It’s time once again for the annual Cooling Showcase. The NEWS’ annual issue has traditionally introduced the latest cooling units available for the upcoming summer season. The intent is to help contractors prepare for this busy period by doing the research that will help them to distinguish between brands.
Like last year, this year’s Cooling Showcase is split into two parts — commercial and residential. This issue focuses on the commercial side of the air conditioning industry, while the April 15 issue highlighted new offerings in the residential cooling market. Included in the coverage is feature-specific information about each individual product as submitted by the manufacturers.
The product chart includes technical facts, such as unit tonnage, refrigerant type, efficiency rating, and cooling capacity. The photo feature below provides more in-depth information on the features of each individual unit and also includes technical support information from the manufacturer. The manufacturers provided all of the data included in the product grid, as well as in the photo feature. Therefore, any questions should be directed to them via the contact information provided in the photo feature section.
Back to gallery
Serviceability features: Service access door with stainless steel piano hinge provides access to energy recovery wheel and exhaust fan. Door can be propped open or opened fully, resting on the air handling unit roof. Slide-out energy recovery wheel with removable pie sections allows for easy cleaning. Labeled terminal block with color-coded wiring and wiring diagram. Factory-provided potentiometer dial for simple airflow adjustment. Direct-drive fans do not require belt maintenance.
Noise-reduction features: Standard, double-wall, rigid, polyurethane foam-injected panel construction dampens radiated fan sound. Supply and exhaust fans include vibration isolation. Standard direct-drive fans do not produce belt sound. Electronically commutated motors for variable airflow control and reduced fan sound at lower speeds.
IAQ equipment supported: Unit has 100 percent outside air capabilities, providing building occupants with fresh air. Total energy recovery wheel and modulating hot gas reheat work together to provide precise humidity control. The incoming air can be filtered using up to 4-inch MERV-14 filtration. Double-sloped stainless steel drain pans and double-wall panel construction inhibit microbial growth. Ultraviolet lights are available to inhibit microbial growth on the coil and drain pan.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts. Shares replacement parts with other models.
Additional features: Available with DX or chilled-water cooling and electric, hot water, steam, or gas heating. Units are available with low-voltage terminal block for connection to a thermostat or customer-provided control system, giving the freedom to match the control system to the application. Factory-provided AAON controls provide a unique control logic for space temperature control of high percentage outdoor air units. Unit includes an LED light strip with switch in the control panel.
Warranty information: One-year parts.
Special installation requirements: Energy recovery wheel air-handling units ship in sections to be assembled in the field. Low-voltage quick connects make wiring between the sections easy. Installation, operation, and maintenance manual with startup form ships inside the control panel.
Contact: AAON, 918-382-6337; www.aaon.com.
eProduct: 160
Serviceability features: Units include a toolless control service access panel for quick and easy access, as well as hem bends, which reduce sharp edges and improve serviceability. WH Series units include bottom-service access to the expansion valve, reversing valve, filter drier, supply fan, and filters for easy maintenance and servicing. Includes integrated hanging brackets with rubber vibration isolation that is not only durable, but simplifies the installation process.
Noise-reduction features: Neoprene closed-cell foam insulation comes standard on these units for reduced sound transmission. Compressors are mounted with rubber-in-shear on an isolation plate that is rubber-in-shear isolated from the cabinet for reduced vibration. Low sound packages are available for even quieter operation. WH Series units include an insulated divider between the compressor compartment and blower section.
IAQ equipment supported: Units are available with 4-inch filter racks with high efficiency filters, up to MERV 14. Stainless steel drain pans are standard with a double slope to ensure positive drainage and inhibit microbial growth. Neoprene closed-cell foam insulation provides a fiber-free and clean airstream.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Two-stage compressors for improved humidity control and part-load conditions efficiency. Standard aluminum microchannel DX coil with a large face area for improved efficiency. Induction brazing utilized on all copper piping connections. All-aluminum construction for significantly reduced weight and superior corrosion resistance.
Warranty information: Standard with a five-year parts warranty.
Special installation requirements: None.
Contact: AAON, 918-382-6337; www.aaon.com.
eProduct: 161
Serviceability features: Slide-out blower compartment, hinged access panel, easy-access gas compartment, and marked and color-coded wiring.
Noise-reduction features: Isolated compressor for quieter operation and easier service.
IAQ equipment supported: New reheat technology provides increased indoor comfort, improved air quality, and additional energy savings.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units are BACnet compatible. Single-zone variable air volume (VAV)-equipped units precisely coordinate fan speed with the current demand for cooling, reducing energy demand. Optional reheat dehumidification technology.
Warranty information: Fifteen-year limited warranty on stainless steel gas heat exchanger, 10-year limited warranty on aluminized gas and heat exchanger, five-year limited warranty on compressor, three-year limited warranty on Eco-Last coil system, and one-year limited warranty on covered components.
Special installation requirements: None.
Contact: Allied Commercial, 803-738-4134; www.allied-commercial.com.
eProduct: 162
Serviceability features: Installs easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down-discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll™ compressor, which operates most of the time in the quiet low stage. Also includes a two-stage heating system that offers similar comfort benefits in the heating mode. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Dehumidification mode (airflow reduction) standard on all models. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units feature two-stage heating and cooling operation, stainless steel tubular heat exchangers, field-convertible airflow, and high-efficiency electronically commutated indoor blower motors. With cooling efficiencies up to 16 SEER and 12.5 EER, the PGR5 packaged units are Energy Star qualified.
Warranty information: Ten-year limited warranty on heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoArcoaire.com.
eProduct: 163
Serviceability features: IGC solid-state control for onboard diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points located in one convenient place: the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screw feature.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide demand-controlled ventilation capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified units feature two-stage cooling with independent circuits and controls. Dedicated vertical or horizontal airflow duct configuration models. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan, economizers, variable-frequency drive two-speed fan, and hot gas reheat system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized steel heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoArcoaire.com.
eProduct: 164
Serviceability features: Hinged service door, roll-out condenser fan assembly, PLC diagnostics for troubleshooting, exterior service port access, dirty filter indicator, easy-to-clean condenser coils, ModBus interface and remote access web page, and Bard Link™. All service and maintenance performed outside the building, consuming no interior floor space.
Noise-reduction features: Electronically commutated motor, variable indoor and outdoor fan.
IAQ equipment supported: Up to MERV-13 indoor air filters, can control external humidifier, emergency shut off, and emergency ventilation.
Thermostat compatibility: Requires a PLC controller.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: A multi-stage, high-capacity, sensible, cooling air conditioner designed to be a slide-in replacement for retrofit applications. Air-Conditioning, Heating and Refrigeration Institute (AHRI) certified and meets state and national codes. Operates remotely via BardLink technology, leverages favorable weather conditions with optional free cooling economizer, and incorporates electric reheat dehumidification as an optional feature. Bard controller can control up to 14 wall-mount units.
Warranty information: Five-year parts refrigeration components.
Special installation requirements: None
Contact: Bard Mfg. Co., 419-636-1194; www.bardhvac.com.
eProduct: 165
Serviceability features: Variable-speed electronically commutated (EC) blower motor, high- and low-pressure switches, compressor time delay, natural fiber insulation, hydrophilic coils, and easy access to condenser and compressor section. Optional dirty filter indicator. Ventilation package options factory or field installed. All service and maintenance performed outside the building, consuming no interior floor space.
Noise-reduction features: Brushless DC EC blower motor, with sound reduction curbs available. Totally enclosed ball-bearing condenser motor.
IAQ equipment supported: Variety of ventilation options include barometric fresh air damper with and without exhaust, energy recovery ventilator, economizer with and without JADE controller, and commercial room ventilator with fixed or modulating blade. Supports up to MERV-13 filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Use of patent-pending Balanced Climate™ feature removes up to 35 percent more humidity than standard units. Enclosed condenser fan motor and lockable access panel. Fits all standard wall-mount openings.
Warranty information: Five-year refrigeration parts.
Special installation requirements: Fits all standard wall-mount openings.
Contact: Bard Mfg. Co., 419-636-1194; www.bardhvac.com.
eProduct: 166
Serviceability features: Standard smart hinged-door panels allow for the easy service and replacement of cartridge panel filter assemblies and the coil. Most standard coil configurations allow for easy removal through a door panel, which is accessible on the right or left side.
Noise-reduction features: Double-wall panels are manufactured using a unique process with steel sheets coated with polyurethane passing over heated rollers to ensure a consistent R-13 insulation. This process provides uniform 2-inch-thick insulated sandwich panels with improved rigidity, thereby obtaining sound attenuation while reducing vibration.
IAQ equipment supported: There are several mixing box configurations, pre- and post-filtration options (MERV-8 to MERV-16 ratings), and empty sections available for field-installed devices such as dehumidifiers, ionizers, or ultraviolet lights. The unit’s cooling coil drain pans comply with ASHRAE 62.1.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The same models are suitable for both indoor and outdoor applications. The sandwich panel, tongue-and-groove assembly, and complex gasketing provide thermal breaking. Energy recovery options, such as a heat wheel, cross-flow plate heat recuperator, or glycol runaround coils, are available. The standard product lead time is six weeks.
Warranty information: See the full warranty details at www.bosch-climate.us
Special installation requirements: Units can be ordered in sections for field assembly in existing applications. Curb-ready base frames are available for rooftop installations with crane lifting locations. Several nonstandard features are available upon request.
Contact: Bosch Thermotechnology Corp., 603-552-1100; www.bosch-climate.us.
eProduct: 167
Serviceability features: Filter access doors can be opened without tools, allowing for quick and easy access to service, check, and change filters. New control board makes fan unit setup and service simple by offering a dedicated indoor fan setup with a large field wiring terminal connection, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units also have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Innovative Axion fan technology features vane axial indoor fan design with built-in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished air filters are standard. Units available with factory- and field-installed fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Units are also available with multiple choices of gas heat to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: New 5/16-inch copper round tube and aluminum plate condenser coils to improve efficiency and reduce refrigerant charge, and toolless filter access door. Simple fan adjustment is made with reference DC volt chart and switch and rotary dial. No special training required. Units have same footprint as 30 years ago for simplified replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, one-year parts. Other extended warranty packages are also available.
Special installation requirements: No special installation requirements. Units are a single packaged design with many pre-engineered and certified factory options and field accessories to most geographic areas and applications.
Contact: Bryant, 800-428-4326; www.bryant.com.
eProduct: 168
Serviceability features: Filter access doors can be opened without tools, allowing for quick and easy access to service, check, and change filters. New control board makes fan unit setup and service simple by offering a dedicated indoor fan setup with a large field wiring terminal connection, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage thru an intuitive switch and rotary dial. Units also have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Innovative Axion fan technology features vane axial indoor fan design with built-in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished air filters are standard. Units available with factory- and field-installed fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Units are also available with multiple choices of gas heat to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: New 5/16-inch copper round tube and aluminum plate condenser coils to improve efficiency and reduce refrigerant charge, and toolless filter access door. Simple fan adjustment is made with reference DC volt chart and switch and rotary dial. No special training required. Units have same footprint as 30 years ago for simplified replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, and one-year parts. Other extended warranty packages are also available.
Special installation requirements: No special installation requirements. Units are a single packaged design with many pre-engineered and certified factory options and field accessories to most geographic areas and applications.
Contact: Bryant, 800-428-4326; www.bryant.com.
eProduct: 169
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Customizable with many filtration systems. Aids IAQ by utilizing 100 percent outside air. In dry climates, direct evaporative cooling units can add needed humidity to the air, providing more user comfort.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Units are semi-custom fabricated air handlers that can utilize indirect evaporative cooling, direct evaporative cooling, or a combination of both methods. These units use 100 percent outside air to provide tempered makeup air and building cooling. There are 14 models available, ranging from 2,450 to 58,800 cfm.
Warranty information: Manufacturer did not specify.
Special installation requirements: Manufacturer did not specify.
Contact: Cambridge Engineering, 314-753-9420; www.cambridge-eng.com.
eProduct: 170
Serviceability features: Large access panels feature easy-grip handles and no-strip screw technology, while air filters are accessed through a toolless filter access door. New unit control board layout connections for easy troubleshooting in one area, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units have corrosion-resistant, internally sloped, self-draining condensate pan. The use of SystemVu controls increases service and diagnostic capabilities.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Innovative EcoBlue technology features vane axial fan design with built in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished air filter with factory upgrade to MERV 8 is available. Units available with an optional foil face insulation package. Factory- and field-fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Units also available with multiple choices of gas heat sizes to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The new 5/16-inch copper round tube and aluminum plate condenser coils improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch and rotary dial. No special training is required. Units have same footprint as 30 years ago, making ideal for replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, three-year SystemVu controls, and one-year parts. Other extended warranty packages are also available.
Special installation requirements: No special installation instructions. Units are a single packaged design with many pre-engineered and certified factory options and field accessories to most geographic areas and applications.
Contact: Carrier, 800-227-7437; carrier.com/commercial.
eProduct: 171
Serviceability features: Large access panels feature easy-grip handles and no-strip screw technology, while air filters are accessed through a toolless filter access door. New unit control board layout connections for easy troubleshooting in one area, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units have corrosion-resistant, internally sloped, self-draining condensate pan. The use of SystemVu controls increases service and diagnostic capabilities.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Innovative EcoBlue technology features vane axial fan design with built in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished air filter with factory upgrade to MERV 8 is available. Units available with an optional foil face insulation package. Factory- and field-fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Units also available with multiple choices of gas heat sizes to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: New 5/16-inch copper round tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch and rotary dial. No special training is required. Units have same footprint as 30 years ago, making ideal for replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, three-year SystemVu controls, and one-year parts. Other extended warranty packages are also available.
Special installation requirements: No special installation requirements. Units are a single packaged design with many pre-engineered and certified factory options and field accessories to most geographic areas and applications.
Contact: Carrier, 800-227-7437; carrier.com/commercial.
eProduct: 172
Serviceability features: Each panel on the HBH units can be removed easily for complete access to all components for easy service or replacement.
Noise-reduction features: Ultra-quiet option.
IAQ equipment supported: Units can be enhanced with the use of MERV filters and the option of water-source economizers.
Thermostat compatibility: Use the Comfort-Aire/Century-compatible thermostat.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Waterside economizer, electronically commutated motor available, quiet operation, Performance Sentinel system, heavy-duty compressors, compact size, and optional extended range refrigerant circuit.
Warranty information: Five-year compressor, one-year parts (some limitations apply; see printed warranty for details.).
Special installation requirements: Please refer to the installation and owner’s manual.
Contact: Comfort-Aire/Century, 517-787-2100; www.marsdelivers.com.
eProduct: 173
Serviceability features: Installs easily on rooftop or ground level. Easy three-panel access for maintenance and installation. Easily converts to down-discharge applications.
Noise-reduction features: Outdoor fan sized and optimized for minimal noise.
IAQ equipment supported: Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified unit achieves up to 15.5 SEER/12.5 EER electric cooling and up to 8.5 HSPF electric heating. Unit features field-convertible airflow, high- and low-pressure switches for added compressor reliability, and high-efficiency electronically commutated indoor blower motor. Dehumidification mode (airflow reduction) on all models.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: Roof curbs available as field-installed accessories.
Contact: International Comfort Products, 317-240-5133; www.GoComfortmaker.com.
eProduct: 174
Serviceability features: Large access panels feature easy-grip handles and no-strip screw technology, while air filters are accessed through a toolless filter access door. New unit control board layout connections to easily troubleshoot in one area, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units also have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Indoor fan uses X-Vane/vane axial fan design with built-in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished return air filters are standard. Units are also available with an optional foil face insulation package. Factory and field fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Unit also available with multiple choices of electric heat sizes to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The new 5/16-inch copper round tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch and rotary dial. No special training is required. Units have same footprint as 30 years ago, making them ideal for replacement.
Warranty information: Standard limited parts: five-year parts on compressor and one-year parts. Other extended warranty packages are also available.
Special installation requirements: None. Units are a single-packaged design with many pre-engineered and certified factory options and field accessories for most geographic areas and applications.
Contact: International Comfort Products, 317-240-5133; www.GoComfortmaker.com.
eProduct: 175
Serviceability features: Factory-installed valve package omits field service and includes control valve, pressure/temperature ports, unions, strainer, circuit setter, ball shutoff valves, and stainless steel flexible hose. Single-point power on all units, with or without electric heat. Size 3 and 4 units have the smallest cabinet footprint on the market for easy installation. Toolless filter changes with hinged return grille makes filter changing quick and easy.
Noise-reduction features: Electronically commutated motor with backward inclined impeller fan provides quiet operation, and when combined with tight cabinet construction, produces a noise criterion of 30.
IAQ equipment supported: Stainless steel drain pan prevents corrosion and avoids standing water for high IAQ. MERV-13 filters catch dust particles and contaminants.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Energy-saving digital programmable thermostat. Swaged risers reduce installation solder joints.
Warranty information: Standard parts warranty up to 18 months from ship date. Extended warranty (parts only) one, two, three, or four years available.
Special installation requirements: None.
Contact: Daikin, 763-553-5157; www.daikinapplied.com.
eProduct: 176
Serviceability features: Standard features include full-perimeter base rail, sloped drain pan, contactors with lugs, high- and low-pressure switches, high-capacity steel-cased filter driers, crankcase heater, and built-in filter rack for 2-inch filters (convertible to 4 inches).
Noise-reduction features: High-efficiency scroll compressors.
IAQ equipment supported: Factory-installed economizers are available for providing and controlling fresh outside air.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Several factory-installed options include hinged access panels, powered or non-powered convenience outlets, non-fused disconnect switch, return and/or supply air smoke detectors, stainless steel heat exchanger, economizer, and phase monitor. Two high-efficiency scroll compressors and an aluminum microchannel evaporator coil (25-ton model only) provide high performance, efficiency, and reliability. For heating, two-stage heating with an award-winning tubular heat exchanger design provide high heating performance and reliability.
Warranty information: Five-year parts limited warranty and 20-year heat exchanger limited warranty.
Special installation requirements: Units are shipped with downflow orientation. Units come with full perimeter base rail and a sloped drain pan for easy installation.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 177
Serviceability features: Hinged access panels for easy serviceability, slide-out filter racks, and factory-installed 2-inch MERV 8 filters. Options include an outdoor airflow monitoring station, 115-V convenience outlet, and a non-fused disconnect switch. DOAS air-handling units can be integrated into the same intelligent Touch Manager (iTM) as the comfort cooling and heating VRV system.
Noise-reduction features: Electronically commutated supply and exhaust fan motors and double-wall 1-inch foam R7 insulated cabinet.
IAQ equipment supported: Unit provides conditioned outside air for VRV system applications.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Engineered to work with VRV air-cooled heat recovery systems to provide conditioning of 100 percent outside ventilation air. Models with nominal 1,000, 2,000, and 3,000 cfm airflow rates can be configured with pretreatment, cooling, reheat, and heating components. An optional energy recovery wheel section can be added to reduce the mechanical cooling capacity of the system. Auxiliary heat is available in modulating gas heat, SCR-controlled electric heat, or hot water.
Warranty information: Standard one-year unit and parts limited warranty.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 178
Serviceability features: Uses hot gas base pan circuit to allow installation without the need of additional drain pan heaters. Auto changeover to backup (auxiliary) heat as standard. Long pipe lengths, with up to 295 feet of allowable height difference between outdoor and indoor units. Continuous heating during defrost and oil return on multi-module systems. Daikin PE Blue fin coil with 1,000-hour salt spray test. Ships factory standard with coil guards.
Noise-reduction features: Standard operating sound levels are minimized with Daikin’s inverter variable-speed vapor injection compressors, with noise levels as low as 60 dBA.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: This air-cooled VRF system delivers heating down to minus 22°F as standard. Offers 100 percent of nominal heating capacity at 0°, up to 85 percent of nominal capacity at minus 13°, and up to 60 percent capacity at minus 22°. Engineered with patented vapor injection compressor technology for optimized part-load efficiency. Year-round comfort and efficiency with automatic and customizable variable refrigerant technology.
Warranty information: Standard 10-year parts limited warranty and a 10-year replacement compressor limited warranty.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 179
Serviceability features: Convenient drop-down electrical box provides easy access to internal components. Front or top refrigerant pipe connections provide additional application installation flexibility. Easy-to-read, seven-character display provides simplified diagnostics and troubleshooting. Compact and lightweight, the units are transportable using a dolly and elevators, saving time and labor. The compact size and heat rejection cancellation technology allow installation in small spaces without any additional ventilation requirements.
Noise-reduction features: Standard operating sound levels are minimized with Daikin proprietary inverter variable-speed scroll compressors, providing system sound pressure levels as low as 54 dBA.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts. Does not share replacement parts with other models.
Additional features: Engineered for buildings with cooling tower water loops or geothermal applications. Single modules are available in 8, 10, and 12 tons. Single modules can be manifolded together with up to three units to form one system of up to 36 tons. Simultaneous heating and cooling is available with heat recovery configuration. Provides all the attributes of an air-cooled VRV system, including the added flexibility for cold climate applications, low sound levels, advanced comfort control, and zoning.
Warranty information: Standard 10-year parts limited warranty and a 10-year replacement compressor limited warranty.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin North America LLC, 713-861-2500; www.northamerica-daikin.com.
eProduct: 180
Serviceability features: Simple safety circuit troubleshooting with easy-access terminal board. Simplified control box arrangement. Comfort Alert™ diagnostic board includes LED screen with fault code, fault code retention logic, phase protection, built-in time guard anti-short cycle, and low-volt compressor contactor protector. High- and low-pressure switches.
Noise-reduction features: Compressor includes overload protection and vibration isolation for quiet operation.
IAQ equipment supported: As part of an installed system, this unit is compatible with a wide range of IAQ products, including filters, humidifiers, ultraviolet lights, and electronic air cleaners. Factory-installed outdoor air temperature sensor. Optional CO2 sensors can be used in conjunction with a field-installed economizer on the indoor fan coil unit to meet indoor air quality requirements.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Single-stage cooling with fully hermetic scroll compressor, crankcase heater, and suction line accumulators. For easy transport, the CHS 072-121 has a full perimeter base rail with built-in rigging adapters and fork truck slots. Durable round copper tube aluminum plate fin condenser coils. Galvanized steel cabinet with pre-painted exterior/primer-coated interior.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoDayandNight.com.
eProduct: 181
Serviceability features: Large access panels feature easy-grip handles and no-strip screw technology, while air filters are accessed through a toolless filter access door. New unit control board layout connections for easy troubleshooting in one area, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Indoor fan uses X-Vane/vane axial fan design with built-in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished return air filters are standard. Units are also available with an optional foil face insulation package. Factory and field fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Unit also available with multiple choices of electric heat sizes to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The new 5/16-inch copper round tube and aluminum plate condenser coils improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch and rotary dial. No special training is required. Units have same footprint as 30 years ago, making them ideal for replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, one-year parts. Other extended warranty packages are also available.
Special installation requirements: None. Units are a single-packaged design with many pre-engineered and certified factory options and field accessories for most geographic areas and applications.
Contact: International Comfort Products, 317-240-5133; www.GoDayandNight.com.
eProduct: 182
Serviceability features: Self-diagnostic system with easy-to-read LED error codes, which can be looked up in Fujitsu’s Mobile Technician App for step-by-step troubleshooting.
Noise-reduction features: Features 11 indoor unit styles to choose from, several featuring Quiet Mode. The outdoor unit is as low as 54 dBA.
IAQ equipment supported: Wall-mounted indoor models feature ion deodorization filters that decompose absorbed odors using the oxidizing/reducing effects of ions generated by the ultra-fine-particle ceramic and Apple-Catechin filters, which absorb fine dust, invisible mold spores, and harmful microorganisms onto the filter by static electricity, inhibiting and deactivating further growth. Three-year life expectancy. Wash to restore surface action.
Thermostat compatibility: Requires a special thermostat. Thermostat adapter kit offers connection to many of today’s popular thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The compact and slim design of the J-IIIL Series makes it ideal for low-rise and urban building designs with limited installation space. Up to 30 indoor units can be connected to the 10-ton outdoor unit. Outdoor unit high static pressure is available up to 0.24 inches of water column. Advanced refrigerant technology allows systems to reach a total refrigerant piping length of 1,312 feet.
Warranty information: Standard one-year parts and two-year compressor warranty. Systems that have been installed by a licensed contractor, properly commissioned, and registered online have a 10-year parts and compressor warranty. Systems that have been installed by an Elite contractor, properly commissioned, and registered online have a 12-year parts and compressor warranty. See warranty statement for full details.
Special installation requirements: None
Contact: Fujitsu General America Inc., 973-575-0380; www.fujitsugeneral.com.
eProduct: 183
Serviceability features: Self-diagnostic system with easy-to-read LED error codes, which can be looked up in Fujitsu’s Mobile Technician App for step-by-step troubleshooting.
Noise-reduction features: The indoor unit is as low as 24 dBA in Quiet Mode and the outdoor unit is as low as 47 dBA.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat. Using a thermostat adapter kit, the RGLX series can be connected to many of today’s popular thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: These units have enough static pressure to heat or cool a whole house. Can be installed in applications that require static pressure up to 0.80 inches of water column (12/18/24/30/36k models). Maximum piping lengths of up to 246 feet (42/48RGLXD systems). Heating operation rated down to minus 5˚F outdoor temperature. Built-in drain pump. Select two- or three-wire control via dipswitch on indoor unit. Slim and compact design of indoor and outdoor unit.
Warranty information: Standard five-year parts and seven-year compressor warranty. Systems that have been installed in residential applications by a licensed contractor, and the online product registration has been submitted, have a 10-year parts and compressor warranty. Systems that have been installed by an Elite contractor, and the online product registration has been submitted, have a 12-year parts and compressor warranty. See warranty statement for full details.
Special installation requirements: None
Contact: Fujitsu General America Inc., 973-575-0380; >www.fujitsugeneral.com.
eProduct: 184
GZS 006-072 and GZT 024-072
Serviceability features: The hinged control box swings open or removes for quick access to internal components. Electrical and water connections are conveniently located on the front corner post. Other features include front panel refrigerant test port access, removable exterior service panels, sealed air-handling compartment for setup and service during unit operation, and externally mounted desuperheater switch.
Noise-reduction features: Elastomeric compressor vibration absorption pads provide superior compressor and blower motor isolation, resulting in quiet operation. Additionally, high-density closed-cell foam insulation that’s UL Greenguard certified absorbs sound. Cabinets meet industry leakage guidelines.
IAQ equipment supported: Enertech offers a field-installed accessory filter rack that accepts 1- or 2-inch disposable pleated filters. Lifetime washable electrostatic filters or electronic air cleaners with disposable media packs are available as well. Most other air filtration, humidification, or purifier systems are compatible with all Enertech products.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Compact horizontal packaged models are field configurable for side or end discharge and feature a compact design with higher efficiencies. An all-aluminum microchannel air coil improves efficiency. Sensor-and-flow switch-protected. Compact design allows 24-inch on-center attic truss pass-through installation. This unit is available in all sizes with a braze-plate heat exchanger or a coaxial heat exchanger.
Warranty information: All internal system components of the heat pump are covered for a period of one year. Contact Enertech for more details on commercial warranty options 618-664-9010.
Special installation requirements: Manufacturer did not specify.
Contact: Enertech Global LLC, 618-664-9010; geocomfort.com.
eProduct: 185
Serviceability features: IGC solid state control for onboard diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points located in one convenient place, the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screw feature.
Noise-reduction features: Quiet and efficient operation is provided by belt-driven evaporator fans.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide demand-controlled ventilation capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified units feature two-stage cooling with independent circuits and controls. Dedicated vertical or horizontal airflow duct configuration models. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan, economizers, variable-frequency drive two-speed fan, and hot gas reheat system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized steel heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoHeil.com.
eProduct: 186
Serviceability features: Access panels with easy-grip handles provide easy access to the blower, blower motor, control box, and compressors. No-strip screw feature. Newly designed terminal board facilitates safety circuit troubleshooting and simplified control box arrangement.
Noise-reduction features: Fully insulated cabinet.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessory available for field installation to provide demand-controlled ventilation capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star-qualified units are field convertible for vertical or horizontal airflow duct configuration. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan and economizers.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoHeil.com.
eProduct: 187
Serviceability features: Easily accessible control board section. Easy-to-access filter rack.
Noise-reduction features: Insulated compressor compartment. Vibration isolators.
IAQ equipment supported: Concealed compact ceiling location. Room-side air filtration up to MERV 13.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Quiet operation, small profile, concealed design.
Warranty information: Various.
Special installation requirements: Manufacturer did not specify.
Contact: Ice Air, 877-423-2471; www.ice-air.com.
eProduct: 188
Serviceability features: Central terminal board facilitates simple safety circuit troubleshooting and simplified control box arrangement. Newly designed indoor refrigerant header for easy maintenance and replacement. Access panels with easy-grip handles provide quick access to the blower, blower motor, control box and compressor. Features no-strip screw system.
Noise-reduction features: Fully insulated cabinet reduces noise at maximum performance.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Accessory duct-mounted CO2 sensor available for field installation to provide demand-controlled ventilation capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: One-piece two-stage electric cooling with a low profile and efficient scroll compressor. Field convertible from vertical to horizontal airflow; no special kit required. Thermostatic expansion valve refrigerant metering device to precisely control refrigerant flow. Through-the-bottom power entry capability. Standard-, medium-, and high-static fan motor options.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoICPCommercial.com.
eProduct: 189
Serviceability features: Large access panels feature easy-grip handles and no-strip screw technology, while air filters are accessed through a toolless filter access door. New unit control board layout connections to easily troubleshoot in one area, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units also have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Indoor fan uses X-Vane/vane axial fan design with built-in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished return air filters are standard. Units are also available with an optional foil face insulation package. Factory and field fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multispeed motor operation. Unit also available with multiple choices of electric heat sizes to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The new 5/16-inch copper round tube and aluminum plate condenser coils improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch and rotary dial. No special training is required. Units have same footprint as 30 years ago, making them ideal for replacement.
Warranty information: Standard limited parts: five-year parts on compressor and one-year parts. Other extended warranty packages are also available.
Special installation requirements: None. Units are a single-packaged design with many pre-engineered and certified factory options and field accessories for most geographic areas and applications.
Contact: International Comfort Products, 317-240-5133; www.GoICPCommercial.com.
eProduct: 190
Serviceability features: Low operational and maintenance costs with features that include optional Mobile Access Portal, which provides remote monitoring for fewer trips to the roof; Navigator Product Service app, which puts product-specific information at the user’s fingertips; extended grease lines; accessible connections; service ports and lights; coil-cleaning hatches; disconnect switches; and condenser safety tie-off.
Noise-reduction features: Sound outputs are minimized with sound attenuator and compressor sound blanket options.
IAQ equipment supported: Modulating hot gas reheat option; final filtration options, including HEPA filters; ultraviolet lights option; stainless steel drain pan; condensate overflow switch option; airflow measurement options for outside air, supply fan, and return fan.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Additional options are available to meet the Consortium for Energy Efficiency 2019 highest tier ratings. Available modulating options further improve energy gains including compressors, energy recovery wheels, and gas and electric heat. The result is a significant cost-savings over the life of the unit.
Warranty information: One-year parts and either a six-month or one-year promotional labor warranty when started by a certified contractor.
Special installation requirements: Flexibility in airflow path configuration making installation in different scenarios easier.
Contact: Johnson Controls Inc., 888-231-2291; www.johnsoncontrols.com/NexusPremier.
eProduct: 191
Serviceability features: Self-diagnostics. Pre-charged glycol lines. Quick-connect glycol fittings. Single-point power supply.
Noise-reduction features: Quiet operation provides conditioned air to commercial offices, server rooms, and more.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Built-in thermostat
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Self-contained water-cooled refrigeration circuit with integral controls, fluid pump, condensate pump, and glycol reservoir. A remote fluid cooler outdoor unit is provided with 25-feet of water line/power line. A single-source power supply located on the indoor unit provides power for the remote fluid cooler. The units are ideal for areas where typical air-cooled units cannot be used.
Warranty information: Three-year compressor, two year parts.
Special installation requirements: These new a/c units offer ease of installation for temporary or permanent installations.
Contact: Koldwave, 413-564-5520; www.koldwave.com.
eProduct: 192
ARUM***BTE5
Serviceability features: Easy to service with onboard self-diagnostics. Periodic indoor unit filter changes and annual outdoor unit coil cleaning. Additionally, the Mobile LGMV is available to enable users to easily visualize system performance in a convenient and intuitive platform on their smartphones.
Noise-reduction features: Features a new biomimetic fan design that enables the unit to operate efficiently and increase airflow while reducing the perceived noise level by approximately 20 percent.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Operates in ambient conditions down to minus 22°F. Comes with exclusive LG features such as Advanced Smart Load Control and Comfort Cooling intelligence, which measure ambient air humidity and temperature to monitor changing weather conditions in real time.
Warranty information: Standard one-year parts warranty for a qualified system. Extended warranties are available for qualified systems. For complete warranty details, visit lghvac.com.
Special installation requirements: Manufacturer did not specify.
Contact: LG Electronics, Air Conditioning Technologies, 562-243-4925; www.lghvac.com.
eProduct: 193
Serviceability features: Easy to service and requires little maintenance.
Noise-reduction features: Uses a variable-speed compressor.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Featuring a compact and lightweight design and only requiring single-phase power, this 5-ton heat recovery system is ideal for light commercial installations, providing excellent energy efficiency and the versatility of simultaneous heating and cooling. Equipped with automatic changeover between heating and cooling modes, the system allows for the effortless control of user comfort, while also providing a viable heat recovery solution for property owners, even in the most extreme weather.
Warranty information: A standard limited liability warranty is five-year parts and seven-year compressor. Qualifying systems registered through lg.com will receive 10-year parts and 10-year compressor warranty. LG Excellence Contractors who register qualifying systems on lg.com will receive 12 years for the parts and compressor.
Special installation requirements: A heat recovery unit is required for simultaneous heating and cooling operation.
Contact: LG Electronics Inc., 562-243-4925; www.lghvac.com.
eProduct: 194
Serviceability features: The new four-sided heat exchanger reduces overall unit size, delivering application flexibility and performance improvements. In addition, the latest branch circuit (BC) controllers, for use with heat recovery systems, feature a height reduction and service access from the bottom.
Noise-reduction features: The introduction of five airflow settings, along with a redesigned compressor and fan, reduce noise levels across all models. The outdoor unit operates down to 56.5 dBA.
IAQ equipment supported: Outdoor units are compatible with METUS indoor units equipped with multipart filtration systems to reduce contaminants such as allergens, viruses, and bacteria. N-Generation is also compatible with the PremiSys® DOAS, which provides conditioned ventilation air.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: N-Generation increases design freedom with an up to 30 percent smaller footprint and greater vertical separation between the indoor and outdoor units. Expanded vertical piping limits (from 164 to 295 feet) and redesigned BC controllers that can connect up to 11 sub BC controllers. Refrigerant volume is reduced by up to 13 percent, compared to L-Generation. The units also feature a 27 percent IEER improvement over prior generations.
Warranty information: The parts are warrantied to the original owner for a period of one year, and the compressor is warrantied for a period of seven years from the date of installation if installed by a licensed contractor. The parts and compressor will be warrantied for a period of 10 years to the original owner if the system is designed by a Diamond Contractor® using the Diamond System Builder™.
Special installation requirements: Manufacturer did not specify.
Contact: METUS, 703-797-7107; www.nextgenvrf.com.
eProduct: 195
Serviceability features: Optional external port to access the unit’s controls using a remote user interface module without powering down the unit. Intuitive user interface to access unit operating characteristics and set point adjustment. Controls developed and supported by Modine Controls Engineers, not third-party companies. Compatible with all major building management systems, such as BacNET and LonWorks.
Noise-reduction features: Single and dual, direct-drive, backward-curved plenum fans (with airfoil option) make for efficient operation with low sound levels and minimal maintenance.
IAQ equipment supported: The Atherion D-Cabinet, now available in 52 and 60 ton capacities, effectively and efficiently heats, cools, and dehumidifies high volumes of outside air to provide high IAQ.
Thermostat compatibility: Can be integrated easily into building management systems.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Designed for ease of installation, energy efficiency, and durability, the system provides a state-of-the-art solution for dehumidification and ventilation needs. The Atherion offers a gas-fired heating option of up to 94 percent efficiency, thanks to proven Conservicore® technology. Refrigeration circuit includes modulating tandem digital scroll compressors, PF™ microchannel condenser coils, variable-speed condenser fan, head pressure controls, and a modulating hot gas reheat coil.
Warranty information: Standard unit warranty is two years for most parts and extended for compressors: Extend to a total of five years from date of first beneficial use by buyer or any other user within five years from date of resale by buyer in any unchanged condition, or within 66 months from date of shipment from seller, whichever occurs first.
Special installation requirements: Special instructions are in the install manual.
Contact: Modine, 262-636-1318; www.modinehvac.com.
eProduct: 196
Serviceability features: The scroll compressors have logged hundreds of thousands of operating hours in numerous different applications. The corrosive-resistant condenser heat exchangers have been specifically designed for stationary HVAC applications and have undergone extensive laboratory and field testing to extend chiller life and improve performance.
Noise-reduction features: Equipped with specially designed fans and motors to provide lower sound levels while retaining appropriate airflow. The fans are three-bladed for 60 Hz and five-bladed for 50 Hz.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Unit is available with variable-speed fans and pumps to increase efficiency, reducing energy consumption and sound at part-load conditions.
Warranty information: Quantech shall warrant all equipment and material of its manufacture against defects in workmanship and material for a period of 18 months from date of shipment or 12 months from date of startup, whichever occurs first.
Special installation requirements: The chiller arrives as a factory-assembled package, ready to be installed outdoors, either on the roof or at ground level. The air-cooled condensers eliminate the capital, installation, and maintenance costs of a cooling-tower circuit. Power hookup features a standard single-point connection.
Contact: Johnson Controls, 717-771-6133; www.quantech-hvac.com/.
eProduct: 197
Serviceability features: Display-driven test mode, direct-drive supply fan, hinged-door access for all compartments, digital scroll diagnostic system, gas ignition diagnostic system, terminal connections for sealed devices, and DDC unit alarm functionality.
Noise-reduction features: Low noise, electronically commutated supply fan motor, and foam panel construction.
IAQ equipment supported: Dehumidification control and 100 percent outside air capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: DOAS unit that fits on an industry common roof curb with patented hot gas reheat technology.
Warranty information: Two-year all parts, five-year compressor, 10-year heat exchanger.
Special installation requirements: None.
Contact: Nortek Global HVAC, 800-422-4328; www.nortekhvac.com.
eProduct: 198
Serviceability features: External gauge ports, slide-out/blower section, and slide-out drain pan. Patented easy-access filter system to allow 2- and 4-inch filters.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: This commercial package heat pump features a microchannel indoor coil and condenser coil technology.
Warranty information: One-year warranty parts, five-year warranty compressor.
Special installation requirements: Manufacturer did not specify.
Contact: Rheem, 800-621-5622; www.rheem.com.
eProduct: 199
Serviceability features: Mobile Access Portal provides remote monitoring for fewer trips to the roof. The Navigator Product Service app puts product-specific information at the user’s fingertips. Smart equipment-ready; extended grease lines; accessible connections; service ports and lights; coil-cleaning hatches; disconnect switches; and condenser safety tie-off.
Noise-reduction features: Sound attenuator and compressor sound blanket options minimize sound outputs.
IAQ equipment supported: A stainless steel evaporator drain pan provided for longevity. The drain pan can be optionally equipped with an overflow switch to minimize the potential for damage to the conditioned space. Ultraviolet light banks are also an available option that minimize mold and bacteria growth and assists in keeping the evaporator coil clean. Modulating hot gas reheat, final filtration, and airflow measurement options further enhance IAQ capabilities.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Integrated selection tools with BIM files, smart equipment controls with a full array of user-adaptable parameters, and optional remote monitoring capabilities deliver improved performance and design flexibility to reduce operational costs.
Warranty information: One-year parts and either a six-month or one-year promotional labor warranty when started by a certified contractor.
Special installation requirements: Flexibility in airflow path configuration offers easier installation in a wide array of scenarios.
Contact: TempMaster, 888-231-2291; www.tempmaster-hvac.com/omnipremier.
eProduct: 201
Serviceability features: Comfort Alert™ diagnostic board includes LED screen with fault code, fault code retention logic, phase protection, built-in time guard anti-short cycle, and low-volt compressor contactor protector. Easy-access control box arrangement. Simple safety circuit troubleshooting with newly designed terminal board. Simplified control box arrangement. High- and low-pressure switches.
Noise-reduction features: To minimize sound at maximum performance, the compressor includes vibration isolation and overload protection.
IAQ equipment supported: As part of an installed system, this unit is compatible with a wide range of IAQ products, including filters, humidifiers, ultraviolet lights, and electronic air cleaners. Factory-installed outdoor air temperature sensor. Optional CO2 sensors can be used in conjunction with an optional economizer to meet IAQ requirements.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Superior two-stage cooling. Fully hermetic scroll compressor, crankcase heater, and suction line accumulators. Filter drier standard. Full perimeter base rail with built-in rigging adapters and fork truck slots for easy transport. Galvanized steel cabinet with pre-painted exterior/primer-coated interior. Durable round copper tube aluminum plate fin condenser coils.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-240-5133; www.GoTempstar.com.
eProduct: 202
Serviceability features: Large access panels feature easy-grip handles and no-strip screw technology, while air filters are accessed through a toolless filter access door. New unit control board layout connections to easily troubleshoot in one area, plus simple fan adjustments are made to the electronically commutated motor by setting DC voltage through an intuitive switch and rotary dial. Units also have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Indoor fan uses X-Vane/vane axial fan design with built-in ramp-up speed technology to soften the sound experienced during startup. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory-furnished return air filters are standard. Units are also available with an optional foil face insulation package. Factory and field fresh air economizers with capability for demand control ventilation. Economizers use fault-detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation. Unit also available with multiple choices of electric heat sizes to match particular climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The new 5/16-inch copper round tube and aluminum plate condenser coils improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch and rotary dial. No special training is required. Units have same footprint as 30 years ago, making them ideal for replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, one-year parts. Other extended warranty packages are also available.
Special installation requirements: None. Units are a single-packaged design with many pre-engineered and certified factory options and field accessories for most geographic areas and applications.
Contact: International Comfort Products, 317-240-5133; www.GoTempstar.com.
eProduct: 203
Serviceability features: Transverse open V design condenser coils allow easy cleaning of the condenser coils from the inside out, to keep the coils and the chiller properly functioning. Maintenance-free, long-life motors — condenser fans are powered by variable-speed, permanent magnet motors that require no periodic maintenance and are designed for long operational life.
Noise-reduction features: Chillers offer flexible acoustic options, allowing customers to choose the level of sound treatment that best meets any application requirements. These units are ideal for residential or school environment where sound sensitivity are top priorities. Sound packages offer sound power levels as low as 95 dBA at Air-Conditioning, Heating and Refrigeration Institute (AHRI) conditions for full-load operations.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Variable volume ratio scroll compressor, electronically commutated fan motor.
Warranty information: Standard one-year parts. Up to 10-year parts, labor, and refrigerant extended warranties.
Special installation requirements: Manufacturer did not specify.
Contact: Trane, 651-587-6007; www.trane.com/ascend.
eProduct: 204
Serviceability features: Manufacturer did not specify.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Double-wall cabinet with foam-injected insulation. Double-sloped evaporator coil drain pan prevents standing water, eliminating harmful bacterial growth. Direct-drive and variable-speed fans have no belts or sheaves to maintain for clogged filters. Outside air intake is always at least 36 inches from the bottom of the base rail.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Application-specific and field-programmable controller reduces project costs and enables customized sequences of operation. Adaptive Controls™ avoid potential equipment disruptions during rapidly changing conditions. Enables remote connectivity to monitor, analyze, and maximize a building’s performance. Simplified integration with all common standard protocols. Upgraded variable-speed technology matches cooling demand to both compressor and direct-drive fan performance and delivers an IEER up to 17.8.
Warranty information: Standard warranty for a period of 12 months from initial startup or 18 months from date of shipment. A 10-year limited warranty is provided on all stainless steel gas heat exchangers. A five-year limited warranty is provided on optional zero to 100 percent economizer. Extended warranties are available for compressors.
Special installation requirements: None
Contact: Trane, 931-648-5248; www.trane.com/commercial/north-america/us/en.html.
eProduct: 205
Serviceability features: No refrigerant lines to run. Ease of installation, easy compressor change-out (no brazing required). Multiple filter options.
Noise-reduction features: Two-inch insulation, double-wall construction, compressor acoustic cover, electronically commutated blower motors, and a noise criterion of less than 40.
IAQ equipment supported: Yes.
Thermostat compatibility: Built-in controls are standard.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Variable air volume, 00 to 500 cfm, energy recovery wheel and cross-flow heat exchanger, horizontal and vertical configurations, easy installation, low power consumption, factory tested.
Warranty information: Limited five-year compressor warranty (labor not included), limited one-year parts warranty (labor not included).
Special installation requirements: Manufacturer did not specify.
Contact: United CoolAir Corp., 717-843-4311; www.unitedcoolair.com.
eProduct: 206
Serviceability features: A cleanable nylon filter is included. Cleaning is recommended every three months. Regular inspection is suggested.
Noise-reduction features: Noise reduction occurs at part-load through variable-speed compressors and variable-speed fans.
IAQ equipment supported: The VRC is used primarily in small IT spaces where people are not present.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Vertiv™ VRC 100 Series rack cooling system is self-contained, designed specifically for cooling mission-critical IT equipment in small server rooms, network closets, and edge computing spaces. The rack-mounted VRC saves valuable floor space, providing up to 3.5 kW IT cooling. Variable-speed components enable efficient scaling with changing IT loads. It can reject heat to the ceiling or an adjacent space. Remote monitoring connects to BMS and a plug-in SNMP card allows for network monitoring.
Warranty information: One-year whole unit replacement warranty is standard with extended warranty available as an option.
Special installation requirements: Easy to handle and under 150 pounds, the unit fits within standard 19-inch network rail racks. It includes an integrated heat rejection system, is pre-charged with refrigerant, and offers plug-and-play installation. A heat rejection duct kit is provided. A 24-by-24-inch ceiling grille and 24-by-24-by-1-inch filter are provided for makeup air to the room.
Contact: Vertiv, 614-841-6700; www.vertivco.com.
eProduct: 207
Serviceability features: Advanced Aurora controls monitor electrical consumption of the compressor and fan, providing continuous data to detect potential service issues prior to a failure. Along with the electronic expansion valve, the Aurora controls also monitor the refrigeration circuit, providing both temperatures and pressures for simplified diagnostics and eliminating the need for manual gauges.
Noise-reduction features: Direct-drive electronically commutated fan motors with soft-start and inverter-driven scroll compressors. The fully insulated cabinet and a high-density compressor sound blanket further provide sound attenuation.
IAQ equipment supported: The foil-lined insulation allows for easy cleaning of internal panel surfaces. An optional MERV-13 air filter provides superior air filtration down to particles of 1 micron in average size. The optional Aurora UPC controls are available with factory-programmed demand control ventilation sequences.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Variable capacity allows the Versatec VS units to match the load of the space for precise temperature and humidity control. Featuring an inverter-driven DC motor scroll compressor to provide capacity modulation between 25 and 100 percent, outstanding efficiencies are achieved at part-load conditions. Aurora advanced controls provide continuous monitoring of energy and refrigerant performance. Direct-drive electronically commutated fan motors allow up to six individual comfort zones to be served by a single unit.
Warranty information: Standard one-year from installation, but optional extended warranties are available to extend coverage for up to five years.
Special installation requirements: Units can be installed on any conventional condenser water or geothermal ground loop. Aurora controls provide seamless integration with BACnet or LonWorks building automation networks. Factory-sealed and -optimized refrigeration circuits reduce installation costs and minimize the amount of refrigerant in the building.
Contact: WaterFurnace International, 260-478-5667; www.waterfurnace.com.
eProduct: 208
Serviceability features: Compact cabinet design with quick access for ease of service. Horizontal units can be serviced through the unit bottom to virtually eliminate removing ceiling-mounted units for service.
Noise-reduction features: Provided as standard, the unit has a dual-level vibration isolation system. A heavy-gauge mounting plate is isolated from the cabinet via a dense neoprene pad to minimize vibration transfer. The compressor is then isolated from the mounting plate with standard rubber-in-shear isolators to enhance the dual-level vibration isolation. The compressor is located in a well-insulated compartment, separated from the airstream to minimize sound transmission.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Capacities ranging from .5 to 5 tons, with single-stage EERs up to 17 (water loop). With optional hot gas reheat for temperature and humidity control, as well as hybrid heating and cooling, the CAS Series has flexibility over a wide range of applications.
Warranty information: Standard one-year warranty on compressor and parts. Extended five-year warranty is optional.
Special installation requirements: Manufacturer did not specify.
Contact: The Whalen Co., 410-822-8200; www.whalencompany.com.
eProduct: 209
Serviceability features: Inner service panel is removable for access to the unit control wiring and internal piping. The acoustical panel has a flush-mounted design with a hinged door to allow easy filter removal without the use of tools. Lift-out stainless steel pan with P-trap covers the entire unit bottom and can be easily removed for cleaning.
Noise-reduction features: High-efficiency electronically commutated motor has constant torque fan motor for low sound levels and quiet operation. Floating compressor design and cabinet isolation pad to minimize vibration transmission. Water hoses connect to the supply and return water piping, which isolates potential compressor vibration from the building piping system.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts. Shares replacement parts with other models.
Additional features: The first and only two-stage vertical stack water-source heat pump.
Warranty information: Cabinet carries a 15-month warranty, chassis carries a one-year warranty, compressor carries a five-year warranty, and the refrigeration circuit carries a five-year warranty.
Special installation requirements: Manufacturer did not specify.
Contact: The Whalen Co., 410-822-8200; www.whalencompany.com.
eProduct: 210
Serviceability features: Rooftop units are engineered for simplified serviceability to lower the life cycle costs of the unit. Optional features include Mobile Access Portal (MAP), which provides remote monitoring for fewer trips to the roof and Navigator Product Service app, which puts product-specific information at the user’s fingertips; extended grease lines; accessible connections; service ports and lights; coil-cleaning hatches; disconnect switches; and condenser safety tie-off.
Noise-reduction features: Sound attenuator and compressor sound blanket options minimize sound outputs.
IAQ equipment supported: Double-wall construction with foam insulation; modulating hot gas reheat option; final filtration options, including HEPA filters; ultraviolet lights option; stainless steel drain pan; condensate overflow switch option; and airflow measurement options for outside air, supply fan, and return fan.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Integrated selection tools with BIM files. Smart Equipment controls with a full array of user-adaptable parameters and seamless integration with leading building controls systems, such as Verasys.
Warranty information: One-year parts and either a six-month or one-year promotional labor warranty when started by a certified contractor.
Special installation requirements: SunPremier offers flexibility in airflow path configuration, making installation in different scenarios easier.
Contact: York, 888-231-2291; www.york.com/SunPremier.
eProduct: 211
Serviceability features: Isolation valves on the suction and discharge of the solution and refrigerant pumps allow quick and easy servicing of pumps, which typically have a 60,000-hour life. The chiller also offers a control center with a graphical animated LCD display, allowing the user to review present and past operational status, data recording, and chiller safeties.
Noise-reduction features: Manufacturer did not specify.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: This absorption chiller uses an innovative two-step evaporator-absorber/parallel flow design, enabling a lower lithium bromide salt concentration, requiring less energy input. This results in increased reliability and energy efficiency compared to conventional absorption models.
Warranty information: Chillers are supported by an extensive parts and service network, with over 100 locations in the U.S.
Special installation requirements: Manufacturer did not specify.
Contact: Johnson Controls Inc., 717-771-6133; www.johnsoncontrols.com/hvac-equipment/chillers.
eProduct: 212
Back to gallery
Publication date: 5/6/2019
Want more HVAC industry news and information? Join The NEWS on Facebook, Twitter, and LinkedIn today!
