features: Fully insulated cabinet enhances thermal and acoustic performance. Dynamically balanced blower and motor assembly minimize sound. Variable-speed inducers and blowers maximize performance while minimizing sound.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16.
Thermostat compatibility: Compatible with most conventional single-stage thermostats. Added features and functions are available by using the Hx3 Wi-Fi four-wire communicating thermostat, which, with the proper app, supports remote access for the consumer and contractor for both monitoring and control.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Modulating heating operation can range from 35 to 100 percent capacity to meet comfort needs precisely while saving energy. Integration with Coleman Echelon Hx3 thermostat provides unprecedented consumer and contractor control for maximum comfort and minimum power consumption.
Warranty information: Lifetime heat exchanger limited warranty, 10-year parts limited warranty, and 10-year Complete Assurance limited warranty pledge: If the heat exchanger fails within 10 years of installation, manufacturer provides optional furnace replacement in lieu of heat exchanger replacement. To take advantage of this offer, customers must register online within 90 days.
Special installation requirements: Multi-position unit for all installed positions — simply rotate the inducer to the desired venting position, whether out the top or side. Integral condensate trap — just connect the drain. Compatible with the various approved venting material. Approved for one- and two-pipe installations. Wide range of accessories include propane conversion kit, IAQ, and vent termination accessories.
Contact: Coleman, 405-419-6545; http://bit.ly/Coleman-CP9C.
eProduct 177
![Echelon Series HC20 variable-capacity heat pump, HC024-060 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Coleman-Echelon-HC024-060-ACHR-News.jpg)
Serviceability features: Simplified servicing with Charge View™. A touchscreen provides a readout of system condition as well as head pressure and suction pressure while calculating superheat and subcooling. A swing-open electrical box provides corner access to unit interior. The Wi-Fi Hx3 thermostat supports a service app for remote service and monitoring.
Noise-reduction features: Features WhisperDrive™ system with attributes such as flat wire fan guard, swept-wing fan blade, sound-absorptive composite base pan, multi-density compressor cloak, and variable-capacity operation to reduce sound as low as 54 dBA.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16.
Thermostat compatibility: Requires a special thermostat. Designed to operate with the Wi-Fi enabled communicating Hx3 thermostat with consumer and contractor remote access app.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Variable-capacity, inverter-controlled, scroll compressor adjusts system capacity from 35 to 100 percent to meet comfort demands. Integration with Coleman Echelon Hx3 thermostat provides access and control for maximum comfort and minimum power consumption. Charge View provides simplified setup, charging, and evaluation. Refrigerant gauges aren’t needed to evaluate the system during maintenance.
Warranty information: Ninety-day limited labor warranty, limited lifetime compressor warranty, 10-year parts limited warranty with registration. Extended warranties available to purchase.
Special installation requirements: Climate Connect™ technology simplifies setup with preconfigured profiles, part of a matched communicating system using Coleman AVV air handlers, and CM coils with factory-mounted electronic expansion valves (EEVs).
Contact: Coleman, 405-419-6545; www.colemanac.com/echelon.
eProduct 178
![UltraV single/multi mini-split heat pump, VMH-U Series - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Comfort-Aire-UltraV-ACHR-News.jpg)
Serviceability features: These units carry a full complement of fault codes to direct the service technician quickly to any operational issue, including the ability — in cooling — to diagnose low refrigerant charge. A comprehensive service manual is available at www.marsdelivers.com to direct the service provider through any problem, while a technical service team is available at 800-678-9888.
Noise-reduction features: Condenser fan blades use the science of biomimicry, imitating the wings of birds of prey, to create a virtually noise-free unit. The indoor axial fan blade is designed to quietly deliver an even airflow over the full length of the unit.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Outdoor units range from 9,000 to 48,000 Btuh and single-zone to five-zone. Indoor units are available in high-wall, ceiling cassettes, wall/ceiling units, floor consoles, and ducted units. All can be used on single- through five-zone applications. All but the 48,000 Btuh unit have a minimum operating temperature of minus 22°F, with at or near 100 percent capacity at 5° for multi-zone units and 0° for single-zone units.
Warranty information: Standard warranty for this series is two-year all parts, seven-year compressor. The parts warranty is extended to three years when a Mars surge protector is included as part of the installation.
Special installation requirements: Consult the accompanying installer’s manual for minimum and maximum line lengths and communication wire type. Always perform the initial startup in cooling mode to ensure any contaminants are captured before traveling through critical components.
Contact: Heat Controller/Mars, 517-787-2100; www.marsdelivers.com.
eProduct 179
![CVH8 SoftSound Deluxe 18 variable-speed heat pump with SmartSense technology - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Comfortmaker-CVH8-SoftSound-ACHR-News.jpg)
Serviceability features: When installed as part of a complete communicating system, including the Ion™ system control with Wi-Fi capability or the Observer communicating control, the heat pump offers precise system control with remote access, text-based diagnostics, and contractor information displayed. The unit features easy-access service valves.
Noise-reduction features: Variable-speed compressor and compact electronically commutated (EC) fan motor operate at quiet, low speeds most of the time (as low as 56 decibels). Soft start and smooth ramp-up to operating speeds. Cabinet includes isolation compressor grommets and a high-performance compressor sound shield for lower noise, better airflow, and higher efficiency.
IAQ equipment supported: As part of an installed system, compatible with Comfortmaker IAQ system components: humidifiers, ventilators, and UV lamps.
Thermostat compatibility: Compatible with most thermostats. Five-stage operation, communicating and self-configuring functions only available when used with new Ion system control or Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: When installed as part of a complete communicating system, the heat pump provides five-stage variable-speed technology in a compact design. Efficiencies up to 11 HSPF/19 SEER.
Warranty information: Ten-year limited warranty on parts, including compressor and coils, to original homeowner upon timely registration. Limited warranty period is five years for parts if not registered within 90 days of installation. Product qualifies for the 10-year No Hassle Replacement limited warranty. (If the compressor or covered coil fails within 10 years of installation date, then ICP will provide a one-time replacement outdoor unit at no charge.) Some restrictions apply. See warranty certificate for details.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoComfortmaker.com.
eProduct 180
![G9MAE SoftSound Deluxe 98 furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Comfortmaker-G9MAE-ACHR-News.jpg)
Serviceability features: When connected to an Ion system control or Observer communicating control, system information is displayed on a touchscreen. The system self-configures for optimal performance. Features large, one-quarter-turn knobs for easy door installation/removal. Bright LED makes diagnostic flash codes easier to read. Blower assembly is mounted on rails for easy, upfront installation/removal.
Noise-reduction features: Variable-speed electronically commutated (EC) blower motor reduces operating sound levels. Special blower mount quiets vibration and cuts sound. Insulated steel cabinet absorbs sound from heat exchanger and blower compartments.
IAQ equipment supported: When coupled with a condensing unit and humidity-capable thermostat, mainline Comfortmaker furnaces can control relative humidity during cooling operation. These furnaces have a dehumidification function in cooling mode and can control a humidifier accessory in heating mode.
Thermostat compatibility: Compatible with most thermostats. Communicating and self-configuring functions only available when used with the Comfortmaker Ion system control or Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Furnaces are built with stainless steel secondary heat exchangers. Modulating (multi-stage) gas valves allow furnaces to operate on a quieter low-heat setting unless thermostat calls for more heat. Designed for four-way multi-position installation — 35 inches tall and lighter weight than previous counterparts.
Warranty information: Ten-year No Hassle Replacement limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoComfortmaker.com.
eProduct 181
![4HP15L heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Concord-4HP15L-heat-pump-ACHR-News.jpg)
Serviceability features: Easy access to electrical panels and pre-wired for easy hook-up.
Noise-reduction features: Quiet Shift technology allows the heat pump to enter defrost mode without excessive noise. The top discharge directs air and sound away from living area and features a muffler for quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: A high-quality condenser coil with copper enhanced tube and fin design allows for maximum heat transfer capability. Louvered panel coil protection, solid state defrost control, integrated control with LED diagnostics, and a low-pressure switch factory installed for loss of charge protection.
Warranty information: Ten-year limited warranty on compressor, 10-year limited warranty on all parts, extended warranty available. Warranty provides for a total of 10 years of limited warranty coverage (standard five-year limited parts warranty plus an additional five-year limited extended parts warranty). Must be registered online within 60 days of installation.
Special installation requirements: Bidirectional liquid line filter drier factory installed. Short-cycle protection factory installed. Charge for 15 feet of interconnecting tubing.
Contact: Allied Air Enterprises, 803-738-4138; www.concord-air.com.
eProduct 182
![AURORA multi-zone heat pump systems - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Daikin-Aurora-ACHR-News.jpg)
Serviceability features: Space-saving indoor unit installation options including wall mount, floor mount, concealed slimduct, and ceiling cassette. Built-in diagnostics with digital display and potentially hundreds of fault codes that can diagnose performance and other issues. Outdoor coils feature anticorrosion treatment. Auto restart after power failure. Hand-held remote for easy system control.
Noise-reduction features: Quiet outdoor unit operation with sound pressures as low as 50 dBA. Daikin variable-speed inverter compressor gently ramps up or down for quiet operation. Sound blankets further reduce noise.
IAQ equipment supported: Advanced filtration design includes long-life, washable filters, or titanium apatite photocatalytic air purifying filters, depending on the indoor unit model.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Designed for extreme temperatures, the heat pump provides enhanced heating capacity up to 100 percent at 5°F (-15°C) and up to 100 percent cooling capacity at 104°F (40°C). Cooling efficiency levels up to 18 SEER. The multi-zone system is also compatible with Daikin’s new wall-mounted EMURA unit. Wall- and ceiling-mount indoor units are equipped with an intelligent eye feature that automatically adjusts temperature and air movement.
Warranty information: Complete warranty details available from local dealer or at www.daikincomfort.com. To receive the 12-year parts limited warranty, online registration must be completed within 60 days of installation. Online registration and some of the additional requirements are not required in California or Quebec.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct 183
![EMURA CTXG_QVJUW/S wall-mounted indoor unit for multi-zone heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Daikin-Emura-ACHR-News.jpg)
Serviceability features: The compact size (8 by 12 by 39 inches) and light weight (27 pounds) makes the unit easy to install and service.
Noise-reduction features: As low as 21 dBA.
IAQ equipment supported: A titanium apatite photocatalytic air purification filter cleans the air.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: High efficiencies, up to 21 SEER, with a wide operating range from 14° to 115°F for cooling and minus 13° to 60° for heating. Available in silver or white. Inside is a highly intelligent system that can be controlled with a standard wireless remote or via the wireless interface adapter and Daikin Comfort Control app.
Warranty information: Complete warranty details available from local dealer or at www.daikincomfort.com. To receive the 12-year parts limited warranty, online registration must be completed within 60 days of installation. Online registration and some of the additional requirements are not required in California or Quebec.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct 184
![DM97MC modulating variable-speed furnace with ComfortNet communicating system - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Daikin-DM97MC-ACHR-News.jpg)
Serviceability features: Designed for multi-position installation. Easy to install top venting with optional side venting. Convenient left or right connection for gas/electrical service. Airtight solid bottom or side return with easy-cut tabs for effortless removal in bottom air-inlet applications. Self-diagnostic control board with constant memory fault code history to a dual seven-segment display.
Noise-reduction features: Variable-speed electronically commutated motor (ECM) and induced draft motors efficiently ramp up or down, providing quiet system startup and operation. Multiple continuous fan speed options offer quiet air circulation. Fully insulated heat exchanger and blower section with a thermal insulated cabinet that provides air leakage of less than 2 percent to further reduce blower noise.
IAQ equipment supported: Compatible with Clean Comfort IAQ products. Color-coded low-voltage terminals with provisions for electronic air cleaner and humidifier connections. Auto-Comfort and Enhanced Dehumidification modes available. Complies with California 40 ng/J low NOx emissions standard.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Uniquely designed tubular stainless steel primary heat exchanger with wrinkle-bend technology provides outstanding durability and heat transfer. Secondary stainless steel heat exchanger adds increased efficiency. Self-calibrating modulation gas valve auto-configured for each installation. Durable silicon nitride igniter. Heavy-gauge steel cabinet with durable finish provides increased cabinet strength.
Warranty information: Lifetime heat exchanger limited warranty (good for as long as owner owns home) plus a 12-year unit replacement limited warranty and a 10-year parts limited warranty with online registration completed within 60 days of installation. Online registration is not required in Quebec or California.
Special installation requirements: Certified for direct vent (two-pipe) or non-direct vent (one-pipe) installations.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct 185
![VRV LIFE furnace and heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Daikin-VRV-LIFE-ACHR-News.jpg)
Serviceability features: The small footprint and side discharge design of the outdoor heat pump provides placement flexibility, requires little space, and allows for easy service access in tight areas. Ability to reuse existing liquid and suction lines for easy replacement of existing equipment.
Noise-reduction features: Quiet operation with outdoor unit sound levels as low as 57 dBA allow for installation flexibility in areas close to lot lines and other sensitive applications where low sound levels are important.
IAQ equipment supported: Optional air cleaner modules, humidifiers, dehumidifiers, ultraviolet air purifiers, and fresh air ventilation accessory systems are available.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Provides flexibility, zoning, low sound, space savings, and the ability to mix and match several styles of ducted and duct-free indoor models. Up to nine indoor units can be connected to one outdoor VRV heat pump to heat or cool, with high heating capacities well below 0°F (minus 18°C). The VRV LIFE offering includes a ducted-style furnace and evaporator coil, allowing two furnace/coils to be connected to one outdoor unit.
Warranty information: Standard 10-year parts limited warranty and 10-year compressor replacement limited warranty. Complete warranty details are available from local Daikin manufacturer’s representative or distributor or at www.daikincomfort.com.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct 186
![N9MSE Performance 96 furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Day-Night-N9MSE-ACHR-News.jpg)
Serviceability features: Sturdy knobs allow service technicians to remove and replace furnace doors with a twist of the wrist. Features four position installation options, 12 different venting combinations, and self-diagnostics from the easy-to-read LED screen. Slide-out heat exchanger and blower assembly.
Noise-reduction features: Special blower mount quiets vibration and cuts sound. Cabinet insulation absorbs sound from heat exchanger compartment.
IAQ equipment supported: Versatile 24- and 115-V connections allow for easy attachment of electronic air cleaners and humidifiers.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Four-position installation capability. Direct ignition with silicon nitride igniters that last long, can tolerate high-line voltage, and don’t require voltage regulators. Meets California low NOx standards. Dual certified venting. Internal condensate drain system. High-temperature limit control guards against overheating.
Warranty information: Twenty-year heat exchanger limited warranty; 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoDayandNight.com.
eProduct 187
![PGR5 packaged gas/electric unit - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Day-Night-PGR5-ACHR-News.jpg)
Serviceability features: Installs easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll compressor, which operates most of the time in the quieter lower stage. Also includes a two-stage heating system that offers similar comfort benefits in the heating mode. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Dehumidification mode (airflow reduction) standard on all models. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Two-stage heating and cooling operation, stainless steel tubular heat exchangers, field convertible airflow, and high-efficiency electronically commutated (EC) indoor blower motors. Energy Star qualified, with cooling efficiencies up to 16 SEER and 12.5 EER.
Warranty information: Five-year No Hassle Replacement limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoDayandNight.com.
eProduct 188
![96G1E furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Ducane-96G1E-Furnace-ACHR-News.jpg)
Serviceability features: Unit is out-of-the-box ready for vertical or horizontal installation with left or right gas and electrical connections. Includes condensate drain with built-in clean out, which can be remote mounted up to 5 feet away; pre-formed flange connections for easy coil installation; and vent piping that works with standard PVC glue.
Noise-reduction features: Unique 11,000-Btu burner assembly and weld-free, mini-clamshell heat exchanger reduce combustion noise levels, providing enhanced homeowner comfort.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star certified. Features include intake and vent piping that can be in different pressure zones, and the serviceable components all use ¼-inch forward-facing screws.
Warranty information: Warranty provides for a total of 10 years of limited coverage (standard five-year limited parts warranty plus an additional five-year limited extended parts warranty). Must be registered online within 60 days of installation. Lifetime warranty on the heat exchanger with registration.
Special installation requirements: Installation must abide by state and local codes.
Contact: Allied Air Enterprises, 803-738-4054; www.ducanehvac.com.
eProduct 189
![ESI ULTRA Series heat pump, ULTRA 36K - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Ecoer-ESI-ULTRA-ACHR-News.jpg)
Serviceability features: The Ecoer Smart Service (ESS) app provides remote diagnostic wireless monitoring and troubleshooting alerts. Printed circuit board (PCB) provides optional LED display and troubleshooting codes on job site. Only one integrated PCB for condensing unit. Limited models with fewer components. Easy PCB replacement design with only six screws requires only 10 minutes for replacement. Plug-and-play design makes service easy. Safety protection design using plastic cover to isolate high-voltage components.
Noise-reduction features: As low as 56dB for condensers. Brushless DC inverter motor with true variable speed. DC inverter compressor with true variable speed. Noise-cancelling jacket reduces noise level. Quiet fan blade design reduces noise generated by air movement. Electronically commutated motor (ECM) on the indoor air handler keeps sound lower. Foil insulation on indoor cabinet reduces noise level.
IAQ equipment supported: System supports most of the existing IAQ equipment.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Two models of smart air conditioners can report all data through the ESS app. Monitoring service on installation quality and performance available 24/7. Refrigerant Precise Charging auto charging technology. Wireless communication between indoor and outdoor units. Same wiring as single-speed systems. Hyper heating offers 100 percent heating capacity down to 5°F; hyper cooling capacity is 100 percent cooling capacity up to 113°.
Warranty information: Ten-year limited warranty on parts and compressors if properly registered. Labor warranty optional. Warranty registration can be done in two minutes at job site with ESS smart phone app.
Special installation requirements: Third-party coils or indoor units could match with Ecoer inverter condensers. Thermostatic expansion valve (TXV) for indoor coil required. Must follow Air-Conditioning, Heating and Refrigeration Institute rating regulations.
Contact: ECOER INC, 703-348-2988; www.ecoer.com.
eProduct 190
![Q8SF convertible packaged heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Frigidaire-Q8SF-ACHR-News.jpg)
Serviceability features: All major components are contractor friendly at the perimeter of the panelized unit: compressor, blower assembly, thermostatic expansion valve (TXV), and electrical. Blower motor operation is a simple, constant high voltage in, and speed is controlled by a fault-detecting PCB with a selection of eight dipswitches for 16 speeds. Two-stage compressor (mechanically loaded) controlled by low voltage — voltage and amperage spikes determine diagnosis. Easy access to TXVs and reversing valve coils for operational confirmation.
Noise-reduction features: Fully insulated return compartment. Precisely matched fan blade and motor technology combined with highly engineered custom venturi fan orifice reduces unwanted vibration and noise. Two-stage compressor with compressor blanket lessens noise in mild climates when running on first stage. The 16-speed blower motor offers one of the widest ranges to lessen the noise impact caused by excessive blower speed.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats. Two-stage heat pump thermostat gives the homeowner the most efficient and comfortable system.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Single-pass, all-aluminum coil technology used on both condenser and evaporator coils reduces refrigerant charge and weight while providing maximum protection, heat transfer, and cleanability. Proven, patented, and innovative hot gas defrost system ensures complete defrost cycle and provides a wide range of seven-segment status codes. The 16-speed blower motor offers a wide range of capacities that can overcome some challenging static and noise situations.
Warranty information: Five-year limited parts warranty and one-year Quality Pledge to replace the unit if the compressor fails within the first year. If the product is registered within 60 days of purchase, the coverage increases to a 10-year limited parts warranty and a 10-year Quality Pledge. Extended warranties are available through the Contractors’ Preferred Protection Plan.
Special installation requirements: There are high wind accessory kits for ground or roof mount that meet Florida’s building codes.
Contact: Nortek Global HVAC, 800-422-4328; www.nortekhvac.com.
eProduct 191
![R8HE convertible packaged gas/electric unit - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Frigidaire-R8HE-ACHR-News.jpg)
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Swept-wing fan blade combined with highly engineered and custom venturi discharge opening minimizes vibration and reduce noise. Copeland Scroll’s compression movement is favorable to reciprocating compressors. Fully insulated return section minimizes indoor noise caused by blower operation. The 16-speed variable-speed blower with balance wheel and optimized housing ensures quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats. Two-stage heat and single-stage cooling thermostat will provide the most efficiency and comfort for the home, but the furnace board does have a high fire timer if needed.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Currently the only residential condensing gas packaged unit on the market. All-aluminum, single-pass coils used on the condenser and the evaporator sections reduce unit and refrigerant weight as well as optimize heat transfer and maintenance. Unique thaw cycle ensures that gas heat is available even in harsh climates. SmartLite feature of the integrated furnace control (IFC) learns specific light-off characteristics of each unique application and adjusts igniter timing to extend igniter life.
Warranty information: Five-year limited parts warranty and one-year Quality Pledge to replace the unit if the compressor or heat exchanger fails within the first year. If the product is registered within 60 days of purchase, the coverage increases to a 10-year limited parts warranty and a 10-year Quality Pledge. Extended warranties are available through the Contractors’ Preferred Protection Plan.
Special installation requirements: The condensate removal is much like a normal condensing furnace. The collector box has a valve that is utilized for roof-mount units — condensate must be brought to a conditioned space, trapped, and disposed of properly. In a ground-mount situation, condensate will track through the vent piping and down a drain 6 to 8 inches below the frost line.
Contact: Nortek Global HVAC, 800-422-4328; www.nortekhvac.com.
eProduct 192
![Multi-zone system, AOU36RLXFZH - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Fujitsu-AOU36RLXFZH-ACHR-News.jpg)
Serviceability features: Self-diagnostic system with easy-to-read LED error codes that can be looked up in Fujitsu’s Mobile Technician app for step-by-step troubleshooting.
Noise-reduction features: Sound pressure level is 55 dBA.
IAQ equipment supported: In certain indoor models, ion deodorization filters decompose absorbed odors using the oxidizing/reducing effects of ions generated by the ultra-fine-particle ceramic and Apple-Catechin filters, absorbing fine dust, invisible mold spores, and harmful microorganisms onto the filter by static electricity, inhibiting and deactivating further growth. Three-year life expectancy. Wash to restore surface action.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Extra-low temperature heating at outdoor temperatures down to -15°F, a programmable remote control, inverter technology, and Energy Star qualified. Outdoor unit features a base heater preventing condensate from freezing.
Warranty information: Standard five-year parts and seven-year compressor warranty. Units that have been installed by a licensed contractor and registered have a 10-year parts and compressor warranty. Units that have been installed by an Elite contractor and registered have a 12-year parts and compressor warranty. See warranty statement for full details.
Special installation requirements: Units have to be installed within 82 feet of each other. The unit has a minimum line set length of 17 feet per unit. The unit has a minimum of 50 feet combined between the line sets.
Contact: Fujitsu General America, Inc., 973-575-0380 x1645; www.fujitsugeneral.com.
eProduct 193
![Guide Series variable-speed water-to-water geothermal heat pump, GWV060 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Geocomfort-GWV060-ACHR-News.jpg)
Serviceability features: A large LCD control screen displays settings, diagnostics, and running conditions, such as heat of extraction/rejection, discharge/suction pressures, superheat/subcooling, flow in gallons per minute, and more. This allows technicians to verify optimum performance at a glance without tools. The onboard control includes a time-saving factory startup wizard with pre-programmed setup options to shorten installation time.
Noise-reduction features: Exclusive design includes triple compressor isolation, featuring elastomeric vibration absorption pads, a heavy-gauge compressor isolation plate, high-density rubber grommets, and UL Greenguard Gold-certified cabinet insulation. Copeland’s variable-speed Scroll compressor and integrated variable-speed load pump also contributes to noise reduction.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most zone controls and their thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Built to provide radiant in-floor heating, forced-air heating and cooling (when paired with an air handler or A coil), and 100 percent of the domestic hot water needed 24/7, on-demand. With the help of an outdoor temperature sensor, the modulating compressor adjusts to deliver the perfect water temperatures for a radiant or hydronic system application.
Warranty information: Standard 10-year all parts warranty (the tank comes with a manufacturer’s warranty, which is currently up to 15 years on parts). All unit components and select accessory components are covered for 10 years, with a 10-year labor allowance on select parts and accessories (registration required).
Special installation requirements: To order and install this system, contractors must complete free training through the manufacturer, available throughout the year at www.geothermaluniversity.com/training-calendar.html.
Contact: Enertech Global LLC, 618-690-3231; www.geocomfort.com.
eProduct 194
![GMEC96 14-inch gas furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Goodman-GMEC96-ACHR-News.jpg)
Serviceability features: Self-diagnostic control board continuously monitors system for consistent, reliable operation and indicates condition via LED for quick troubleshooting. Designed for multi-position installation — upflow and horizontal left or right. Certified for direct (two-pipe) or non-direct (one-pipe) vent. Easy-to-install top venting; optional side venting. Convenient left or right connection for gas/electrical service. Airtight solid bottom or side return with easy-cut tabs for effortless removal in bottom air-inlet applications.
Noise-reduction features: A quiet two-speed induced draft blower with low continuous fan speed options offers quiet air circulation. The fully insulated thermal cabinet means air leakage of less than 2 percent to maximize the heat transfer efficiency and lower blower noise.
IAQ equipment supported: Color-coded low-voltage terminals with provisions for electronic air cleaner and humidifier. Supports Clean Comfort IAQ products and other IAQ products. All models comply with California 40 ng/J low NOx emissions standard.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: At 14 inches wide, the compact furnace provides high-efficiency heating with 96 percent-plus AFUE ratings. The aluminized steel tubular primary heat exchanger — with distinctive tubular aluminized steel construction formed using wrinkle-bend technology — provides durability, long-term reliability, and efficiency.
Warranty information: Lifetime heat exchanger limited warranty (as long as buyer owns home); 10-year unit replacement limited warranty; and 10-year parts limited warranty when online registration is completed within 60 days of installation. Complete warranty details available from local dealer or at www.goodmanmfg.com. Online registration is not required in California or Quebec.
Special installation requirements: Manufacturer did not specify.
Contact: Goodman Mfg., 281-536-6063; www.goodmanmfg.com.
eProduct 195
![Multi21+ heat pump, MULTI18HP230V1CO - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Gree-MULTI18HP230V1CO-ACHR-News.jpg)
Serviceability features: Top and side access to service all components for ease of maintenance.
Noise-reduction features: G10 inverter technology saves energy and reduces outdoor noise.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires factory-supplied thermostat.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: G10 inverter control. Up to 22 SEER and 12.5 HSPF. Sound levels down to 56 dBA on outdoor unit. Low ambient cooling down to 0°F. Multi-point diagnostics. Multi-speed fans. Swing louvers. Cleanable air filters. Infrared remote controller. Wired controller on select models. Power failure recovery.
Warranty information: Five-year parts, five-year limited unit replacement (with refrigerant component failure).
Special installation requirements: Required installation from a licensed contractor.
Contact: Tradewinds Climate Systems, 754-707-4220; www.greecomfort.com.
eProduct 196
![Sapphire heat pump, SAP09HP230V1A - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Gree-SAP09HP230V1A-ACHR-News.jpg)
Serviceability features: Top and side access to service all components for ease of maintenance.
Noise-reduction features: G10 inverter technology saves energy and reduces outdoor noise.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat. Compatible only with wired Xk41 and Xb76 thermostats.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Up to 38 SEER in heating to reduce energy consumption up to 65 percent. Ultra Heat technology for temperatures as low as minus 22°F. G10 inverter and variable-speed compressor technology. I-Feel automation setting. Photocatalytic filter. Built-in universal Wi-Fi technology.
Warranty information: Five-year parts, five-year unit replacement (if any part in the refrigerant circuit fails).
Special installation requirements: Required by licensed contractor.
Contact: Tradewinds Climate Systems, 754-707-4220; www.greecomfort.com.
eProduct 197
![G9MVE QuietComfort Deluxe 96 furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Heil-G9MVE-QuietComfort-ACHR-News.jpg)
Serviceability features: The LED makes diagnostic flash codes easy to read. Allows technicians to see last seven stored fault codes even if power is interrupted. Blower assembly is mounted on rails for easy upfront installation and removal. Large, robust, one-quarter-turn knobs for easy door installation and removal.
Noise-reduction features: Variable-speed, electronically commutated motors (ECMs) minimize operating sound levels. The blower motor is attached with soft-mount rubber grommets that absorb sound and vibration. Insulated heat exchanger and blower compartments muffle sound and absorb vibration noise.
IAQ equipment supported: When coupled with a condensing unit and humidity-capable thermostat, mainline Heil furnaces can control relative humidity during cooling operation. These furnaces have a dehumidification function in cooling mode and can control a humidifier accessory in heating mode.
Thermostat compatibility: Compatible with most thermostats. Communicating and self-configuring functions available only when used with the new Heil Ion system control or the Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Furnaces are built with stainless steel secondary heat exchangers. Two-stage heat and two-stage cooling compatible; electronically commutated (EC) variable-speed blower motor; designed for four-way multi-position installation; 35 inches tall and lighter weight than previous counterparts. Meets low NOx-emissions standards.
Warranty information: Ten-year No Hassle Replacement limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoHeil.com.
eProduct 198
![HVH8 QuietComfort Deluxe 18 variable-speed heat pump with SmartSense technology - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Heil-HVH8-QuietComfort-ACHR-News.jpg)
Serviceability features: When installed as part of a complete communicating system including the Ion system control with Wi-Fi capability or the Observer communicating control, the heat pump offers precise system control with remote access, text-based diagnostics, and contractor information displayed. Easy-access service valves.
Noise-reduction features: Variable-speed compressor and compact electronically commutated (EC) fan motor operate at quiet, low speeds most of the time (as low as 56 decibels). Soft start and smooth ramp-up to operating speeds. Cabinet includes isolation compressor grommets and a high-performance compressor sound shield for lower noise, better airflow, and higher efficiency.
IAQ equipment supported: As part of an installed system, compatible with Heil IAQ system components: humidifiers, ventilators, and UV lamps.
Thermostat compatibility: Compatible with most thermostats. Five-stage operation, communicating and self-configuring functions only available when used with new Heil Ion system control or Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: When installed as part of a complete communicating system including the Ion system control with Wi-Fi capability or the Observer communicating control, the heat pump provides five-stage variable-speed technology in a compact design. Efficiencies up to 11 HSPF/19 SEER.
Warranty information: Ten-year limited warranty on parts, including compressor and coils, to original homeowner upon timely registration. Limited warranty period is five years for parts if not registered within 90 days of installation. Product qualifies for the 10-year No Hassle Replacement limited warranty. (If the compressor or covered coil fails within 10 years of installation date, then ICP will provide a one-time replacement outdoor unit at no charge.) Some restrictions apply. See warranty certificate for details.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoHeil.com.
eProduct 199
![HSH1BE heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Intertherm-HSH1BE-heat-pump-ACHR-News.jpg)
Serviceability features: The new corner post and panel design allows each side panel to be removed individually with two screws. This reduces the time it takes to access the coil and increases the number of annual service calls as well as repairs made per day.
Noise-reduction features: With the corner post and panel design, each component has increased forming, which leads to stronger panels. These tooled components create a tight fit, which reduces the noise created from any rattling. All HSH heat pumps also have a lofted top pan with a premium circular grille to reduce vibration.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: The corner post and panel design was developed with simple installation and reduced service time in mind. The redesigned drain pan has an increased quantity of drainage holes for the defrost cycle, as well as molded spacers to properly position the coil.
Warranty information: One-year limited parts warranty and five-year limited compressor warranty. If the system is registered within 60 days of installation, coverage is extended to 10 years limited parts.
Special installation requirements: Because this is a manufactured housing specific heat pump, the unit is charged to accommodate 20 feet of line set. This is the minimum length required in the manufactured housing industry but different from the residential standard.
Contact: Nortek Global HVAC, 800-422-4328; www.nortekhvac.com.
eProduct 200
![G9MAE ProComfort Deluxe 98 furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/KeepRite-G9MAE-ProComfort-ACHR-News.jpg)
Serviceability features: When connected to an Ion system control or Observer communicating control, system information is displayed on a touchscreen. The system self-configures for optimal performance. Features large, one-quarter-turn knobs for easy door installation/removal. The LED makes diagnostic flash codes easy to read. Blower assembly is mounted on rails for easy, upfront installation/removal.
Noise-reduction features: Variable-speed electronically commutated (EC) blower motor reduces operating sound levels. Special blower mount quiets vibration and cuts sound. Insulated steel cabinet absorbs sound from heat exchanger and blower compartments.
IAQ equipment supported: When coupled with a condensing unit and humidity-capable thermostat, mainline KeepRite furnaces can control relative humidity during cooling operation. These furnaces have a dehumidification function in cooling mode and can control a humidifier accessory in heating mode.
Thermostat compatibility: Compatible with most thermostats. Communicating and self-configuring functions only available when used with the KeepRite Ion system control or Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Furnaces are built with stainless steel secondary heat exchangers. Modulating (multi-stage) gas valves allow furnaces to operate on a quieter low-heat setting unless the thermostat calls for more heat. Designed for four-way multi-position installation, 35 inches tall, and lighter weight than previous counterparts.
Warranty information: Ten-year No Hassle Replacement limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoKeepRite.com.
eProduct 201
![PGR5 packaged gas/electric unit - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/KeepRite-PGR5-ACHR-News.jpg)
Serviceability features: Installs easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll compressor, which operates most of the time in the quieter lower stage. Also includes a two-stage heating system that offers similar comfort benefits in the heating mode. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Dehumidification mode (airflow reduction) standard on all models. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units feature two-stage heating and cooling operation, stainless steel tubular heat exchangers, field convertible airflow, and high-efficiency electronically commutated (EC) indoor blower motors. With cooling efficiencies up to 16 SEER and 12.5 EER, these packaged units are Energy Star qualified.
Warranty information: Five-year No Hassle Replacement limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoKeepRite.com.
eProduct 202
![Dave Lennox Signature Collection SLP98V variable-capacity gas furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Lennox-SLP98V-Furnace-ACHR-News.jpg)
Serviceability features: Serviceable parts are very accessible and readily available for when dealers need them. The onboard diagnostics assist service professionals in troubleshooting should a failure occur during service. Comes with a limited life warranty on the heat exchanger and a 10-year warranty on all remaining covered components.
Noise-reduction features: SilentComfort® technology combines heavy cabinet insulation, quieter burners, and no loud blasts of air during startup to preserve the peace and quiet in a home.
IAQ equipment supported: Supports a humidifier and high-efficiency filters and has a height of 33 inches, which allows the unit to support various IAQ solutions. Supports Lennox’s PureAir® products, including the latest introduction — PureAir S whole home air purification system.
Thermostat compatibility: For precision comfort and seamless service, the furnace is best paired with one of the Lennox family of communicating thermostats, which includes the iComfort S30 or iComfort M30.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Lennox’s Precise Comfort® technology keeps the temperature within .5°F of the homeowner’s ideal temperature. Heat is distributed evenly throughout the home, helping to eliminate cold spots.
Warranty information: Limited lifetime warranty for the heat exchanger and a 10-year limited warranty on all remaining covered components.
Special installation requirements: None.
Contact: Lennox Industries, 972-497-5000; www.lennox.com/residential.
eProduct 203
![Dave Lennox Signature Collection SL297NV variable-speed, ultra-low emissions, gas furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Lennox-SL297NV-Furnace-ACHR-News.jpg)
Serviceability features: Serviceable parts are very accessible and readily available for when a dealer needs them. Onboard diagnostics assist service professionals in troubleshooting should a failure occur.
Noise-reduction features: Special sound-absorbing insulation further reduces sounds for quiet operation.
IAQ equipment supported: Supports a humidifier and high-efficiency filters and has a height of 33 inches, which allows the unit to support various IAQ solutions. Compatible with Lennox’s PureAir products, including the latest introduction of the PureAir S whole home air purification system, which features purification efficiency of MERV 16.
Thermostat compatibility: Compatible with most thermostats; however, for enhanced performance and service, the furnace is best paired with one of the Lennox family of communicating thermostats, including the iComfort S30 or iComfort M30.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This furnace provides reliable comfort while producing low NOx emissions. The variable-speed motor maintains a consistent temperature in a home, using as little fuel as possible. This helps homeowners stay comfortable and reduces their utility costs.
Warranty information: Limited lifetime warranty on the heat exchanger and five-year limited warranty on covered components with product registration.
Special installation requirements: None.
Contact: Lennox Industries, 972-497-5000; www.lennox.com/residential.
eProduct 204
![Art Cool Premier wall-mount split system, LANO9OHYV1 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/LG-Art-Cool-Premier-LANO9OHYV1-ACHR-News.jpg)
Serviceability features: Easy access, removable filter, service and installation support clip, detachable bottom panel for convenient access, and built-in Wi-Fi standard for service and diagnostics through smart device app.
Noise-reduction features: Twin rotary compressor reduces vibration and noise transmission. Sleep mode permits lower airflow and sound output.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Built-in Wi-Fi and SmartThinQ™ connectivity, enabling easy control. Monitor the indoor unit’s full array of functions via a smartphone or using Amazon Echo or Google Assistant.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: This unit earned Energy Star’s Most Efficient 2018 designation. The system also features Reliable to Extreme Degrees (RED) heating technology.
Warranty information: Standard limited liability warranty: 10-year parts and 10-year compressor warranty on qualified systems. LG Excellence Contractors are eligible for an additional two-year parts and two-year compressor warranty for qualifying residential/light commercial systems, extending the standard limited liability warranty to 12 years for the parts and compressor. For complete warranty details, visit lg-dfs.com/warranty.aspx.
Special installation requirements: Manufacturer did not specify.
Contact: LG Electronics Inc., 212-880-5266; www.lghvac.com.
eProduct 205
![Multi F MAX with LGRED heat pump (outdoor unit), LMU420HHV - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/LG-Multi-F-MAX-LMU420HHV-ACHR-News.jpg)
Serviceability features: With both ducted and duct-free indoor unit options available, contractors and builders have the freedom to create the solution that is best suited for their customers’ needs and the space. In using refrigerant piping rather than ductwork, installation is not only simplified, but contractors are afforded the flexibility to install the system around architectural features while being minimally invasive to the space.
Noise-reduction features: LG’s proprietary inverter technology offers quiet operation that reduces noise pollution in and around one’s home.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Heating capabilities of 100 percent at 5°F and continuous operation down to minus 13°F, providing enough flexibility and customization to ensure comfort regardless of season or location. With many Wi-Fi compatible indoor units available, homeowners can control their system from anywhere using the LG SmartThinQ app alongside their other LG Wi-Fi enabled products. Energy efficient, quiet, and Energy Star certified.
Warranty information: Standard limited liability warranty: 10-year parts and 10-year compressor warranty on qualified systems. LG Excellence Contractors are eligible for an additional two-year parts and two-year compressor warranty for qualifying residential/light commercial systems, extending their standard limited liability warranty to 12 years for the parts and compressor. For complete warranty details, visit lg-dfs.com/warranty.aspx.
Special installation requirements: None.
Contact: LG Electronics Inc., 212-880-5266; lghvac.com.
eProduct 206
![KNIGHT fire-tube boiler - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Lochinvar-Knight-Boiler-ACHR-News.jpg)
Serviceability features: Easy to install, service, and maintain.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Designed, engineered, and assembled in the U.S., this boiler includes 13 models: seven wall-mount options and six floor-standing models. Models range from 55,000 to 399,000 Btuh. Turndown ratios of 10:1 and 95 percent AFUE. Corrosion-resistant steel fire-tube heat exchanger. Negative regulation combustion system. Variable-speed electronically commutated motor (ECM) circulator. CON·X·US remote connectivity. LOCH-N-LINK® USB programming. Boilers can be cascaded together for redundancy.
Warranty information: For 15 years, Lochinvar warrants the heat exchanger on this product against defects in materials or workmanship, and failure due to thermal shock as described in this document, if installed within the U.S. or Canada, and provided the product remains at its original place of installation. Parts are under warranty for five years.
Special installation requirements: LOCH-N-LINK USB programming with parameters uploaded from USB drive. Universal vent adapter allows for easy transition to multiple types of vent material. Electronically commutated (EC) variable-speed pump increases system efficiency and reduces operational costs. Dual location parameter memory for quick component replacement. Electrical outlet for a work light or condensate pump. Wall- and floor-mount options with top and bottom water connections.
Contact: Lochinvar, 615-889-8900; www.lochinvar.com.
eProduct 207
![Acclimate Series HL20 variable-capacity heat pump, HL024-060 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Luxaire-Acclimate-HL20-ACHR-News.jpg)
Serviceability features: Simplified servicing with Charge Smart™. A touchscreen provides readout of system condition as well as head pressure and suction pressure while calculating superheat and subcooling. A swing-open electrical box provides corner access to unit interior. The Wi-Fi Hx3 thermostat supports a service app for remote service and monitoring.
Noise-reduction features: As low as 54 dBA in heating and cooling modes.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16 provide a superior level of indoor air quality.
Thermostat compatibility: Requires a special thermostat. Designed to operate with the Wi-Fi-enabled communicating Hx3 thermostat with consumer and contractor remote access app.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Variable-capacity, inverter-controlled, scroll compressor adjusts system capacity from 35 to 100 percent to meet comfort demands. Integration with Luxaire Acclimate Hx3 thermostat provides access and control for maximum comfort and minimum power consumption. Charge Smart provides simplified set-up, charging, and evaluation. Refrigerant gauges aren’t needed to evaluate the system during maintenance.
Warranty information: One-year labor limited warranty, lifetime compressor limited warranty, and 10-year parts limited warranty on registered units. Extended warranties available to purchase.
Special installation requirements: Charge Smart has a touchscreen providing charge monitoring with readout of system pressures and suction and liquid line temperatures while calculating superheat and subcooling. Climate Sync™ technology simplifies setup with preconfigured profiles, part of a matched communicating system using Luxaire AVV air handlers and CM coils with factory-mounted electronic expansion valves (EEVs).
Contact: Luxaire, 405-419-6545; www.luxaire.com/acclimate.
eProduct 208
![Acclimate LP9C Series modulating gas furnace, LP9C060-120 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Luxaire-Acclimate-LP9C-ACHR-News.jpg)
Serviceability features: Rotatable inducer for venting out top or side. Every unit is one- or two-pipe vent compatible. Built-in condensate trap, removed from the blower compartment simplifies installation. Tool-less entry with quarter-turn knobs. Flexible installation will work with conventional thermostats or the Hx3 Wi-Fi communicating thermostat when a limited number of thermostat wires are available.
Noise-reduction features: Fully insulated cabinet enhances thermal and acoustic performance. Dynamically balanced blower and motor assembly minimize sound. Variable-speed inducers and blowers maximize performance while minimizing sound.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16 provide a superior level of indoor air quality.
Thermostat compatibility: Compatible with most conventional single-stage thermostats. Added features and functions are available by using the Hx3 Wi-Fi four-wire communicating thermostat that, with the proper app, supports remote access for the consumer and contractor for both monitoring and control.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Modulating heating operation can range from 35 to 100 percent capacity to meet comfort needs precisely while saving energy. Integration with Luxaire Acclimate Hx3 thermostat provides unprecedented consumer and contractor control for maximum comfort and minimum power consumption.
Warranty information: Lifetime heat exchanger limited warranty, 10-year parts limited warranty, and 10-year Complete Assurance limited warranty pledge: If the heat exchanger fails within 10 years of installation, manufacturer provides optional furnace replacement in lieu of heat exchanger replacement. To take advantage of this offer, customers must register online within 90 days.
Special installation requirements: Multi-position, one unit for all installed positions — simply rotate the inducer to the desired venting position, whether out the top or side. Integral condensate trap — just connect the drain. Compatible with the various approved venting material. Approved for one- and two-pipe installations. Wide range of accessories include propane conversion kit, IAQ, and vent termination accessories.
Contact: Luxaire, 405-419-6545; http://bit.ly/LuxaireLP9C.
eProduct 209
![PPG3HE convertible packaged gas/electric unit - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Maytag-PPG3HE-ACHR-News.jpg)
Serviceability features: All components at unit perimeter near panelized compartment for temperature, voltage, and amperage readings. Refrigerant pressure readings without removing panels. On-board, three-position LED diagnostics (on, off, or flashing) simplifies and narrows blower and furnace troubleshooting. Duct covers for both airflow configurations reduces installation time and cost. Condensate removal through roof or through vent pipe and then below frost line. Single-pass, all-aluminum coils make cleaning easier
Noise-reduction features: Swept-wing fan blade combined with highly engineered and custom venturi discharge opening minimize vibration and reduce noise. Copeland Scroll’s superior compression movement is favorable to reciprocating compressors. Fully insulated return section minimizes indoor noise caused by blower operation. The 16-speed variable-speed blower with balance wheel and optimized housing ensures quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats. Two-stage heat/single-stage cooling thermostat is the most efficient; furnace board does have high fire timer if needed.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Currently the only residential condensing gas packaged unit on the market. All-aluminum, single-pass coils used on the condenser and the evaporator sections reduce unit and refrigerant weight, as well as optimize heat transfer and maintenance. Unique thaw cycle ensures that gas heat is available even in harsh climates. SmartLite feature of the integrated furnace control (IFC) learns specific light-off characteristics of each unique application and adjusts igniter timing to extend igniter life.
Warranty information: Five-year limited parts warranty and one-year Dependability Promise to replace the unit if the compressor or heat exchanger fails within the first year. If the product is registered within 60 days of purchase, the coverage increases to a 12-year limited parts warranty and a 12-year Dependability Promise. Extended warranties are available through the Contractors’ Preferred Protection Plan.
Special installation requirements: The condensate removal is much like a normal condensing furnace. The collector box has a valve that is utilized for roof mount units — condensate must be brought to a conditioned space, trapped, and disposed of properly. In a ground-mount situation, condensate will track through the vent piping and down a drain 6 to 8 inches below the frost line.
Contact: Nortek Global HVAC, 800-422-4328; nortekhvac.com.
eProduct 210
![PPdivSF convertible packaged heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Maytag-PPH3SF-ACHR-News.jpg)
Serviceability features: All components at unit perimeter near panelized compartment for temperature, voltage, and amperage readings. Refrigerant pressure readings without removing panels. On board, three-position LED diagnostics (on, off, or flashing) narrows blower troubleshooting. Seven-segment defrost board troubleshooting display with forced defrost feature enhances defrost troubleshooting. Simple on/off dipswitch settings for 16-speed blower.
Noise-reduction features: Fully insulated return compartment. Precisely matched fan blade and motor technology combined with highly engineered custom venturi fan orifice reduces unwanted vibration and noise. Two-stage compressor lessens noise in mild climates when running on first stage. The 16-speed blower motor offers one of the widest ranges to lessen the noise impact caused by excessive blower speed.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Single-pass, all-aluminum coil technology used on both condenser and evaporator coils, which reduces refrigerant charge and weight while providing maximum protection, heat transfer, and cleanability. Proven, patented, and innovative hot gas defrost system ensures complete defrost cycle and provides a wide range of seven-segment status codes. The 16-speed blower motor offers a wide range of capacities that can overcome some challenging static and noise situations
Warranty information: Five-year limited parts warranty and one-year Dependability Promise to replace the unit if the compressor fails within the first year. If the product is registered within 60 days of purchase, the coverage increases to a 12-year limited parts warranty and a 12-year Dependability Promise. Extended warranties are available through the Contractors’ Preferred Protection Plan.
Special installation requirements: There are high wind accessory kits for roof or ground mount that meet Florida’s codes.
Contact: Nortek Global HVAC, 800-422-4328; nortekhvac.com.
eProduct 211
![HSH1BE heat pump - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Miller-HSH1BE-heat-pump-ACHR-News.jpg)
Serviceability features: The new corner post and panel design allows each side panel to be removed individually with two screws. This reduces the time it takes to access the coil and increases the number of annual service calls as well as repairs made per day.
Noise-reduction features: With the corner post and panel design, each component has increased forming, which leads to stronger panels. These tooled components create a tight fit, which reduces the noise created from any rattling. All HSH heat pumps have a lofted top pan with a premium circular grille to reduce vibration.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: The corner post and panel design was developed with simple installation and reduced service time in mind. The redesigned drain pan has an increased quantity of drainage holes for the defrost cycle, as well as molded spacers to properly position the coil. These units are manufactured housing specific, so the charge is set for 20 feet of line set instead of the residential standard of 15 feet.
Warranty information: Includes a one-year limited parts warranty and a five-year limited compressor warranty. If the system is registered within 60 days of installation, coverage is extended to 10-year limited parts.
Special installation requirements: Because this is a manufactured housing-specific heat pump, the unit is charged to accommodate 20 feet of line set. This is the minimum length required in the manufactured housing industry but different from the residential standard.
Contact: Nortek Global HVAC, 800-422-4328; nortekhvac.com.
eProduct 212
![MLZ one-way ceiling cassette - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Mitsubishi-MLZ-Cassette-ACHR-News.jpg)
Serviceability features: Designed to fit between existing ceiling joists and can be serviced from below without an access panel. This eliminates the need for contractors to modify the surrounding area for servicing, simplifying both installation and maintenance.
Noise-reduction features: The electric DC motor provides quiet operation down to 26 dBA.
IAQ equipment supported: A built-in filtration system improves IAQ when operating. An additional anti-allergy enzyme feature is also available, which helps trap allergens such as mold, bacteria, and other irritants.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Beyond the ability to service from below, the unique design provides effective conditioning and optimal adjustable airflow regardless of ceiling height. Auto vane control allows the MLZ to adjust air direction based on the homeowner’s comfort needs. The cassette installs easily between standard 16-inch joists. A built-in, 19-inch condensate lift mechanism provides homeowners with additional installation savings.
Warranty information: Five-year parts warranty to the original owner of the system. If the system is installed in a residential single-family home and registered within 90 days of installation, the parts will be warrantied for 10 years. If the system (indoor and outdoor unit) is installed by a Mitsubishi Electric Diamond Contractor, the parts and compressor will be warrantied for 12 years.
Special installation requirements: Follow standard installation practices for Mitsubishi Electric Trane HVAC US equipment.
Contact: Mitsubishi Electric Trane HVAC US, 703-797-7107; www.mehvac.com.
eProduct 213
![Multi-position air handler (PVA), PVA-AXXAA7 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Mitsubishi-PVA-ACHR-News.jpg)
Serviceability features: Servicing the air handler is both easy and convenient. The cabinet features embossed labels with separate slide-out drawers for the electrical, evaporator coil, blower, and filter components. The unique blow-through design also provides easy access to the evaporator coil for streamlined cleaning and service. All screws are the same size for simplicity.
Noise-reduction features: Positively pressurized, solid-state cabinet construction, full 1-inch R4.2 rated insulation, and a highly-efficient electronically commutated (EC) motor. The combination minimizes vibration and ensures quiet operation, as low as 24 dBA, across three different fan speeds. In addition, the PVA’s design creates a near airtight barrier, allowing for minimal air leakage. The result is whisper-quiet operation.
IAQ equipment supported: Supports energy recovery ventilators (ERVs) and humidifiers/dehumidifiers. The high-static capabilities provide the ability to utilize highly efficient filtration replacing the standard filter.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Ideal for replacing a furnace, the PVA can be fully disassembled and reassembled to fit through small spaces, such as attic doors and crawl spaces, making installation easier for the contractor. Additionally, the PVA’s high static capabilities (field adjustable) and ability to be installed in horizontal, vertical, and downflow configurations allow for existing ductwork to be utilized.
Warranty information: In residential applications, when installed and registered by a Mitsubishi Electric Diamond Contractor, 12-year parts limited warranty.
Special installation requirements: Designed to be paired with a high-performance inverter-driven heat pump outdoor unit.
Contact: Mitsubishi Electric Trane HVAC US, 703-797-7107; www.mehvac.com.
eProduct 214
![Ultimate 9700 Series furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Napoleon-9700-Furnace-ACHR-News.jpg)
Serviceability features: Self-diagnostic integrated furnace controls with easy blower removal and built-in LED lighting in upper and lower compartments. Factory-installed UV Light Air purifier and smart thermostat ready.
Noise-reduction features: Durable powder coated, acoustically, and thermally insulated cabinet. Sealed vestibule and blower compartments for quiet operation.
IAQ equipment supported: Factory-installed UV Light Air purifier.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Stainless steel cabinet cover makes this a stylish furnace. The Vortex turbulator inside the heat exchanger increases efficiency by disrupting the natural airflow, extracting the maximum heat from flue gases.
Warranty information: Fifteen-year unit replacement heat exchanger limited warranty, lifetime heat exchanger limited warranty, 10-year parts limited warranty.
Special installation requirements: Please refer to the manual for installation requirements. Furnace is certified for upflow installation only.
Contact: Napoleon Products, 705-721-1212; www.napoleonheatingandcooling.com.
eProduct 215
![NRCB199 combi boiler - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Noritz-NRCB199-boiler-ACHR-News.jpg)
Serviceability features: Each part of the boiler is assembled as an individual component, simplifying servicing and replacement for technicians. At less than 100 pounds, it is lighter than a traditional boiler, allowing it to save up to 80 percent in space. The mounting bracket lines up with the top of the unit, allowing installers to more easily position the boiler on the wall.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Simultaneous domestic water and space heating. Built-in auxiliary pump connections. Dual 316L austenite stainless steel heat exchangers. Built-in outdoor reset control. Wi-Fi capable. Ultra-low-NOx Eco-Burner (nitrogen-oxide emissions level of only 14 ppm). Recirculation capability. Venting versatility (polypropylene, PVC, CPVC).
Warranty information: Ten-year warranty on heat exchangers, five-year warranty on other parts, and one-year warranty on reasonable labor.
Special installation requirements: The NRCB accommodates 2- or 3-inch PVC/CPVC or polypropylene vent pipe and is ½-inch gas line compatible. Includes an integrated pump for primary loop pumping.
Contact: Noritz, 866-766-7489; www.noritz.com.
eProduct 217
![Series PBC combi boiler - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Peerless-Series-PBC-ACHR-News.jpg)
Serviceability features: Easy-to-follow control menu for set-up and service. Spacious vestibule. Control panel pivots for easy-to-access components.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Combination heating and domestic hot water boiler. Direct vent uses 2- or 3-inch vent piping. Low NOx-, low CO2-emissions. Up to 5.2 gpm of domestic hot water.
Warranty information: Twelve-year residential limited warranty on heat exchanger. One-year parts and labor warranty coverage starting on day 91 if boiler is fully registered via online registration.
Special installation requirements: Manufacturer did not specify.
Contact: PB Heat LLC, 610-845-6213; www.PeerlessBoilers.com.
eProduct 218
![Classic Series, ultra-low NOx, upflow/horizontal, gas furnace, R801T - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Rheem-R801T-ACHR-News.jpg)
Serviceability features: Opening the furnace with quarter-turn door knobs for tool-less access is simple. The furnace is designed with PlusOne® Diagnostics, seven-segment, LED display on all units to make it easy to service and diagnose. The heat exchanger is also removable for improved serviceability.
Noise-reduction features: One of the quietest furnaces on the market. The new patented heat exchanger design provides improved airflow, which reduces the operating sound. The sealed burner, solid doors, and an insulated blower compartment provide quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This certified unit meets the ultra-low NOx emission standard and attains even less than 14ng/J NOx emissions.
Warranty information: Ten-year conditional parts warranty and 20-year heat exchanger warranty.
Special installation requirements: All R801T products maintain standard furnace cabinetry sizes for easy replacement of existing equipment and upgrades. For installation requirements, please refer to the manufacturer’s installation manual. For technical support, contractors can access MyRheem.com 24/7 or use the QR codes on the furnace to access product information from a smartphone or tablet.
Contact: Rheem Mfg. Co., 770-351-3018; www.Rheem.com.
eProduct 219
![Prestige Series, EcoNet<sup>®</sup>-enabled, variable-speed heat pump, RP20*B - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Rheem-Prestige-RP20-ACHR-News.jpg)
Serviceability features: Contractor-friendly design includes expanded valve space and triple service access, which makes install and repairs fast and easy. Corner service access allows optimal access to internal components while individual louver panels speed coil cleaning and cabinet reassembly. This next-generation heat pump harnesses the power of the new EcoNet smart thermostat, which provides control, monitoring, and one-touch contractor alert capability.
Noise-reduction features: Designed for durability, this unit features a smart composite base pan, which adds to quieter performance. Enhanced mufflers, improved refrigerant tubing, curved louver panels, and rugged corner post design all contribute to quiet, reliable operation. By running at lower speeds throughout the day, these variable-speed heat pump units streamline airflow and reduce vibration.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Exclusive Charge Mode simplifies charging during installation, while the unit’s refrigeration charge management ensures system balances in heating and cooling modes. Utilizing advanced sensor technology, the EcoNet smart thermostat monitors high-side pressure and temperature control, while onboard filter and coil monitoring and diagnostic tools deliver real-time alerts and system notifications.
Warranty information: Ten-year conditional unit replacement with registration.
Special installation requirements: The new EcoNet smart thermostat serves as the hub of communication for a home’s heating, cooling, and water heating systems and is required to operate the Prestige Series heat pump in a fully communicating mode.
Contact: Rheem Mfg. Co., 770-351-3000; www.Rheem.com.
eProduct 220
![Achiever Series, ultra-low NOx, upflow/horizontal gas furnace, R801T - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Ruud-Ultra-Low-Furnace-ACHR-News.jpg)
Serviceability features: Opening the furnace with quarter-turn door knobs for toolless access is simple. The furnace is designed with the PlusOne Diagnostics, seven-segment LED display on all units to make it easy to service and diagnose. The heat exchanger is also removable for improved serviceability.
Noise-reduction features: The new patented heat exchanger design provides improved airflow, which reduces the operating sound. The sealed burner, solid doors, and an insulated blower compartment provide quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This certified unit meets the ultra-low NOx emission standard and attains even less than 14ng/J NOx emissions.
Warranty information: Ten-year conditional parts warranty and 20-year heat exchanger warranty.
Special installation requirements: All R801T products continue to maintain standard furnace cabinetry sizes for easy replacement of existing equipment and upgrades. For installation requirements, please refer to the manufacturer’s installation manual. For technical support, contractors can access MyRuud.com 24/7 or use the QR codes on the furnace to access product information from a smartphone or tablet.
Contact: Rheem Mfg. Co., 770-351-3018; www.RUUD.com.
eProduct 221
![Ultra Series EcoNet-enabled, variable-speed heat pump, UP20*B - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Ruud-Ultra-Series-EcoNet-Heat-Pump-ACHR-News.jpg)
Serviceability features: Contractor-friendly design includes expanded valve space and triple service access, which makes install and repairs fast and easy. Corner service access allows optimal access to internal components, while individual louver panels speed coil cleaning and cabinet reassembly. This next-generation heat pump harnesses the power of the new EcoNet smart thermostat, which provides control, monitoring, and one-touch contractor alert capability.
Noise-reduction features: Designed for durability, this unit features a smart composite base pan, which adds to quieter performance. Enhanced mufflers, improved refrigerant tubing, curved louver panels, and rugged corner post design all contribute to quiet, reliable operation. By running at lower speeds throughout the day, these variable-speed heat pump units streamline airflow and reduce vibration.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Exclusive Charge Mode simplifies charging during installation, while the unit’s refrigeration charge management ensures system balances in heating and cooling modes. Utilizing advanced sensor technology, the EcoNet smart thermostat monitors high-side pressure and temperature control. Onboard filter and coil monitoring and diagnostic tools deliver real-time alerts and system notifications via the EcoNet Smart Home system.
Warranty information: Ten-year conditional unit replacement with registration.
Special installation requirements: The new EcoNet smart thermostat serves as the hub of communication for a home’s heating, cooling and water heating systems and is required to operate the Ultra Series heat pump in a fully communicating mode.
Contact: Rheem Manufacturing Company, 770-351-3000; www.Ruud.com.
eProduct 222
![F9MVE Deluxe 96 furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Tempstar-F9MVE-Furnace-ACHR-News.jpg)
Serviceability features: The LED makes diagnostic flash codes easy to read. Allows technicians to see last seven stored fault codes even if power is interrupted. Blower assembly is mounted on rails for easy upfront installation and removal. Large, robust one-quarter-turn knobs allow for easy door installation and removal.
Noise-reduction features: Variable-speed, electronically commutated motors (ECMs) minimize operating sound levels. The blower motor is attached with soft-mount rubber grommets that absorb sound and vibration. Insulated heat exchanger and blower compartments muffle sound and absorb vibration noise.
IAQ equipment supported: When coupled with a condensing unit and humidity-capable thermostat, mainline Tempstar furnaces can control relative humidity during cooling operation. These furnaces have a dehumidification function in cooling mode and can control a humidifier accessory in heating mode.
Thermostat compatibility: Compatible with most thermostats. Communicating and self-configuring functions available only when used with the new Tempstar Ion system control or the Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Furnaces are built with stainless steel secondary heat exchangers. Two-stage heat and two-stage cooling compatible. Electronically commutated (EC) variable-speed blower motor. Designed for four-way multi-position installation — 35 inches tall and lighter weight than previous counterparts. Meets low NOx emissions standards.
Warranty information: Ten-year No Hassle Replacement limited warranty. Lifetime heat exchanger and 10-year parts limited warranty to original purchaser with timely registration. Parts limited warranty period is 20-year heat exchanger and five-year parts if not registered within 90 days of installation (see warranty certificate for details and restrictions).
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoTempstar.com.
eProduct 223
![TVH8 Deluxe 18 variable-speed heat pump with SmartSense technology - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Tempstar-TVH8-ACHR-News.jpg)
Serviceability features: When installed as part of a complete communicating system, including the Ion system control with Wi-Fi capability or the Observer communicating control, this heat pump offers precise system control with remote access, text-based diagnostics, and contractor information displayed. Easy-access service valves.
Noise-reduction features: Variable-speed compressor and compact electronically commutated (EC) fan motor operate at quiet, low speeds most of the time (as low as 56 decibels). Soft start and smooth ramp-up to operating speeds. Cabinet includes isolation compressor grommets and a high-performance compressor sound shield for low noise, optimal airflow, and high efficiency.
IAQ equipment supported: As part of an installed system, compatible with Tempstar IAQ system components: humidifiers, ventilators, and UV lamps.
Thermostat compatibility: Compatible with most thermostats. Five-stage operation, communicating and self-configuring functions only available when used with new Tempstar Ion system control or Observer communicating control (thermostat).
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: When installed as part of a complete communicating system including the Ion system control with Wi-Fi capability or the Observer communicating control, the heat pump provides five-stage variable-speed technology in a compact design. Efficiencies up to 11 HSPF/19 SEER.
Warranty information: Ten-year limited warranty on parts, including compressor and coils, to original homeowner upon timely registration. Limited warranty period is five years for parts if not registered within 90 days of installation. Product qualifies for the Tempstar 10-year No Hassle Replacement limited warranty. (If the compressor or covered coil fails within ten years of installation date, then ICP will provide a one-time replacement outdoor unit at no charge.) Some restrictions apply. See warranty certificate for details.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoTempstar.com.
eProduct 224
![S9V2-VS S-Series furnace - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Trane-S9V2-VS-S-Series-ACHR-News.jpg)
Serviceability features: Self-diagnostic features will display specific error codes on the furnace control, ensuring that technicians are able to solve customer issues quickly. The door of the furnace also has a large 4- by 5-inch viewing window so that homeowners can easily view the error codes and remotely relay this information back to their servicing technician safely, without needing to remove the panel to get inside the equipment.
Noise-reduction features: Sound insulation is included inside the blower compartment. The furnace also has a variable-speed inducer motor with a learning algorithm that will learn at which RPM the motor should run to ensure maximum performance at the lowest possible sound level.
IAQ equipment supported: Furnaces work well with humidifiers, fresh air ventilators, and high-efficiency air filters. The Trane CleanEffects whole home air filter removes dust, allergens, and even viruses like influenza from the indoor air. CleanEffects has been recognized by the Asthma and Allergy Foundation of America as being a certified asthma and allergy friendly product and has met rigid test standards to be included in the Clean Air Certification Program™.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The furnace achieves 97 percent AFUE, has a fully variable-speed blower, variable-speed inducer, and a very user-friendly menu and option-driven control board. It is compatible with the Trane TruComfort™ variable-speed outdoor systems, which provide up to 750 cooling speeds for comfort and efficiency.
Warranty information: Lifetime heat exchanger and 10-year parts registered warranty.
Special installation requirements: This furnace comes ready to install. No special conversion kits are required to convert the furnace to any of the alternate poise positions. Converting the furnace to right-side gas entry from the default left-side gas entry is a simple process, because a specially designed conversion tube is installed on every furnace.
Contact: Ingersoll Rand, 903-245-7953; www.trane.com/residential.
eProduct 225
![XV19 low-profile, variable-speed heat pump, 4TWL9 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Trane-XV19-ACHR-News.jpg)
Serviceability features: Single-panel access to all components. The back-lit integrated diagnostic display with Bluetooth technology will — in the very near future — allow technicians to view all information via their cellphones. Built-in compressor and inverter drive diagnostics take the guesswork out of troubleshooting. Charging and pump-down modes are available for ease of install and service. The Nexia dealer diagnostic portal provides dealers remote access to system fault codes and alerts.
Noise-reduction features: With a maximum operating sound level of 57 dBA, this is the quietest ducted split heat pump Trane has to offer. The use of larger compressor capacities and fan sizes allows the system to operate at slower and quieter speeds. Perfect for use where low sound levels are required by local code or where ultra-quiet outdoor unit operation is desired. Zero lot line, hotels, condos, and outdoor living spaces are a few examples.
IAQ equipment supported: Compatible with the Trane CleanEffects whole house air cleaner, FreshEffects energy recovery ventilator, and EnviroWise inline ventilators. The ComfortLink-II communicating controls provide technicians and homeowners simple control and service reminders for installed accessories. Hyperion communicating air handlers also have optional integrated UV light accessories that only operate during cooling mode, which lengthens the life of the UV bulbs and reduces energy savings and the cost of operation.
Thermostat compatibility: Requires the use of a Trane Comfortlink-II XL850 or XL1050 communicating control.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: TruComfort technology provides up to 700 speeds for precise control of indoor temperature and humidity. The draw-through design discharges air away from the home to minimize recirculation and the potential for staining of the home that can occur with blow-through designs. The use of a refrigerant-cooled inverter, electronic expansion valve, and demand defrost controls enhances long-term system reliability.
Warranty information: Limited warranty (registered): 10-year compressor, coil, and parts. Limited warranty (nonregistered): five-year compressor, coil, and parts. Extended warranty available.
Special installation requirements: Utilizes Comfortlink-II communicating controls and is compatible with ComfortLink-II Zoning and accessories. Requires a minimum of 6-inch clearance from the house on the coil side and 36-inch clearance from the fan outlet grille. A minimum of 2 inches is required and allowed when installed beneath a deck or overhang to allow access for removal of the top panel. Epoxy-coated coils can be special ordered for coastal applications.
Contact: Trane, 704-655-5076; www.trane.com.
eProduct 226
![Unico System vertical upflow air handler, 2430, 3036, 3642 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Unico-Air-Handler-ACHR-News.jpg)
Serviceability features: This one-piece unit has the blower and coil all in one, eliminating the need for space-eating mechanical areas. Installation is easy, simply requiring connection to ductwork and either refrigerant or water lines, depending on the application. The unit uses an electronically commutated (EC) motor and software, providing the ability to precisely manage airflow.
Noise-reduction features: Because the unit is designed to run inside closets, eliminating sound and vibration is an important aspect of the system. The entire surface of the interior is lined with 1-inch sound-deadening insulation, making sound levels fall to under 40 decibels.
IAQ equipment supported: Equipped with a blower and coil, the air handler provides all the benefits of the Unico System, including the ability to fit into small spaces, draft-free airflow, lower humidity, and even room temperatures.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The air handler is specifically designed for closet spaces or any upflow application, with flexible control-box mounting to the top, front, or either side of the unit. Available in three sizes, the unit will never be taller than 5 feet, allowing for easy fit and space for ductwork and fittings to come directly off of the unit and into the attic or ceiling space.
Warranty information: A 15-year warranty is available on installations completed by a Unico preferred contractor. For more information, visit https://tech.unicosystem.com/upc.
Special installation requirements: Manufacturer did not specify.
Contact: Unico Inc., 800-527-0896; www.unicosystem.com.
eProduct 227
![MAC-205 and MAH-165 boiler - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/Utica-MAC-205-Boiler-ACHR-News.jpg)
Serviceability features: Both boilers come with a free Labor Saver™ manifold to save time and increase productivity.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Boiler uses artificial intelligence (AI) control technology. The AI control self-commissions and continuously calibrates to ensure clean burning and optimum efficiency. It also measures water temperature, flue gas temperature, flame signal, and pressure that can impact the boiler operation and CO levels. It will automatically shut down operation should these values exceed normal operating levels, providing added protection to the consumer.
Warranty information: Ten-year limited heat exchanger warranty. These models also receive a free two-year parts and labor warranty when registered within 60 days from the date of installation.
Special installation requirements: Manufacturer did not specify.
Contact: Utica Boilers, 315-797-1310; www.uticaboilers.com.
eProduct 228
![Affinity Series YP9C modulating gas furnace, YP9C060-120 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/YORK-Affinity-YP9C060-120-Furnace-ACHR-News.jpg)
Serviceability features: Rotatable inducer for venting out top or side. Every unit is one- or two-pipe vent compatible. Built-in condensate trap, removed from the blower compartment, simplifies installation. Toolless entry with quarter-turn knobs. Flexible installation will work with conventional thermostats or the Hx3 Wi-Fi communicating thermostat when a limited number of thermostat wires are available.
Noise-reduction features: Fully insulated cabinet enhances thermal and acoustic performance. Dynamically balanced blower and motor assembly minimize sound. Variable-speed inducers and blowers maximize performance while minimizing sound.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16.
Thermostat compatibility: Compatible with most conventional single-stage thermostats. Added features and functions are available by using the Hx3 Wi-Fi four-wire communicating thermostat, which, with the proper app, supports remote access for the consumer and contractor for both monitoring and control.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Modulating heating operation can range from 35 to 100 percent capacity to meet comfort needs while saving energy. Integration with York Affinity Hx3 thermostat provides unprecedented consumer and contractor control for maximum comfort and minimum power consumption.
Warranty information: Lifetime heat exchanger limited warranty, 10-year parts limited warranty, and 10-year Complete Assurance limited warranty pledge: If the heat exchanger fails within 10 years of installation, manufacturer provides optional furnace replacement in lieu of heat exchanger replacement. To take advantage of this offer, customers must register online within 90 days.
Special installation requirements: Multi-position unit for all installed positions — simply rotate the inducer to the desired venting position, whether out the top or side. Integral condensate trap — just connect the drain. Compatible with the various approved venting material. Approved for one- and two-pipe installations. Wide range of accessories include propane conversion kit, IAQ, and vent termination accessories.
Contact: York, 405-419-6545; http://bit.ly/YorkUP9C.
eProduct 229
![Affinity Series YZV variable-capacity heat pump, YZV024-060 - The ACHR News](/ext/resources/2018/09-2018/09-10-2018/York-Affinity-YZV024-060-Heat-Pump-ACHR-News.jpg)
Serviceability features: Simplified servicing with Charge Assurance™. A touchscreen provides a readout of system condition as well as head pressure and suction pressure while calculating superheat and subcooling. A swing-open electrical box provides corner access to unit interior. The Wi-Fi Hx3 thermostat supports a service app for remote service and monitoring.
Noise-reduction features: Features QuietDrive™ system with attributes such as flat wire fan guard, swept-wing fan blade, sound-absorptive composite base pan, multi-density compressor cloak, and variable-capacity operation to reduce sound as low as 54 dBA.
IAQ equipment supported: Optional system-matched humidifiers, dehumidifiers, germ-killing UVC lighting, and high-efficiency filtration through MERV 16 provide a superior level of indoor air quality.
Thermostat compatibility: Requires a special thermostat. Designed to operate with the Wi-Fi enabled communicating Hx3 thermostat with consumer and contractor remote access app.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Variable-capacity inverter-controlled scroll compressor dynamically adjusts system capacity from 35 to 100 percent to meet comfort demands. Integration with York Affinity Hx3 Wi-Fi enabled communicating thermostat provides access and control for maximum comfort and minimum power consumption. Charge Assurance provides simplified setup, charging, and evaluation. Refrigerant gauges aren’t needed to evaluate the system during maintenance.
Warranty information: One-year labor limited warranty, lifetime compressor limited warranty, and 10-year parts limited warranty on registered units. Extended warranties available to purchase.
Special installation requirements: Climate Set™ technology simplifies setup with preconfigured profiles, part of a matched communicating system using York AVV air handlers and CM coils with factory-mounted electronic expansion valves (EEVs).
Contact: York, 405-419-6545; www.york.com/affinity.
eProduct 230
![Back button.](/ext/resources/Generic_Images/responsive-images/back-button-white.png)
