In addition to the product chart below, The NEWS spotlights the industry’s latest commercial heating products in the following photo feature. The manufacturers provided us with a brief description of features included with each product. For more information, please contact the manufacturers or their distributors.
Back to gallery
Serviceability features: Hinged service access doors to components that require maintenance. Ignition device automatically lights the burner. Modulating gas controller allows technicians to make configuration changes, view status, change set points, create forced modes, and perform diagnostics using a keypad next to an LCD display. Labeled terminal block with a color-coded wiring and wiring diagram. Factory-provided potentiometer dial for simple supply airflow adjustment. Direct-drive fans do not require belt maintenance.
Noise-reduction features: Double-wall, rigid, polyurethane, foam-injected panel construction reduces radiated fan sound. Supply and exhaust fans include vibration isolation. Standard direct-drive fans do not have belt noise. Electronically commutated motors (ECMs) for variable airflow control and reduced fan sound at lower speeds.
IAQ equipment supported: Energy recovery wheel and high-efficiency gas heater facilitate air handling units with 100 percent outside air capabilities, providing building occupants fresh air. In addition, the incoming air can be filtered using up to 4-inch MERV 14 filtration. Optional clogged-filter switch feature alerts when filters need to be replaced. Double-wall panel construction inhibits microbial growth. UV lights are available to inhibit microbial growth.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: High-efficiency (up to 96 percent) condensing furnace with modulating 3:1 turndown and two- or four-stage heat can be matched with high-efficiency direct expansion (DX) or chilled water cooling. Every unit has an ECM for variable airflow control and reduced fan sound at lower speeds. Units can be selected with factory-installed controls for single-zone variable air volume (VAV), VAV, constant air volume (CAV), or 100 percent outside air application.
Warranty information: Parts-only warranty for 12 months from the date of equipment startup or 18 months from the date of shipment, whichever is less. Standard extended warranty for the gas-fired heat exchanger is 10 years.
Special installation requirements: Designed to fit through 36-inch-wide by 80-inch-tall doors for ease of installation and retrofit applications; energy recovery units will ship in splits to maintain these dimensions if desired. Low-voltage quick connects make wiring between the sections as easy as plugging two parts together. Field-installed Category IV venting and condensate drain system required.
Contact: Aaon, 918-382-6337; www.aaon.com.
eProduct: 160
Serviceability features: Available in 3-, 4- and 5-ton sizes for application flexibility. 230 V operation. Easy access to service valves. Only two screws to access control panel. External high and low refrigerant service ports.
Noise-reduction features: Quiet operation (as low as 72 dBA). Units are equipped with Copeland Scroll™ compressors and isolation compressor grommets to minimize sound at maximum performance. Compressor sound blanket standard.
IAQ equipment supported: As part of an installed system, compatible with Arcoaire IAQ system components: humidifiers, ventilators, UV lamps, and air purifier.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Energy Star and Arizona International Energy Conservation Code (IECC) qualified. Up to 15.4 SEER and 8.5 HSPF efficiency ratings. Scroll compressor provides reliable single-stage, three-phase cooling for improved temperature and humidity control. Galvanized steel construction protects unit against extreme weather.
Warranty information: Five-year limited warranty on compressor; five-year parts limited warranty (including compressor and coil). Timely registration required for five-year parts limited warranty. Jurisdictions where warranty benefits cannot be conditioned on registration will receive the registered limited warranty periods. Please see warranty certificate for further details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoArcoaire.com.
eProduct: 161
Serviceability features: IGC solid-state control for onboard diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points are located in one convenient place: the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screws.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified units feature field convertible airflow, high- and low-pressure switches, and dual scroll compressors. Scroll compressors have internal line-break overload protection. Factory-installed options include three heat options (high, medium, low) and medium- and high-static indoor fan option. Other market-driven options such as liquid propane/high-altitude kits available.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized stainless steel heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoArcoaire.com.
eProduct: 162
Serviceability features: All service and maintenance performed outside the building, consuming no interior floor space. Additional service features include step capacity compressor, multispeed blower motor, and high- and low-pressure switches. Ventilation package options factory or field installed; 18-gauge stainless steel tubular heat exchanger; hinged service door with easy access to air filters; advanced in-shot burner design; integrated direct spark ignition (DSI) control; and versatility to satisfy ducted or non-ducted application.
Noise-reduction features: Step-capacity compressor, electronically commutated (EC) indoor blower motor, advanced design in-shot burners.
IAQ equipment supported: Variety of ventilation options include energy recovery ventilator, economizer, and commercial room ventilator.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Multi-step capacity compressor with green refrigerant R-410A and ventilation package options. Its space-saving design accommodates applications such as new construction, modular applications, school modernization, portable structures, retail stores, correctional facilities, and other commercial applications.
Warranty information: Five-year parts warranty, 10-year heat exchanger warranty.
Special installation requirements: Low NOx models, high-altitude kits, and Canadian-approved models available.
Contact: Bard Mfg. Co. Inc., 419-636-1194; www.bardhvac.com.
eProduct: 163
Serviceability features: Designed so that all critical components are easily serviced directly from the front of the unit.
Noise-reduction features: Special insulation has been installed around the heat exchanger and boiler jacket to ensure quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: With an efficiency of 96 percent, this series is loaded with standard features, including 5:1 turndown ratio and onboard control that features weather compensation, Modbus connectivity, and a two-wire cascades link. It offers practical control solutions for any application, push terminal wiring, and a host of venting options. Boilers are CSD1-compliant, thanks to built-in low water cutoff and an adjustable manual reset high limit.
Warranty information: The manufacturer warrants that the heat exchanger will remain free of leaks for 10 years from the date of original installation or date of manufacture if proof of installation is not available, provided that the boiler is properly installed and maintained by a certified, licensed contractor and the other conditions of the warranty are met.
Special installation requirements: Designed for ease of installation and features an automatic control unit for gas-fired appliances with a premix burner, pneumatic air-gas system, factory built-in low water cutoff, and safety temperature high limiter with manual reset.
Contact: Bosch Thermotechnology, 312-673-6063; www.bosch-climate.us.
eProduct: 164
Serviceability features: All Model AH air handlers have service availability from either the left- or right-hand side of the unit. Access to the interior of the unit is provided by quick-release smart latches and hinged or completely removable door panels, which allow easy access to all the unit’s components for servicing. Water coils have air vents located on the outside of the unit for fast, convenient bleeding of any air trapped in the system.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Innovative cabinet design features double-wall panels that sit on a framework of aluminum supports. Its galvanized steel base is unique due to its dual suitability for both indoor and outdoor installations. The unique, folded-panel design with sections joined using a double tongue-and-groove joint along with complex gasketing ensures maximum air tightness and thermal break.
Warranty information: The manufacturer warrants that all internal components incorporated into the air handler at the time of shipment shall remain free from defects in workmanship and materials for all internal functional parts two years following shipment date of the product for the unit casing and five years from the shipment date, provided it is installed and properly maintained by a qualified and trained HVAC contractor.
Special installation requirements: Units are built with contractors’ installation needs in mind. They can be configured for different inlet and outlet locations for easy duct connection and can be delivered fully assembled or in sections to accommodate space restrictions.
Contact: Bosch Thermotechnology, 312-673-6063; www.bosch-climate.us.
eProduct: 165
Serviceability features: Comes standard with a large, organized control box and standardized components. The central terminal board provides one convenient location for easy access for wiring and service points. Handled easy-access panels, no-strip screw technology, and toolless filter access provide quick entry.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, prop condenser fan, and rigid base rails assist with noise reduction.
IAQ equipment supported: Integrated economizer with multiple sensing options, 2-inch disposable filters, and multi-speed indoor fan motors on most models.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Units are designed for vertical and horizontal airflow capabilities. Basic unit footprint has not changed in over 20 years, allowing the unit to directly fit on past Bryant models. Units are available with many certified factory-installed options and field-installed accessories.
Warranty information: Five-year parts only on compressors and electric heaters, plus one-year parts only on all other. Optional extended protection programs are available.
Special installation requirements: None.
Contact: Bryant, 317-847-6930; www.bryant.com.
eProduct: 166
Serviceability features: Exclusive gas controller provides onboard diagnostics with LED error indicator, burner logic, and energy saving indoor fan motor delay for easy troubleshooting. Large access doors with handles and no-strip screw system provides quick entry.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, prop condenser fan, and rigid base rails assist with noise reduction.
IAQ equipment supported: Factory-installed Perfect Humidity dehumidification system and 2-inch disposable filters. Units are also available with multiple types of air economizers and power exhaust systems with the use of multi-speed indoor fan motors on most models.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Units are designed for vertical and horizontal airflow capabilities. Basic unit footprint has not changed in over 20 years, allowing the unit to directly fit on past Bryant models. Units are available with many certified factory-installed options and field-installed accessories.
Warranty information: Ten-year parts only warranty on aluminized heat exchanger, 15-year parts only warranty on stainless steel heat exchangers, five-year parts only on compressors, and one-year parts only on all other. Optional extended protection programs are available.
Special installation requirements: None.
Contact: Bryant, 317-847-6930; www.bryant.com.
eProduct: 167
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: These high-temperature space heaters combine heating and ventilation into one unit, drawing in 100 percent outside air for high IAQ. With a unique blow-thru design, this direct gas-fired space heater efficiently delivers more usable heat and thermal comfort with minimal temperature variation throughout the heated space. New vertical and horizontal mounting stands add flexibility and make installations easier.
Warranty information: Two-year warranty on the heater and five-year warranty on the Cambridge burner.
Special installation requirements: Space heaters install through walls, on rooftops, or under the roof to deliver heat in large open spaces, including warehouses, distribution centers, and other industrial settings. Pre-piped and pre-wired to make installation and startup easier, the S-Series’ compact size takes up less valuable interior storage or production space. New mounting stands provide a seamless installation package for retrofits as well as new construction.
Contact: Cambridge Engineering, 888-919-1887; www.cambridge-eng.com.
eProduct: 168
Serviceability features: Comes standard with onboard controls that provide diagnostics and troubleshooting capabilities. Also includes system LED indicator, fault LED indicator, compressor fault LED, phase loss protection, and phase reversal protection.
Noise-reduction features: High-efficiency scroll compressors include vibration isolation and overload protection for quiet and durable operation.
IAQ equipment supported: When paired with Carrier 40RUQ air handler, direct expansion cooling coils prevent the buildup of humidity. The air handler has integrated economizer operation with multiple sensing options, 2-inch disposable filters, and multi-speed indoor fan motors.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Units come standard with time/temperature defrost controls and refrigerant suction line accumulator. Complete offering of sizes, operation, and options makes the 38AUQ model suitable for replacement or new construction.
Warranty information: Five-year parts only on compressors and one-year parts only on all other. Optional extended protection programs are available.
Special installation requirements: None.
Contact: Carrier, 317-847-6930; carrier.com/commercial.
eProduct: 169
Serviceability features: Large terminal board facilitates simple safety circuit troubleshooting and simplified control box arrangement. The access panels feature easy-grip handles. Unit access panels feature innovative, easy starting, no-strip screws. In addition, there is a toolless filter access door.
Noise-reduction features: Fully insulated cabinet with foil-faced insulation, isolation compressor mounting design, prop condenser fan, and rigid base rails assist with noise reduction.
IAQ equipment supported: Multistage cooling in single circuit design allows for full active evaporator coils for better humidity control. Factory-installed Humidi-MiZer adaptive dehumidification system and 2-inch disposable filters. Units are also available with multiple types of air economizers with demand control ventilation capabilities, power exhaust systems, and multi-speed indoor fan motors.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The multistage cooling compressor system with the Staged Air Volume™ (SAV) system provides comfort, energy savings, and humidity control. With the use of SystemVu™ controls and the variable-frequency drive fan system, the unit is suitable for single-zone variable air volume capability. Twelve sizes are available from 3 to 23 tons.
Warranty information: Ten-year parts only heat exchanger (aluminized), 15-year parts only heat exchanger (stainless steel), five-years parts only (compressor), three-year parts only on SystemVu controls, one-year parts only on all other parts, and many extended warranty packages available.
Special installation requirements: None.
Contact: Carrier, 317-847-6930; carrier.com/commercial.
eProduct: 170
Serviceability features: Setup, optimization, and monitoring are easy with standard Smart Equipment controls — a next-generation control system that offers an optional mobile access portal (MAP) gateway for access via a smartphone, tablet, laptop, or remote PC. Optional fault detection and diagnostics (FDD) saves contractors time by providing detailed alerts.
Noise-reduction features: Designed for lower outdoor operating sound levels as low as 79 dBA.
IAQ equipment supported: Units are available with economizers as well as fresh air and relief damper options. Three static drive options allow for airflow versatility up to 2-inch external static pressure (ESP). Two- or 4-inch field-convertible air filters and epoxy coil coating options are available.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Direct Fit™ heat pumps feature an exact-fit replacement design that matches the footprints of other manufacturers’ units to reduce installation time, cost, and complexity. Available with adjustable defrost and three heat capacities, two cabinet heights and footprint sizes, and a choice of cooling or electric heat configurations.
Warranty information: One-year limited complete unit and five-year limited compressor and electric heater element warranties are available.
Special installation requirements: None.
Contact: Champion, 405-419-6545; www.championhomecomfort.com/replacement.
eProduct: 171
Serviceability features: Hinge-mounted burner with gas-assist lift for easy access; quick fireside access for routine maintenance and inspections
Noise-reduction features: Electronically commutated (EC) variable-speed fan equates to sub-70 dBA sound levels.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Named a finalist in the 2018 AHR Expo Innovation Awards, the boiler achieves up to 99 percent efficiency due to its enhanced AluFer fire-tube heat exchanger and dual-temperature returns. Dual-temperature return systems increase condensing in a hot water boiler, raising efficiency by 6 percent or more compared to a traditional single-return design. The ClearFire-CE is easy for engineers to incorporate into a retrofit design or a new construction project because there are no flow limitations to consider.
Warranty information: Non-prorated warranties, including 20-year warranty against thermal stress, 10-year warranty against fireside corrosion, and five-year burner canister warranty.
Special installation requirements: Easy to install. It fits through a standard doorway, and the side casings can be removed easily for passage through tight-access areas. Components are pre-programmed for plug-and-play operation.
Contact: Cleaver-Brooks, 800-250-5883; www.cleaverbrooks.com.
eProduct: 172
Serviceability features: Setup, optimization, and monitoring are easy with standard Smart Equipment controls — a next-generation control system offering optional Mobile Access Portal (MAP) Gateway for access via a smartphone, tablet, laptop, or remote PC. An optional Fault Detection and Diagnostics (FDD) saves contractors time by providing detailed alerts.
Noise-reduction features: Designed for lower outdoor operating sound levels as low as 79 dBA.
IAQ equipment supported: Available with an economizer and fresh air and relief damper options; three static drive options for airflow versatility up to 2-inch external static pressure (ESP); and options for 2- or 4-inch field-convertible air filters and epoxy coil coating options.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Heat pumps feature an exact-fit replacement design that matches the footprints of other manufacturers’ units to reduce installation time, cost, and complexity. Available with adjustable defrost and three heat capacities, two cabinet heights and footprint sizes, and a choice of cooling or electric heat configurations.
Warranty information: One-year limited warranty on complete unit. Compressors and electric heater elements each carry a five-year limited warranty.
Special installation requirements: None.
Contact: Coleman, 405-419-6545; www.colemanac.com/peak.
eProduct: 173
Serviceability features: Performance Sentinel system monitors the operation and can warn of a potential problem so that preventative maintenance can be scheduled before a lockout occurs. Standard galvanized cabinetry and optional tin-coated evaporator coil minimizes corrosion potential, while the optional cupronickel water coil offers added durability.
Noise-reduction features: Sound-absorbing glass fiber insulation, plus insulated divider to separate compressor and air handler compartments, dampens sound transmission.
IAQ equipment supported: Compatible with most accepted methods of IAQ remediation.
Thermostat compatibility: Compatible with most thermostats. Water-side economizer will require two-stage cooling/one-stage heating heat pump thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Optional factory-installed waterside economizer (WSE) uses cool loop water for “free” cooling. WSE option meets IECC section C403.3.1 and is a requirement in many states. Optional electronically commutated (EC) blower motor increases efficiency, while the optional high-static motor allows for more flexible installation applications. LonWorks, BACnet, Modbus, and Johnson N2 compatibility options are available for direct digital control (DDC).
Warranty information: Five-year compressor, one-year parts.
Special installation requirements: Available in a wide variety of voltages, in both water-loop and extended-range configurations for ground-loop applications. Configurable for left/right/front return, and top/back/straight supply depending on model.
Contact: Mars/Heat Controller, 800-448-5872; www.marsdelivers.com.
eProduct: 174
Serviceability features: Installs easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll compressor, which operates most of the time in the quiet, low stage. Also includes a two-stage heating system that offers similar comfort benefits in the heating mode. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Dehumidification mode (airflow reduction) standard on all models. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units feature two-stage heating and cooling operation, stainless steel tubular heat exchangers, field-convertible airflow, and high-efficiency electronically commutated (EC) indoor blower motors. With cooling efficiencies up to 16 SEER and 12.5 EER, the PGR5 packaged units are Energy Star qualified.
Warranty information: Ten-year limited warranty on heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoComfortmaker.com.
eProduct: 175
Serviceability features: Access panels with easy-grip handles provide easy access to blower and blower motor, control box, and compressors. No-strip screw feature has superior holding power and guides screws into position while preventing the screw from stripping the unit’s metal. Terminal board facilitates simple safety circuit troubleshooting and simplified control box arrangement.
Noise-reduction features: Fully insulated cabinet.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide demand-controlled ventilation (DCV) capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified units are field convertible for vertical or horizontal airflow duct configuration. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan and economizers.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoComfortmaker.com.
eProduct: 176
Serviceability features: Toolless access door is front-hinged to swing open, allowing for quick and easy access to components, including the filter, fan, and electrical box. All units — with or without electric heat — have a single-point power connection.
Noise-reduction features: Engineered for high-rise apartments, office buildings, dormitories, and hotels, OptiLine provides quiet, comfortable, and economical heating and cooling in a slender package. The electronically commutated motor (ECM) — with its backward inclined impeller fan and cabinet design — typically achieves a noise criterion (NC) of 25 to 30.
IAQ equipment supported: Comes standard with a MERV 8 filter for superior air filtration and particle arrestance. The filter is easily accessible behind the access door, and the stainless steel drain pan prevents corrosion and avoids standing water for high IAQ.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Designed to consume the lowest amount of energy possible, the standard features reduce energy costs by 30 to 50 percent when compared to typical fan coils. Its high-efficiency backward inclined fan motor with a three-speed ECM results in power consumption of 30 watts or lower.
Warranty information: Standard parts warranty up to 18 months from ship date. Extended warranties (parts only) of one to four years are also available.
Special installation requirements: Factory-mounted swaged risers reduce the number of solder joints and the risk of riser sizing errors to make installation fast and easy. Daikin pre-engineers the risers for proper flow and minimal pressure drop to reduce the pumping energy, which eliminates the need for couplings. Top and side electrical connections allow drywall to be installed directly against the unit on both sides.
Contact: Daikin Applied, 763-553-5330; www.DaikinApplied.com.
eProduct: 177
Serviceability features: Full-perimeter base rail, sloped drain pan, contactors with lugs, high- and low-pressure switches, high-capacity steel-cased filter driers, crankcase heater, and built-in filter rack for 2-inch filters convertible to 4 inches.
Noise-reduction features: High-efficiency scroll compressors.
IAQ equipment supported: Factory-installed economizers are available for providing and controlling fresh outside air.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Several factory-installed options include hinged access panels, powered or non-powered convenience outlets, non-fused disconnect switch, return and/or supply air smoke detectors, stainless-steel heat exchanger, economizer, and phase monitor. Two high-efficiency scroll compressors, an award-winning tubular heat exchanger, and an aluminum microchannel evaporator coil provide high performance, efficiency, and reliability.
Warranty information: Five-year parts limited warranty and 20-year heat exchanger limited warranty.
Special installation requirements: Units are shipped with downflow orientation but are convertible to horizontal orientation.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 178
Serviceability features: Standard ease-of-service features include full-perimeter base rail, sloped drain pan, contactors with lugs, high- and low-pressure switches, high-capacity steel-cased filter driers, and built-in filter rack for 2-inch filters.
Noise-reduction features: High-efficiency scroll compressors
IAQ equipment supported: Factory-installed economizers are available for providing and controlling fresh outside air.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Several factory-installed options include hinged access panels, powered or non-powered convenience outlets, non-fused disconnect switch, return and/or supply air smoke detectors, stainless-steel heat exchanger, economizer, and phase monitor.
Warranty information: Five-year parts limited warranty and 20-year heat exchanger limited warranty.
Special installation requirements: Units are shipped with downflow orientation but are convertible to horizontal orientation.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 179
Serviceability features: Uses hot gas base pan circuit to allow installation without the need for additional drain pan heaters. Auto changeover to backup (auxiliary) heat as standard. Long pipe lengths with up to 295 feet allowable height difference between outdoor and indoor units. Continuous heating during defrost and oil return on multi-module systems. Daikin PE Blue fin coil with 1,000 hours salt spray test. Ships factory standard with coil guards.
Noise-reduction features: Standard operating sound levels are minimized with inverter variable-speed vapor injection compressors.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This air-cooled VRF system delivers heating down to minus 22°F (minus 30°C) as standard. Offers 100 percent of nominal heating capacity at 0°F (minus 18°C), up to 85 percent of nominal capacity at minus 13°F (minus 25°C), and up to 60 percent capacity at minus 22°F (minus 30°C). Engineered with patented vapor injection compressor technology for optimized part-load efficiency. Year-round comfort and efficiency with automatic and customizable variable refrigerant technology (VRT).
Warranty information: Ten-year parts limited warranty and 10-year replacement compressor limited warranty.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 180
Serviceability features: Convenient drop-down electrical box provides easy access to internal components. Front or top refrigerant pipe connections provide additional application installation flexibility. Easy-to-read, seven-character display provides simplified diagnostics and troubleshooting. Compact (39 inches high by 30 inches wide by 22 inches deep), lightweight (430 pounds) units are transportable using a dolly and elevators, saving time and labor. The compact size and heat rejection cancellation technology allow installation in small spaces without any additional ventilation requirements.
Noise-reduction features: Standard operating sound levels are minimized with Daikin engineered and manufactured proprietary, inverter, variable-speed scroll compressors, providing system sound pressure levels as low as 54 dBA.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Engineered for buildings with cooling tower water loops or geothermal applications. Single modules are available in 8, 10, and 12 tons. Single modules can be manifolded together with up to three units to form one system of up to 36 tons. Simultaneous heating and cooling is available with heat recovery configuration. Provides all the attributes of an air-cooled VRV system, including the added flexibility for cold climate applications, low sound levels, advanced comfort control, and zoning.
Warranty information: Ten-year parts limited warranty and 10-year replacement compressor limited warranty.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 181
Serviceability features: Available in 3-, 4- and 5-ton sizes for application flexibility with 230-V operation. Easy access to service valves. Only two screws to access control panel. External high and low refrigerant service ports.
Noise-reduction features: Quiet operation (as low as 72 dBA). Units are equipped with Copeland Scroll compressors and isolation compressor grommets to minimize sound at maximum performance. Compressor sound blanket standard.
IAQ equipment supported: As part of an installed system, compatible with Day & Night IAQ system components: humidifiers, ventilators, UV lamps, and air purifier.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Energy Star and Arizona International Energy Conservation Code (IECC) qualified. Up to 15.4 SEER and 8.5 HSPF efficiency ratings. Scroll compressor provides single-stage, three-phase cooling for temperature and humidity control. Galvanized steel construction protects unit against extreme weather.
Warranty information: Five-year limited warranty on compressor; five-year parts limited warranty (including compressor and coil). Timely registration required for five-year parts limited warranty. Jurisdictions where warranty benefits cannot be conditioned on registration will receive the registered limited warranty periods. Please see warranty certificate for further details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoDayandNight.com.
eProduct: 182
Serviceability features: Units have provisions for through-the-bottom power entry. Advanced terminal board for simple safety circuit troubleshooting and control box arrangement. Access panels have easy-grip handles and no-strip screws. Toolless filter access door. IGC solid-state control for onboard diagnostics with LED error code designation and burner control logic.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide outdoor air for demand controlled ventilation (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: This ASHRAE 90.1-compliant unit features efficient scroll compressors with internal line-break overload protection. Field convertible from vertical to horizontal airflow on all models (field accessory supply duct kit required for 180 size only). Exclusive non-corrosive composite condensate pan in accordance with ASHRAE 62. Low-pressure, freeze protection, and high-pressure switches. Fixed refrigerant metering system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger, 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoDayandNight.com.
eProduct: 183
Serviceability features: Control board features an easy-to-use interactive display for boiler setup as well as status and fault monitoring. Stage active light and individual circuit breakers for each element provide positive indication of element activity and easy isolation for troubleshooting. Audible alarm for built-in low water cutoff and water temperature high limit faults.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Compact size for tight boiler room applications. New control provides digital temperature control with supply and return water temperature sensing and outdoor reset. Control board is capable of multi-boiler staging and lead-lag operation. Programmable stage delay for better element control where power demand charges are in effect. BACnet and LonWorks interface module options available. Complies with ASME CSD-1, boiler vessel rated at 30 psi or optional 125 psi, and National Board and CRN registered.
Warranty information: One-year limited warranty on boiler control components and boiler elements. Five-year limited warranty on boiler vessel.
Special installation requirements: Manufacturer did not specify.
Contact: Electro Industries, 763-295-4138; www.electromn.com.
eProduct: 184
Serviceability features: Built-in circuit breakers for high voltage disconnect. Interactive display for operation status and fault monitoring. Front panel access to all control components and wiring. All low-voltage wiring connections at control board. Front panel access to aluminum washable filter.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Automatic operation with interlock to an exhaust fan using an included current sensor. Three-speed blower operation is available in applications using the included current sensor to detect exhaust fan amperage. A simple calibration routine allows the installer to match the makeup air unit fan speed to the exhaust fan speed at three set points. Now available in an extended range of sizes in 208-/240-vac single-phase and additional 208-vac three-phase models.
Warranty information: Commercial applications: one-year warranty on all control components, blower, and elements.
Special installation requirements: Manufacturer did not specify.
Contact: Electro Industries, 763-295-4138; www.electromn.com.
eProduct: 185
Serviceability features: LEDs on the control board indicate operational status and fault conditions. Refrigerant access valves are standard. All major components are readily accessible. Front control panel allows easy access and complies with National Electrical Code (NEC) clearance codes on side-by-side units. Major components accessible from either side.
Noise-reduction features: These models minimize sound levels. A high-efficiency axial fan moves air silently through the outdoor coils. A low-vibration scroll compressor ensures quiet operation as well as energy efficiency. The indoor air mover utilizes an electronically commutated motor (ECM) that automatically adjusts its speed to maintain the proper airflow at various external static pressures.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: EH Series feature EERs up to 11.5. EHS Series feature two-stage compressors, outside air options, standard 2-inch pleated MERV 8 filters, R-410A refrigerant, an optional economizer that reduces energy usage, a high-efficiency compressor, lanced coil fins, high- and low-pressure switches with lockout and short cycle protection, single-point power entry, built-in mounting flanges and internal disconnect, standard access valves and filters, and status LEDs.
Warranty information: Standard warranty covers parts for one year, five-year compressor. Optional extended warranties are available.
Special installation requirements: Sloped top with flashing eliminates need of rain hood. Built-in mounting flanges facilitate installation and minimize chance of water leaks. Factory-installed disconnect on all units, including 460-V models. Outside air hood included with each unit. Single-point power entry complies with latest edition of UL Standard 1995.
Contact: Airxcel Commercial/Industrial Group, 229-273-3636 X5384; www.airxcel.com.
eProduct: 186
Serviceability features: Standard 42-by-16-inch chassis built for ease of installation and serviceability. Easy-to-remove indoor blower section for cleaning and motor service. Easy access to all working components for both cleaning and service.
Noise-reduction features: Inverter technology eliminates noisy on/off cycles and operates at quieter levels than other conventional PTAC units.
IAQ equipment supported: Integrated FreshAire™ system delivers 35 cfm of conditioned fresh air into the space (in negative pressure environments, more cfm is expected). The fresh air is filtered through a MERV 8 filter per ASHRAE 62.1-2013.
Thermostat compatibility: Most 24-V thermostats are supported, including Friedrich Energy Management thermostats. The inverter system will operate as a modular system when a 24-V thermostat is applied, still providing the major benefits of inverter technology. Friedrich is currently designing a 12-V controller for the FreshAire PTAC to allow for full resolution of the inverter system (anticipated in 2019).
Replacement parts compatibility: Shares replacement parts with other models
Additional features: Utilizes a fully integrated fresh air system that delivers makeup air that complies with ASHRAE 62.1-2013 requirements. Inverter compressor extends the unit’s cooling and heating capacity.
Warranty information: Two-year parts warranty, five-year limited.
Special installation requirements: None. Standard 42-by-16-inch PTAC fits into most wall sleeves.
Contact: Friedrich Air Conditioning, 210-546-0500; www.friedrich.com.
eProduct: 187
Serviceability features: Units are easy to diagnose, repair, and replace. Typical troubleshooting and operational support can be accomplished without specialized training or certifications. Serviceability features include easy-access control boards, single-panel access to refrigeration components, same size screws on all panels to make disassembly quick and easy, wall controller diagnostics (active diagnostic, historical diagnostic data), software upgradeable from wall controller, and easy removal of indoor blower.
Noise-reduction features: Precision Inverter® technology eliminates noisy on/off cycles and operates at quiet levels. The closet-mounted unitary package design also conceals compressor noise. The unique free-floating chassis means no metal-to-metal contact, and fully insulated panels provide improved sound characteristics.
IAQ equipment supported: Optional integrated FreshAire system that delivers 0, 70, or up to 140 cfm of conditioned fresh air into the space. The fresh air is filtered through a MERV 8 filter per ASHRAE 62.1-2013.
Thermostat compatibility: Compatible with most thermostats. Friedrich offers two thermostat options, with or without energy management and occupancy sensors. There are additional thermostats on the market that will also work with the unit.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Precision Inverter delivers efficiencies up to 15.5 SEER, 11 EER, and 8.6 HSPF. Operates 20 to 120 percent of rated capacity. Humidity control system with onboard sensors and humidistats. Low-ambient heat pump operation down to 0˚ F. Optional FreshAire system brings in up to 140 cfm of conditioned, MERV 8-filtered outside air, helping building owners meet ASHRAE 62.1-2013 building code for IAQ.
Warranty information: One-year parts warranty, five-year warranty on the sealed refrigeration system, including compressor, indoor and outdoor coils, and tubing.
Special installation requirements: None.
Contact: Friedrich Air Conditioning, 210-546-0500; www.friedrich.com.
eProduct: 188
Serviceability features: Inspection/replacement of main parts is easy due to innovative construction and consolidated electrical components. Easy-to-read, seven-segment LED display explains operational /trouble status. Connection Check function simplifies communication wiring checking.
Noise-reduction features: The unit offers two low-noise modes. Using these modes can lower the outdoor unit sound rating by 5 to 6 dB.
IAQ equipment supported: Indoor wall-mounted units feature ion deodorization filters, which decompose absorbed odors using the oxidizing/reducing effects of ions generated by the ultra-fine-particle ceramic and Apple-Catechin filter that absorbs fine dust, invisible mold spores, and harmful microorganisms onto the filter by static electricity, further inhibiting and deactivating growth. In addition, affiliated third parties provide economizer and filter boxes for ducted indoor units.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This compact single-phase VRF system provides both heating and cooling, featuring control logic, inverter-driven dual-rotary compressor, dual high-efficiency DC fans, and a large heat exchanger. The unit achieves SEER ratings of up to 19.8 and HSPF of up to 11.4.
Warranty information: For systems that are installed and commissioned by a qualified contractor, there is a 10-year warranty on parts and compressor. See warranty statement for full details.
Special installation requirements: Installing contractors are required to take the Airstage Service training to guarantee trouble-free installation and long equipment life.
Contact: Fujitsu General America Inc., 888-888-3424; fujitsugeneral.com.
eProduct: 189
Serviceability features: High-quality powder coated jacket panels detach from the cabinet in seconds. Toolless latches and a hinged front door allow the service technician rapid access to critical components for service and maintenance.
Noise-reduction features: Incorporates a variable-speed fan; a gasketed, 16-gauge thick steel cabinet; and a low-noise blower and burner to keep sound emissions to a minimum. Also included as standard are Fulton exclusive resonator tubes, which are used to eliminate burner harmonics, for quieter operation across all operating conditions.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This high-mass fire-tube condensing boiler is built with Duplex Alloy stainless steel. It is designed for variable primary flow, a piping arrangement that eliminates dedicated boiler pumps, maximizes thermal efficiency, and enhances temperature control. The burner features O2 compensation with true 15:1 turndown. O2 compensation tunes combustion in real time, automatically adjusting for seasonality and ensuring the burner is always operating at its most efficient and most reliable condition.
Warranty information: Lifetime thermal shock, 10-year pressure vessel and flue gas corrosion, five-year burner head, and one-year parts warranty. Parts warranties are available at the time of purchase for up to five years.
Special installation requirements: Can be placed side-by-side (1-inch clearance) between pairs, with 24 inches required on the outside of each pair. A special gas vent (Category IV flue) is required, which is typically UL-1738 listed stainless steel or polypropylene.
Contact: Fulton Heating Solutions, 315-268-8510; fulton.com.
eProduct: 190
Serviceability features: The hinged control box swings open or removes for access to internal components. Electrical and water connections are located on the front corner post. Other features include front panel refrigerant test port access, removable exterior service panels, sealed air handling compartment for setup and service during unit operation, and externally mounted desuperheater switch.
Noise-reduction features: Elastomeric compressor vibration absorption pads provide superior sound and vibration insulation. Heavy-gauge compressor mounting plate with multiple durometer rubber and elastomeric vibration absorption pads provide superior compressor and blower motor isolation. High-density, UL Greenguard Gold-certified, closed-cell foam insulation absorbs sound. Heavy-gauge galvanized or pre-painted sheet metal cabinet is engineered and built to meet industry leakage guidelines.
IAQ equipment supported: Field-installed accessory filter rack accepts a 1- or 2-inch disposable pleated filter. Lifetime washable electrostatic filters or electronic air cleaners with disposable media packs are available as well. Most other air filtration, humidification, or purifier systems are compatible with all Enertech products.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Compact horizontal packaged models are field configurable for side or end discharge and feature a compact design with high efficiencies. An all-aluminum microchannel air coil improves efficiency. The sensor and flow switch-protected, foam-enclosed brazed plate heat exchanger reduces weight and refrigerant charge while increasing performance. Compact design allows 24-inch on-center attic truss pass-through installation. This unit is available in all sizes with a braze plate heat exchanger or a coaxial heat exchanger.
Warranty information: Standard residential warranty includes 10-year on all unit components, 10-year warranty on select accessory items, and a five-year labor allowance on all of the above, including select accessories. Free labor allowance upgrade to 10 years with warranty registration. Optional limited lifetime microchannel air coil and compressor warranty available.
Special installation requirements: Manufacturer did not specify.
Contact: Enertech Global, LLC, 618-690-3231; www.enertechgeo.com.
eProduct: 191
Serviceability features: Top and side access serviceable to all components for ease of maintenance.
Noise-reduction features: G10 inverter technology saves energy and reduces outdoor noise.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: G10 inverter control reduces sound levels to 56dBA. Intelligent defrost low-ambient cooling.
Warranty information: Five-year parts, five-year limited unit replacement with refrigerant component failure.
Special installation requirements: Required installation from a licensed contractor
Contact: Tradewinds Climate Systems, 855-8507928; www.greecomfort.com.
eProduct: 192
Serviceability features: Units have provisions for through-the-bottom power entry. All connections and troubleshooting points are located in one convenient place: the master terminal board. Access panels have easy-grip handles and no-strip screws. IGC solid-state control for onboard diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide outdoor air for demand controlled ventilation (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Dedicated vertical or horizontal airflow duct configuration models. This ASHRAE 90.1-compliant unit features high- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include three heat options (high, medium, low), stainless steel heat exchangers, and high-static indoor fan option.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger, 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoHeil.com.
eProduct: 193
Serviceability features: Units feature through-the-base utility connections capability. All connections and troubleshooting points located in one convenient place: the master terminal board. Access panels have easy grip handles and no-strip screw feature. Large laminated control/power wiring drawings affixed to unit make troubleshooting easy.
Noise-reduction features: Quiet and efficient operation provided by belt-driven evaporator fans. Fully insulated cabinet.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified units are field convertible for vertical or horizontal airflow duct configuration. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan and economizers.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoHeil.com.
eProduct: 194
Serviceability features: Units have provisions for through-the-bottom power entry. Advanced terminal board for simple safety circuit troubleshooting and control box arrangement. Access panels have easy-grip handles and no-strip screws. Toolless filter access door. IGC solid-state control for onboard diagnostics with LED error code designation and burner control logic.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide outdoor air for demand controlled ventilation (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: This ASHRAE 90.1-compliant unit features efficient scroll compressors with internal line-break overload protection. Field convertible from vertical to horizontal airflow on all models (field accessory supply duct kit required for 180 size only). Exclusive non-corrosive composite condensate pan in accordance with ASHRAE 62. Low-pressure, freeze protection, and high-pressure switches. Fixed refrigerant metering system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger, 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoICPCommercial.com.
eProduct: 195
Serviceability features: IGC solid-state control for onboard diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points located in one convenient place: the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screw feature.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide outdoor air for demand-controlled ventilation (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units feature field convertible airflow and high- and low-pressure switches. Single-stage cooling, two-stage gas heat. Factory-installed options include three heat options (high, medium, and low) and medium- and high-static indoor fan option. Other market-driven options such as liquid propane/high-altitude kits are available.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger, 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoICPCommercial.com.
eProduct: 196
Serviceability features: Setup, optimization, and monitoring are easy with standard Smart Equipment controls — a next-generation control system offering optional Mobile Access Portal (MAP) Gateway for access via a smartphone, tablet, laptop, or remote PC. An optional Fault Detection and Diagnostics (FDD) saves contractors time by providing detailed alerts.
Noise-reduction features: Designed for outdoor operating sound levels as low as 79 dBA.
IAQ equipment supported: Units are available with an economizer and fresh air and relief damper options, three static drive options for airflow versatility up to 2-inch external static pressure (ESP), and options for 2-inch or 4-inch field-convertible air filters and epoxy coil coating options.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Heat pumps feature an exact-fit replacement design that matches the footprints of other manufacturers’ units to reduce installation time, cost, and complexity. Available with adjustable defrost and three heat capacities, two cabinet heights and footprint sizes, and a choice of cooling or electric heat configurations.
Warranty information: One-year limited warranty on complete unit. Compressors and electric heater elements each carry a five-year limited warranty.
Special installation requirements: None.
Contact: Johnson Controls, 405-419-6545; http://bit.ly/Series-12r.
eProduct: 197
Serviceability features: Modular construction that separates burner trays, gas train, and blower assembly makes units easy to install and maintain. Water connection may be reversed to accommodate left- or right-side piping. Vent and combustion air connections can be located on the top or the back of the unit, in any combination, and every unit has a long-lasting washable air filter. Pennant units can be stacked to save space in tight boiler rooms.
Noise-reduction features: Very quiet, sealed combustion operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: New intuitive-to-use LaarsLinc control interface uses icon-driven touch screen technology, packaging powerful functionality into an easy to use system. Features include Quick Start configurator, built-in redundancy — a bank of boilers will continue to operate even if the master control goes down (uses a lag unit’s internal set point or a configurable redundant lead boiler), auto configuring cascade of up to eight units, USB data connection, and multiple pump control.
Warranty information: Boilers: 10-year limited warranty; water heaters: five-year limited warranty.
Special installation requirements: Units can be vented as a Category I or Category III appliance. Category I fan-assisted appliances allow for smaller diameter vents than natural draft units but can still be vented with standard B-vent. Boilers can be used with up to a 50:50 glycol to water mix, and waterways can operate in water with a hardness up to 17 gpg. Units are available as a boiler, volume water heater, or pool heater.
Contact: Laars Heating Systems Company, 603-335-6300; www.laars.com.
eProduct: 198
Serviceability features: Units are designed to be easily serviced and maintained. Features include easy access to service filters, slide-out blower motor and auto-tensioning pulley, accessible compressor and service valves, and a removable and reversible drain pan that fits on horizontal or vertical applications.
Noise-reduction features: The factory-installed variable-frequency drive (VFD) blower lowers sound in part-load operation by reducing air speed. VFD slow start gradually ramps blower up to speed, reducing noise on startup.
IAQ equipment supported: Standard MERV 8 filters and an inverter-driven blower (MSAV™) that reduces airflow to provide moisture removal in part-load cooling. MERV 14 filters are optional.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: This unit offers a Pure Comfort™ system with two-stage cooling and factory-installed MSAV, Advanced Condensate Management™ design to control condensation to keep moisture where it belongs, and Simple Service™ features.
Warranty information: Five-year limited warranty on compressor and one-year limited warranty on covered components.
Special installation requirements: None.
Contact: Lennox Commercial, 972-947-7802; www.lennoxcommercial.com.
eProduct: 199
Serviceability features: Easy to service and onboard self-diagnostics. Periodic indoor unit filter changes and annual outdoor unit coil cleaning. Additionally, the app, Mobile LGMV, is available to enable users to easily visualize system performance in a convenient and intuitive platform on their smartphone.
Noise-reduction features: Biomimetic fan design.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Part of a Multi V system that is compatible with most thermostats
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Operates in ambient conditions down to minus 13°F, making it suitable for commercial applications in extreme cold weather climates.
Warranty information: Standard one-year parts warranty for a qualified system. Extended warranties of a total of 10 years are available for qualified systems. For complete warranty details visit, www.lghvac.com.
Special installation requirements: Manufacturer did not specify.
Contact: LG Electronics Air Conditioning Technologies, 212-880-5266; www.lghvac.com.
eProduct: 200
Serviceability features: Easy to service and requires little maintenance.
Noise-reduction features: Uses a variable-speed compressor.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This heat recovery system is designed to provide energy efficient and flexible simultaneous heating and cooling, down to minus 13°F. System is designed to provide energy-efficient, simultaneous heating and cooling, even in the most extreme weather.
Warranty information: Standard limited liability warranty is five-year parts and seven-year compressor. Qualifying systems registered through www.lg.com will receive 10-year parts and 10-year compressor warranty. LG Excellence Contractors who register qualifying systems on www.lg.com will receive 12 years for the parts and compressor.
Special installation requirements: A heat recovery unit is required for simultaneous heating and cooling operation.
Contact: LG Electronics Air Conditioning Technologies, 212-880-5266; www.lghvac.com.
eProduct: 201
Serviceability features: These models feature a redesigned gas and air manifold to allow for easy and efficient maintenance.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Up to 96 percent thermal efficiency. Designed, engineered, and assembled in the U.S., the boiler comes in 12 models ranging from 2.5 to 6 million Btuh. Turndown ratios of 20:1. Corrosion-resistant 316L stainless steel fire-tube heat exchanger. CON·X·US® remote connectivity is standard, allowing for adjusting equipment controls and monitoring boiler performance from most smart devices. Up to eight CREST condensing boilers can be cascaded together for redundancy
Warranty information: For 10 years, Lochinvar warrants this product against defects in materials or workmanship and failure due to thermal shock.
Special installation requirements: Boiler offers six venting options and permits direct-vent air intake and exhaust runs of up to 100 feet using AL29-4C stainless steel vent pipe on all models as well as CPVC, PVC, and polypropylene on the 2501-3501 models.
Contact: Lochinvar, 615-830-5777; www.lochinvar.com.
eProduct: 202
Serviceability features: Setup, optimization, and monitoring are easy with standard Smart Equipment controls — a next-generation control system offering optional Mobile Access Portal (MAP) Gateway for access via a smartphone, tablet, laptop, or remote PC. An optional Fault Detection and Diagnostics (FDD) saves contractors time by providing detailed alerts.
Noise-reduction features: Designed for outdoor operating sound levels as low as 79 dBA.
IAQ equipment supported: Units are available with an economizer and fresh air and relief damper options, three static drive options for airflow versatility up to 2-inch external static pressure (ESP), and options for 2-inch or 4-inch field-convertible air filters and epoxy coil coating options.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Heat pumps feature an exact-fit replacement design that matches the footprints of other manufacturers’ units to reduce installation time, cost, and complexity. Available with adjustable defrost and three heat capacities, two cabinet heights and footprint sizes, and a choice of cooling or electric heat configurations.
Warranty information: One-year limited warranty on complete unit. Compressors and electric heater elements each carry a five-year limited warranty.
Special installation requirements: None.
Contact: Luxaire, 405-419-6545; www.luxaire.com/eclipse.
eProduct: 203
Serviceability features: These units fit into the same space as many standard ceiling tiles. The unique corner-pocket design allows service access through each of the four corners for easy maintenance and height adjustments. In addition, washable filters provide about 2,500 hours of use in a standard commercial environment before cleaning is required.
Noise-reduction features: A 3-D turbo fan provides quiet, comfortable space conditioning.
IAQ equipment supported: Supports ventilation air intake.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Features technology that increases efficiency without sacrificing occupant comfort. The redesigned 3D i-see Sensor™ continuously scans the room and adjusts temperatures to maintain comfort according to the requirements of the space. Ventilation air intake is supported, and the 3-D turbo fan allows for customized airflow patterns to provide conditioning for a variety of room layouts.
Warranty information: As part of the CITY MULTI® system, the warranty is to the original owner for a period of 10 years from the date of installation if the system is designed by a Diamond Designer using Diamond System Builder™ software and the installing HVAC contractor has successfully completed the CITY MULTI approved training course. The complete warranty documents can be found on MyLinkDrive.com: http://meus1.mylinkdrive.com/Policies/index.html.
Special installation requirements: The 3D i-see Sensor requires the use of a PAR33MAA-J controller.
Contact: Mitsubishi Electric Trane HVAC US LLC, 703-797-7107; www.metahvac.com.
eProduct: 204
Serviceability features: Communication over BACnet and Modbus. Runs on traditional thermostat input signal or return air sensor. Board can control three outputs: blower, stage one, and stage two valve. Uses unit heater temperature to perform energy saver function. Signals sent across BMS allow unit to switch between summer/winter operation, change heating/fan-only set point and set-point band, change energy saver function temperature set point, turn unit on/off, and report equipment vitals through statuses and alarms wired into board.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: The BMS offers control over heating units through an interface. Through a simple and inexpensive room sensor, Modine customers get the functions of a BMS thermostat with the added benefit of equipment alarms and statuses normally not available using a conventional BMS thermostat method. Modine’s board supports the energy saver function, which destratifies warm ceiling air temperatures before turning on the burners.
Warranty information: Manufacturer did not specify.
Special installation requirements: Standard offering on the Effinity unit heaters; optional on standard efficiency gas-fired unit heaters
Contact: Modine, 865-977-1973; www.ripleypr.com.
eProduct: 205
Serviceability features: Direct-drive fans require no belt adjustments. Units leaving factory cfm set by onboard control system unit display. Factory charge, no field adjustment required. Factory-installed disconnect. Access panels to all critical areas, including filter, fans, controls, and compressors. Field-convertible horizontal and vertical discharge.
Noise-reduction features: Compressor sound blanket.
IAQ equipment supported: Demand control ventilation sequencer.
Thermostat compatibility: Unit has an onboard built-in control system. External thermostat not applicable.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Superior latent performance allows tight control of building humidity. No excessive air movement, as only the required amount of air is moved based on the scenario, resulting in fan energy savings. Precise control regulates discharge temperature that decreases building load and minimizes system complexity. Provides unlimited economizer for maximum energy efficiency. Small footprint with downsized equipment for minimal space requirements. Simple, non-complex system provides easy access, effortless system integration, and uncomplicated maintenance.
Warranty information: Includes a two-year, non-prorated warranty on all parts. An extended warranty may be purchased.
Special installation requirements: Manufacturer did not specify.
Contact: Nortek Global HVAC, 800-695-1901; www.reznorhvac.com.
eProduct: 206
Serviceability features: Solid single-piece top and durable panels make installing and servicing units quick and easy. The Qwik-Slide blower assembly fully slides out with the removal of only three screws and rotates more than 180 degrees for service of components such as the blower motor, thermostatic expansion valve (TXV), and microchannel coil. The Qwik-Change Flex-Fit rack design allows simple changeover between 2- and 4-inch standard size filters. A dual seven-segment LED display delivers enhanced diagnostics with easy-to-understand codes.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Units offer energy savings of up to 30 percent compared to current baseline technology and feature a new footprint for seamless installs on most replacements. Units exceed new 2018 IEER requirements and meet 2023 regulations. Offers smart communication using factory-installed ClearControl™ direct digital control (DDC) and sensors that can connect to LonWorks, BACnet, and Modbus BAS/EMS systems for remote monitoring and precise control.
Warranty information: Every commercial unit is backed by commercial limited warranty.
Special installation requirements: Products are built to order, providing business owners and commercial specifiers with customized solutions to suit exact needs, design, and application requirements. Customers choose the efficiency level and the factory-installed options they need, with most factory-installed options and field-installed accessories available across all product tiers. Smart selection tools help specify, select, and document all Rheem equipment for new construction or replacement in all commercial applications.
Contact: Rheem Mfg. Co., 770-351-3000; www.Rheem.com.
eProduct: 207
Serviceability features: Installs easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll compressor, which operates most of the time in the quiet, low stage. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Enhanced dehumidification is available on high-stage cooling with use of a dehumidistat. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Two-stage Copeland Scroll compressors provide two-stage heating and cooling operation. Units include field-convertible airflow for either ground level (horizontal) or rooftop (down) airflow and high-efficiency electronically commutated (EC) indoor blower motors. With cooling efficiencies up to 15.5 SEER and 12.5 EER, these heat pumps are Energy Star qualified.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoTempstar.com.
eProduct: 208
Serviceability features: Units have provisions for through-the-bottom power entry. Advanced terminal board for simple safety circuit troubleshooting and control box arrangement. Access panels have easy-grip handles and no-strip screws. Toolless filter access door. IGC solid-state control for onboard diagnostics with LED error code designation and burner control logic.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide outdoor air for demand controlled ventilation (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: This ASHRAE 90.1-compliant unit features efficient scroll compressors with internal line-break overload protection. Field convertible from vertical to horizontal airflow on all models (field accessory supply duct kit required for 180 size only). Exclusive non-corrosive composite condensate pan in accordance with ASHRAE 62. Low pressure, freeze protection, and high-pressure switches. Fixed refrigerant metering system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger, 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts.
Special installation requirements: None.
Contact: International Comfort Products, 317-847-6930; www.GoTempstar.com.
eProduct: 209
Serviceability features: Swingout door assembly provides complete access to burner, combustion chamber, and heat exchanger, so annual maintenance and burner inspections are as simple as opening a door. No need to hold, support, or pull burners. The AMP series provides service access to the heat exchanger as well for cleaning of flue products.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Optional racking system places twice the Btu in the same footprint. Two-hundred feet of equivalent venting standard out of box in Cat 4 and Cat 2.
Warranty information: Ten-year limited warranty on heat exchanger and one-year on parts.
Special installation requirements: Manufacturer did not specify.
Contact: Thermal Solutions, 717-239-7642; www.thermalsolutions.com.
eProduct: 210
Serviceability features: Compact cabinet design with quick access for ease of service. Horizontal units can be serviced through the unit bottom to virtually eliminate removing ceiling-mounted units for service.
Noise-reduction features: Provided as standard, the unit has a dual-level vibration isolation system. A heavy-gauge mounting plate is isolated from the cabinet via a dense neoprene pad to minimize vibration transfer. The compressor is then isolated from the mounting plate with standard rubber in shear isolators to enhance the dual-level vibration isolation. The compressor is located in a well-insulated compartment, separated from the air stream to minimize sound transmission.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Capacities ranging from .5- to 5-ton with single-stage EERs up to 17 (water loop) conditions in a compact cabinet designed for ease of services. With optional hot gas reheat for temperature and humidity control, as well as hybrid heating and cooling, the CAS series has flexibility over a wide range of applications.
Warranty information: Standard one-year warranty on compressor and parts. Extended five-year warranty is optional.
Special installation requirements: Manufacturer did not specify.
Contact: The Whalen Co., 918-557-5828; www.whalencompany.com.
eProduct: 211
Serviceability features: Supply openings in multiple locations. Supply grille aluminum construction minimizes future maintenance and eliminates oxidation from condensation. Inner service panel is removable, allowing access to control wiring and internal piping. The plug-in-type fan/motor assembly is easily removed through return air opening, with electronically commutated motor (ECM) technology.
Noise-reduction features: Water hoses connect the chassis to the supply and return water piping, which isolates sound from the building piping system. An acoustical panel dampens sound while permitting filter removal without the need for tools. The refrigeration chassis uses an insulated compressor compartment and vibration isolation to further reduce noise.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: These hybrid heat pump units use a hydronic heating coil instead of reversing the refrigerant cycle to allow for energy savings by turning the compressor off and diverting the condenser water to a heating coil. The refrigeration chassis uses a versatile, removable-floating design with insulated compressor compartment and vibration isolation.
Warranty information: The cabinet carries a 15-month warranty, chassis carries a one-year warranty, and the compressor and refrigeration circuit carry a five-year warranty.
Special installation requirements: Manufacturer did not specify.
Contact: The Whalen Co., 918-557-5828; www.whalencompany.com.
eProduct: 212
Serviceability features: Setup, optimization, and monitoring are easy with standard Smart Equipment controls — a next-generation control system offering optional Mobile Access Portal (MAP) Gateway for access via a smartphone, tablet, laptop, or remote PC. An optional Fault Detection and Diagnostics (FDD) saves contractors time by providing detailed alerts.
Noise-reduction features: Designed for outdoor operating sound levels as low as 79 dBA.
IAQ equipment supported: Units are available with an economizer and fresh air and relief damper options, three static drive options for airflow versatility up to 2-inch external static pressure (ESP), and options for 2-inch or 4-inch field-convertible air filters and epoxy coil coating options.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Heat pumps feature an exact-fit replacement design that matches the footprints of other manufacturers’ units to reduce installation time, cost, and complexity. Available with adjustable defrost and three heat capacities, two cabinet heights and footprint sizes, and a choice of cooling or electric heat configurations.
Warranty information: One-year limited warranty on complete unit. Compressors and electric heater elements each carry a five-year limited warranty.
Special installation requirements: None.
Contact: York, 405-419-6545; www.york.com/directfit.
eProduct: 213
Back to gallery
Publication date: 10/1/2018
Want more HVAC industry news and information? Join The NEWS on Facebook, Twitter, and LinkedIn today!
Report Abusive Comment
