The ACHR NEWS is featuring the industry’s latest commercial cooling products for summer 2022. The manufacturers provided The ACHR NEWS with the brief description of features included with each product. For more information, please contact the manufacturers or their distributors.
The Cooling Showcase is split into two parts — commercial and residential. This year’s Residential Showcase was published on April 25, 2022.
Included below is the product chart, which includes technical facts, such as unit tonnage, refrigerant type, efficiency rating, and cooling capacity.
![AAON EcoFit Heat Pump](/ext/resources/2022/05-May/AAON-EcoFit-Heat-Pump.jpg)
Serviceability features: Removeable panels provide service access to the controls, compressor, and supply fan. Vertical configuration unit’s fan can be field converted between side and end discharge. Vertical configuration unit includes integrated condensate p-trap within the cabinet that eliminates need for housekeeping pad. High condensate level sensor is standard for indicating a higher-than-normal condensate level in the drain pan.
Noise-reduction features: Compressors are mounted with isolation for reduced vibration. Sturdy galvanized steel construction with sound-absorbing fiberglass insulation. Floating threaded condensate water connections reduce sound. Hanging brackets include factory-provided rubber-in-shear vibration isolation.
IAQ equipment supported: Up to 4-inch MERV 14 pleated filters are available. Sloped, stainless steel drain pan includes automated TIG and induction welding to ensure positive drainage and microbial growth prevention.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: EcoFit water-source heat pumps are designed to address the unique needs of the new construction market. The units feature a wide array of selectable options to allow design engineers and owners to optimize the equipment required to address unique building requirements and provide excellent efficiency.
Warranty information: Standard five-year parts warranty from date of installation.
Special installation requirements: None.
Contact: AAON, 918-583-2266; www.aaon.com.
eProduct: 160
![AAON ProFit Heat Pump](/ext/resources/2022/05-May/AAON-ProFit-Heat-Pump.jpg)
Serviceability features: ProFit water-source heat pumps are a drop-in replacement for most existing water-source heat pumps. Vertical configuration unit’s fan can be field converted between side and end discharge. Vertical configuration unit includes integrated condensate p-trap within the cabinet that eliminates need for housekeeping pad. High condensate level sensor is standard for indicating a higher-than-normal condensate level in the drain pan. Removeable panels provide service access to the controls, compressor, and supply fan.
Noise-reduction features: Compressors are mounted with isolation for reduced vibration. Sturdy galvanized steel construction with sound-absorbing fiberglass insulation.
Floating threaded condensate water connections reduce sound. Hanging brackets include factory provided rubber-in-shear vibration isolation.
IAQ equipment supported: Fiberglass and pleated filters selectable. Sloped, stainless steel drain pan includes automated TIG and induction welding to ensure positive drainage and microbial growth prevention.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: ProFit replacement water-source heat pumps are designed to be a drop-in replacement for most existing water-source heat pumps. ProFit allows owners and service contractors to provide a feature-rich replacement unit for most competitive models. This reduces the need to rely on overpriced exact replacements simply because they fit the space.
Warranty information: Standard five-year parts warranty from date of installation.
Special installation requirements: None
Contact: AAON, 918-583-2266; www.aaon.com.
eProduct: 161
![Addison PR Series Dessicant System](/ext/resources/2022/05-May/Addison-PR-Series-Dessicant-System.jpg)
Serviceability features: Hinged access doors provide easy access to the inner components. Finger-Save electrical connections and components. Optional 4-, 7-, or 10-inch touchscreen equipment interface.
Noise-reduction features: Two-inch double-wall foam insulated construction.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: The new desiccant option for the PR Series adds increased flexibility for applications that require ultra-low dewpoint air. Precise leaving air temperature and dewpoint control. Complete modulation operation from the speed of the desiccant wheel, to regeneration air, to compressor and supply air blower. Typical applications include retail grocery, laboratories, process control, and many others.
Warranty information: One-year all parts, five-year compressor. Optional extended warranties available.
Special installation requirements: Manufacturer did not specify.
Contact: Addison, 918-557-5828; www.addison-hvac.com.
eProduct: 162
![Airquest PGR5 QuietComfort Rooftop Unit](/ext/resources/2022/05-May/Airquest-PGR5-QuietComfort-Rooftop-Unit.jpg)
16 packaged gas/electric rooftop
Serviceability features: Installed easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll® compressor, designed to operate most of the time in the quieter, lower stage. Also includes a two-stage heating system that offers similar comfort benefits in the heating mode. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Dehumidification mode (airflow reduction) standard on all models. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units feature two-stage heating and cooling operation, stainless steel tubular heat exchangers, field-convertible airflow, and high-efficiency ECM indoor blower motors. With cooling efficiencies up to 16 SEER and 12.5 EER, the PGR5 packaged units are Energy Star qualified.
Warranty information: Ten-year limited warranty on heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.goairquest.com.
eProduct: 163
![Airquest RGH 181-303 Rooftop Unit](/ext/resources/2022/05-May/Airquest-RGH-181-303-Rooftop-Unit.jpg)
Serviceability features: IGC solid-state control for on-board diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points located in one convenient place: the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screw feature.
Noise-reduction features: Fully insulated cabinet with isolated scroll compressors and rigidly mounted indoor fan system.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessor available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Features two-stage cooling with independent circuits and controls. Dedicated vertical or horizontal airflow duct configuration models. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan, economizers, variable-frequency drive two-speed fan, and hot gas reheat system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized steel heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.goairquest.com.
eProduct: 164
![Allied Commercial MagicPak Rooftop Unit](/ext/resources/2022/05-May/Allied-Commercial-MagicPak-Rooftop-Unit.jpg)
Packaged rooftop, HWC (gas/electric) and EWC (electric/electric)
Serviceability features: Ease-of-service features are built into the unit and include forward-facing components along with a slide-out cooling chassis and time-saving single screw attachment of igniter and rollout switch.
Noise-reduction features: Rubber isolation mount dampers on the compressor and insulated cabinet design. Plastic vibration base pan to assist with noise reduction.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: MagicPak All-In-One V-Series provides value for multifamily living by shedding the constraints of traditional split systems, with expanded design freedom and faster installation. The 1-ton 13 SEER models with up to 95% AFUE gas heating with electric cooling arrive at the jobsite factory-tested and ready to install. There’s no charging or line sets to run, no outdoor units, no refrigerant lines, no external flue or combustion air, and no additional outdoor power supply requirements.
Warranty information: Five-year limited parts warranty on the stainless-steel exchanger.
Special installation requirements: Manufacturer did not specify.
Contact: Allied Air Enterprises, 800-448-5872; www.allied-commercial.com.
eProduct: 165
![Allied Commercial Q-Series Unit](/ext/resources/2022/05-May/Allied-Commercial-Q-Series-Unit.jpg)
Three-phase packaged rooftops, QGA (gas/electric), QCA (electric/electric), and QHA heat pump (208/230-V and 460-V models)
Serviceability features: Easy access to all components with quick-connect electrical connections. Brass service valves on the liquid and discharge lines.
Noise-reduction features: Quiet combustion technology. Low gas pulses during compression reduce operational sound levels. Muffler in discharge line reduces operating sound levels. Conditioned areas insulated with foil-faced insulation to reduce operating sound levels.
IAQ equipment supported: None.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Q-Series units were specifically engineered to accommodate both horizontal and downflow applications with plug-and-play designs that install quickly and easily even when replacing different brands. With a variety of time-saving features (including no need for riggings and brackets) it’s ready for installation when it arrives at the jobsite. It also features side and bottom connection entrances, quick-connect electric connections, and factory-installed float switch.
Warranty information: Ten-year limited warranty for the aluminum gas heat exchanger; five-year limited warranty for the compressor; and one-year limited warranty on additional covered components.
Special installation requirements: Manufacturer did not specify.
Contact: Allied Air Enterprises, 800-448-5872; www.allied-commercial.com.
eProduct: 166
![Arcoaire RGH 181-303 Rooftop Unit](/ext/resources/2022/05-May/Arcoaire-RGH-181-303-Rooftop-Unit.jpg)
Serviceability features: IGC solid-state control for on-board diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points located in one convenient place: the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screw feature.
Noise-reduction features: Fully insulated cabinet with isolated scroll compressors and rigidly mounted indoor fan system.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessor available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Features two-stage cooling with independent circuits and controls. Dedicated vertical or horizontal airflow duct configuration models. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan, economizers, variable-frequency drive two-speed fan, and hot gas reheat system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized steel heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.goarcoaire.com.
eProduct: 167
![Arcoaire RHV036-072 Heat Pump](/ext/resources/2022/05-May/Arcoaire-RHV036-072-Heat-Pump.jpg)
With X-Vane™ fan technology
Serviceability features: New unit control board puts all connections and troubleshooting points in one convenient location. Most low-voltage connections can be made to the same easy-access board. Large control box provides room to work and easily mount accessories. An intuitive switch and rotary dial arrangement make configuration of the fan settings simple. Field-convertible to horizontal airflow for installation flexibility.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor/outdoor fan systems. Indoor fan uses X-Vane/Vane Axial fan design with built-in, ramp-up speed technology to soften sound during startup. Lightweight, high-impact composite fan blade on the outdoor fan system minimizes sound. X-Vane units have an acoustic dBA of 79 (by comparison the dial tone on a phone has a dBA of 80).
IAQ equipment supported: Factory and field fresh air economizers with capability for demand control ventilation. Economizers use fault detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation. Horizontal economizers are available as an accessory only.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: X-Vane fan technology indoor fan system uses less energy and has 75% fewer moving parts than traditional belt drive systems. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. New 5/16-inch round copper tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Units have the same footprint as 30 years ago, making them ideal for replacement. No special training required.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Up to five-year extended parts warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: Vane Axial fans always spin in the correct direction. Installers should perform a proper startup, including: checking three-phase compressors to ensure that they are phased correctly and measuring temperatures/pressures at startup to ensure the compressor is pumping. If the installer cannot check the cooling operation at startup (i.e., winter startup), then the cooling function should be disabled until the installer can return and complete proper startup.
Contact: International Comfort Products, 317-481-5744; www.goarcoaire.com.
eProduct: 168
![Bard MEGA-TEC Air Conditioner](/ext/resources/2022/05-May/Bard-MEGA-TEC-Air-Conditioner.jpg)
Serviceability features: Hinged service door, roll-out condenser fan assembly, PLC diagnostics for troubleshooting, exterior service port access, dirty filter light indicator, easy-to-clean condenser coils, and Modbus interface and remote access web page, Bard Link™. All service and maintenance performed outside the building, consuming no interior floor space.
Noise-reduction features: ECM variable indoor and outdoor fan.
IAQ equipment supported: Up to MERV 13 indoor air filters; can control external humidifier; emergency shut off; and emergency ventilation.
Thermostat compatibility: Requires a PLC controller.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: A multistage, high-capacity, sensible, cooling air conditioner designed to be a slide-in replacement for retrofit applications. AHRI certified and meets state and national codes. Operates remotely via BardLink technology, leverages favorable weather conditions with optional free cooling economizer, and incorporates electric reheat dehumidification as an optional feature. Bard controller can control up to 14 wall-mount units.
Warranty information: Five-year parts refrigeration components
Special installation requirements: None.
Contact: Bard Mfg. Co., 419-636-1194; www.bardhvac.com.
eProduct: 169
![Bosch QV Series Heat Pump](/ext/resources/2022/05-May/Bosch-QV-Series-Heat-Pump.jpg)
Serviceability features: The blower systems on the QV’s horizontal cabinets are designed to be easily reconfigured on the job site. Installers can switch the blower discharge arrangement from end to straight through discharge in just a few minutes.
Noise-reduction features: The QV comes equipped with Bosch-patented compressor encapsulation. The unit’s unique sound package includes an insulated blower and cabinet insulation, which dampen unwanted noise. The product also includes an elevated base-plate, ensuring air-tight encapsulation around the compressor and optimal sound performance. Its DEC Star® blower produces the same cfm as the preceding LV model but at a lower rpm, resulting in decreased power consumption, lower sound levels, and optimal sound performance.
IAQ equipment supported: All QV series units can be configured with a MERV 8 or a MERV 13 filter.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The QV Series is an industry leader in sound performance, with an overall sound rating of 53 dB. It is also small, making it an ideal fit for condo retrofit projects or new construction. To optimize sound performance in the small cabinet, Bosch engineers upgraded the fan to the newest technology — the highly-efficient DEC Star blower — and targeted the compressor with Bosch-patented noise insulation technology.
Warranty information: Five-year compressor and one-year parts warranty.
Special installation requirements: Nothing out of the ordinary is required. The process for installing the QV is the same as for standard Bosch water-source heat pumps.
Contact: Bosch Thermotechnology Corp., 781-488-8693; www.bosch-thermotechnology.us/us/en.
eProduct: 170
![Carrier WeatherExpert Rooftop Unit.](/ext/resources/2022/05-May/Carrier-WeatherExpert-Rooftop-Unit.jpg)
Serviceability features: Large access panels feature easy-grip handles. Innovative, easy starting, no-strip screw feature on unit access panels, toolless filter access door. Units have corrosion-resistant, internally sloped, self-draining condensate pan.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, prop condenser fans, and rigid base rails. Indoor motor speed controller by VFD to make sure fan operates at system optimized speed. Also has speed ramp up capability.
IAQ equipment supported: Factory-furnished air filters, standard with economizer, and option for CO2 sensing capabilities. Supply air temperature sensor to provide optimum in comfort to the remote multi zone terminals.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: With IEER up to 21, this unit provides multi-zone VAV operation down to 6-ton size models in cooling only, cooling with gas heat, or electric heat. Unit also provides plug/play integration with i-Vu open terminal controllers for better linkage and system commissioning. Unit uses supply air temperature sensor and duct static sensor, which are factory furnished.
Warranty information: Ten-year parts on aluminum gas heat exchanger and 15-year stainless steel gas heat exchanger option. Five-year parts only warranty on compressors and electric heat, and one-year all other parts. Optional extended protection programs are available.
Special installation requirements: Units require the use of Carrier zone terminal controls to provide comfort control and ease of system commissioning.
Contact: Carrier, 571-453-8636; www.corporate.carrier.com.
eProduct: 171
![Carrier WeatherExpert Packaged Rooftop Unit](/ext/resources/2022/05-May/Carrier-WeatherExpert-Packaged-Rooftop-Unit.jpg)
With Ecoblue technology, 48FC
Serviceability features: Slide-out indoor blower/motor assembly with large access panels and easy grip handles. New unit control board helps easily troubleshoot in one area, plus simple fan adjustments are made to the ECM by setting DC voltage through an intuitive switch and rotary dial design. The use of SystemVu controls increases service and diagnostic capabilities with more than 100 alarm codes that are displayed on a large backlit multi-line text key pad.
Noise-reduction features: Indoor fan uses Vane Axial fan design with Ecoblue technology with built-in ramp-up speed technology to soften the sound experienced by other traditional systems during startup. Fully insulated cabinet, isolated scroll compressors, and balanced indoor and outdoor fan systems. Units are built on a rigid base pan and base rail design to ensure original design is maintained.
IAQ equipment supported: Factory- and field-installed fresh air economizers with the capability for demand control ventilation and free cooling. Economizers use fault detection diagnostic (FDD) controls to ensure operation and control ventilation air at multi-speed motor operation. Factory-furnished air filter with factory upgrade to 4-inch MERV 13 filters are available. Unit also available with multiple choices of gas heat sizes to match particular climate zones and applications. Units also have corrosion-resistant, internally sloped, self-draining condensate pan.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Manufacturer did not specify.
Additional features: Vane Axial indoor fan system has 75% fewer moving parts than traditional belt drive systems and uses less energy. The new reliable 5/16-inch copper round tube and aluminum plate condenser coils helps improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. No special training is required. Units have same footprint as 30 years ago, making them ideal for replacement.
Warranty information: Standard limited parts: 10-year aluminum gas heat exchanger (15-year with stainless steel), five-year parts on compressor, three-year SystemVu controls, and one-year parts. Other extended warranty packages are also available.
Special installation requirements: There are no special installation requirements. The units are a single packaged design with many pre-engineered and certified factory options and field accessories to most geographic areas and applications.
Contact: Carrier, 571-453-8636; www.corporate.carrier.com.
eProduct: 172
![Comfort-Aire/Century Heat Pump](/ext/resources/2022/05-May/Comfort-Aire-Century-Heat-Pump.jpg)
HBH/HBV006 - HBH/HBV060
Serviceability features: Multiple panels available for removal to allow for easy access to all components of this series for easy maintenance or the replacement of parts.
Noise-reduction features: Optional ultra-quiet addition, compressor
sound blanket.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Available waterside economizer. ECM motor. Quiet operation. Heavy duty compressors. Compact size. Optional extended range refrigerant cycle.
Warranty information: Five-year compressor, one-year parts.
Special installation requirements: With all water-source heat pumps, there are multiple advantages and options for the installation. The IOM outlines these options.
Contact: MARS/Heat Controller, 517-787-2100; www.marsdelivers.com.
eProduct: 173
![Comfortmaker CHS 072-121 Heat Pump](/ext/resources/2022/05-May/Comfortmaker-CHS-072-121-Heat-Pump.jpg)
Serviceability features: Simple safety circuit troubleshooting with easy-access terminal board. Simplified control box arrangement. Comfort Alert™ diagnostic board includes LED screen with fault code, fault code retention logic, phase protection, built-in time guard anti-short cycle, and low volt compressor contactor protector. High- and low-pressure switches.
Noise-reduction features: Compressor includes overload protection and vibration isolation for quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Single- and two-stage cooling with fully hermetic scroll compressor, crankcase heater, and suction line accumulators. For easy transport, the CHS 072-121 has a full perimeter base rail with built-in rigging adapters and fork truck slots. Durable round copper tube aluminum plate fin condenser coils. Galvanized steel cabinet with pre-painted exterior/primer-coated interior.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.gocomfortmaker.com.
eProduct: 174
![Comfortmaker RGW 036-060 Air Conditioner](/ext/resources/2022/05-May/Comfortmaker-RGW-036-060-Air-Conditioner.jpg)
With X-Vane™ fan technology
Serviceability features: Beltless, direct-drive, X-Vane™ fan technology uses Vane Axial fan design, reliable two-stage scroll compressor and ECM. No need to adjust belts or pulleys. Upgraded control board with intuitive indoor fan adjustment. Naturally draining heat exchanger. High- and low-pressure switches. Easy-access handles and no-strip screw system. Cabinet sized to fit existing roof curbs.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor/outdoor fan systems. Indoor fan uses X-Vane/Vane Axial fan design with built-in, ramp-up speed technology to soften sound during startup. Lightweight, high-impact composite fan blade on the outdoor fan system minimizes sound. X-Vane units have an acoustic dBA of 79 (by comparison, the dial tone on a phone has a dBA of 80).
IAQ equipment supported: Factory and field fresh air economizers with capability for demand control ventilation. Economizers use fault detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation. Horizontal economizers are available as an accessory only. Units available in a variety of gas heat sizes to match specific climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: X-Vane fan technology indoor fan system has 75% fewer moving parts than traditional belt drive systems and uses less energy. The new 5/16-inch round copper tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. Units have same footprint as 30 years ago, making them ideal for replacement. No special training required.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. Up to five-year extended parts warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: Vane Axial fans always spin in the correct direction. Installers should perform a proper startup, including: checking three-phase compressors to ensure that they are phased correctly and measuring temperatures/pressures at startup to ensure the compressor is pumping. If the installer cannot check the cooling operation at startup (i.e., winter startup), then the cooling function should be disabled until the installer can return and complete proper startup.
Contact: International Comfort Products, 317-481-5744; www.gocomfortmaker.com.
eProduct: 175
![Daikin Applied Magnitude Chiller](/ext/resources/2022/05-May/Daikin-Applied-Magnitude-Chiller.jpg)
Serviceability features: Magnitude’s oil-free, magnetic bearing design uses direct-drive motor and shaft for increased reliability with infinite life – no bearing wear surfaces, gears, or slide valves. Soft start feature reduces mechanical and thermal stresses and maintenance for increased motor life. The HMI control screen utilizes SiteLine Controls, providing real-time analytics for energy optimization, IAQ, and sustainability. Digital controls monitor chiller operating status providing fault protections. Adjustable HMI panel and compact unit footprint enables easy servicing accessibility.
Noise-reduction features: Magnitude chillers utilize magnetic bearings, which offers an inherently quiet design – these chillers’ sound levels are tested in accordance with AHRI Standard 575.
IAQ equipment supported: WME uniquely meets IAQ demands with inverted duty operation and low condenser entering water temperature savings. Allowing the chiller to accept condenser entering water temperature below the evaporator leaving water temperature can eliminate the need for a waterside economizer. Economizer elimination simplifies pressurization control – essential in reducing humidification and maintaining quality air. Humidity levels can mean life or death in a hospital, as consistent air temperature and humidity levels mitigate bacteria and infectious disease spreading.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Magnitude uses VFDs, magnetic bearings, and advanced controls for the best uptime capabilities in the industry – RideThrough® and RapidRestore®. For mission critical facilities, power loss means loss of cooling. RapidRestore produces industry-leading startup and fast-loading times, restarting in 20 seconds after power resumption, then restoring 80% cooling load capacity in 75 seconds. RideThrough, Daikin’s unique power trip resilience technology for WME models, allows chillers to maintain operation even during power loss up to 17 seconds.
Warranty information: Warranty options for refrigerant, parts, unit parts, and labor, and extended versions for each are available.
Special installation requirements: Magnitude has standard installation requirements with nothing unique compared to other chillers in the same segment.
Contact: Daikin Applied, 763-553-5330; www.daikinapplied.com.
eProduct: 176
![Daikin Commercial Unitary Heat Pump](/ext/resources/2022/05-May/Daikin-Commercial-Unitary-Heat-Pump.jpg)
Standard efficiency gas/electric and heat pump rooftops, 3 to 25 tons
Serviceability features: Easy access to fan, motor, control panel, gas valves, and compressor with optional, toolless hinged access doors. Standard features include slide-out blower for easy access and removal, sloped drain pan, contactors with lugs, high- and low-pressure switches, high-capacity steel-cased filter driers, crankcase heater, built-in filter rack for 2-inch filters convertible to 4 inches, labeled field connections, and color-coded and continuously marked wires for easy point-to point component connections.
Noise-reduction features: High-efficiency scroll compressors.
IAQ equipment supported: Factory-installed economizers are available for providing and controlling fresh outside air.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Manufactured at the Daikin Texas Technology Park, Daikin’s line of standard efficiency RTUs bring ease of installation and efficient operation with an outstanding limited warranty. Features include 5-mm condensing coils and a durable tubular heat exchanger. Several factory-installed options include hinged access panels, powered or non-powered convenience outlets, non-fused disconnect switch, return and/or supply air smoke detectors, stainless-steel heat exchanger, economizer, and phase monitor. New Daikin LCXpress selection tool specifically for rooftop application configuration.
Warranty information: The heat exchanger is covered by a 20-year warranty, and all functional parts are covered by a five-year parts warranty. Complete warranty details are available from local dealer, distributor, or manufacturer representative. To receive the parts limited warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Quebec.
Special installation requirements: Engineered to be an easy, direct replacement for most rooftop units without the need for a curb adapter. All sizes include built-in through-the-base options and horizontal access knockouts for easy infield wiring and piping installation. Supply fan comes standard for downflow applications and field convertible for horizontal applications.
Contact: Daikin Comfort Technologies North America Inc., 713-861-2500; www.northamerica-daikin.com.
eProduct: 177
![Daikin Commercial Unitary Rooftop Units](/ext/resources/2022/05-May/Daikin-Commercial-Unitary-Rooftop-Units.jpg)
High-efficiency gas/electric and heat pump rooftops, 3 to 12.5 tons
Serviceability features: Easy access to fan, motor, control panel, gas valves, and compressor with optional, toolless hinged access doors. Standard features include slide-out blower for easy access and removal, sloped drain pan, contactors with lugs, high- and low-pressure switches, high-capacity steel-cased filter driers, crankcase heater, built-in filter rack for 2-inch filters convertible to 4 inches, labeled field connections, and color-coded and continuously marked wires for easy point-to point component connections.
Noise-reduction features: High-efficiency scroll compressors.
IAQ equipment supported: Factory-installed economizers are available for providing and controlling fresh outside air.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Manufactured at the Daikin Texas Technology Park, Daikin’s line of standard efficiency RTUs bring ease of installation and efficient operation with an outstanding limited warranty. Features include 5-mm condensing coils and a durable tubular heat exchanger. Several factory-installed options include hinged access panels, powered or non-powered convenience outlets, non-fused disconnect switch, return and/or supply air smoke detectors, stainless steel heat exchanger, economizer, and phase monitor. New Daikin LCXpress selection tool specifically for rooftop application configuration.
Warranty information: The heat exchanger is covered by a 20-year warranty and all functional parts are covered by a five-year parts warranty. Complete warranty details are available from local dealer, distributor, or manufacturer representative. To receive the parts limited warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Quebec.
Special installation requirements: Engineered to be an easy, direct replacement for most rooftop units without the need for a curb adapter. All sizes include built-in through the base options and horizontal access knockouts for easy infield wiring and piping installation. Supply fan comes standard for downflow applications and field convertible for horizontal applications.
Contact: Daikin Comfort Technologies North America Inc., 713-861-2500; www.northamerica-daikin.com.
eProduct: 178
![Daikin Commercial VRV Emerion](/ext/resources/2022/05-May/Daikin-Commercial-VRV-Emerion.jpg)
Serviceability features: Completely redesigned for ease of service. Sealed electrical box with IP55 rating for protection from dust, water, and snow. Hot gas defrost circuit at bottom of coil eliminates need for base pan heater. Service window provides quick access to multi-functional display and configuration buttons. Multifunctional display provides refrigerant pressures and temperatures, eliminating the need to connect gauges during regular maintenance check. Refrigerant-cooled circuit keeps PCB cool. Intermittent outdoor fan operation minimizes snow accumulation.
Noise-reduction features: Standard operating sound levels are minimized with Daikin’s inverter variable-speed vapor injection compressors.
IAQ equipment supported: Compatible with 100% outside air processing unit (FXMQ_MFVJU) and energy recovery ventilator (VAM_GVJU) providing sufficient levels of fresh outside air and recover waste heat from extracted air leaving the conditioned zone.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: New stylish, space-saving design engineered to provide ease of installation and service. Available in a single- and dual-module lineup with a new larger chassis and modular connectivity providing up to 40-ton system capacity with only two modules. Longer piping lengths allow coverage up to 360 feet of vertical distance. Patented vapor injection inverter compressor technology for optimized part-load efficiency. Year-round comfort and efficiency with automatic and customizable variable refrigerant technology (VRT).
Warranty information: Ten-year parts limited warranty and 10-year replacement compressor limited warranty. Complete warranty details are available from local dealer, distributor, or manufacturer representative. To receive the parts limited warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Quebec.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin Comfort Technologies North America Inc., 713-861-2500; www.northamerica-daikin.com.
eProduct: 179
![Daikin Commercial VRV Heat Pump](/ext/resources/2022/05-May/Daikin-Commercial-VRV-Heat-Pump.jpg)
Serviceability features: Convenient drop-down electrical box provides easy access to internal components. Front or top refrigerant pipe connections provide additional application installation flexibility. Easy-to-read, seven-character display provides simplified diagnostics and troubleshooting. Compact (39 inches high by 30 inches wide by 22 inches deep), lightweight (430-pound) units are transportable using a dolly and elevators, saving time and labor. The compact size, and heat rejection cancellation technology allow installation in small spaces, without any additional ventilation requirements.
Noise-reduction features: Standard operating sound levels are minimized with Daikin engineered and manufactured, proprietary, inverter, variable-speed scroll compressors, providing system sound pressure levels as low as 54 dBA.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Engineered for buildings with cooling tower water loops or geothermal applications. Single modules are available in 8, 10, and 12 tons. Single modules can be manifolded together with up to three units to form one system of up to 36 tons. Simultaneous heating and cooling is available with heat recovery configuration. Provides all the attributes of an air-cooled VRV system including the added flexibility for cold climate applications, low sound levels, advanced comfort control, and zoning.
Warranty information: Ten-year parts limited warranty and 10-year replacement compressor limited warranty. Complete warranty details are available from local dealer, distributor, or manufacturer representative. To receive the parts limited warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Quebec.
Special installation requirements: Manufacturer did not specify.
Contact: Daikin Comfort Technologies North America Inc., 713-861-2500; www.northamerica-daikin.com.
eProduct: 180
![Day and Night RAH 073 Air Conditioner](/ext/resources/2022/05-May/Day-and-Night-RAH-073-Air-Conditioner.jpg)
Serviceability features: Central terminal board facilitates simple safety circuit troubleshooting and simplified control box arrangement. Toolless filter access door with large panels and easy-grip handles provide quick access to the blower, blower motor, control box, and compressor. Features no-strip screw system with superior holding power.
Noise-reduction features: Fully insulated cabinet reduces noise at maximum performance.
IAQ equipment supported: Two-inch return air filters encased in tilt-down metal filter frame. Optional economizer control accepts CO2 sensor for IAQ capability. Accessory duct-mounted CO2 sensor available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: One-piece two-stage electric cooling with a low profile and efficient scroll compressor. Field convertible from vertical to horizontal airflow; no special kit required. TXV refrigerant metering device to precisely control refrigerant flow. Through-the-bottom power entry capability. Standard, medium, and high static fan motor options.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.godayandnight.com.
eProduct: 181
![Day and Night RAW 036-060 Air Conditioner](/ext/resources/2022/05-May/Day-and-Night-RAW-036-060-Air-Conditioner.jpg)
With X-Vane™ fan technology
Serviceability features: Beltless direct-drive X-Vane fan technology uses Vane Axial fan design, reliable two-stage scroll compressor, and ECM motors. No need to adjust belts or pulleys. Upgraded control board with intuitive indoor fan adjustment. Naturally draining heat exchanger. High- and low-pressure switches. Easy-access handles and no-strip screw system. Cabinet sized to fit existing roof curbs.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor/outdoor fan systems. Indoor fan uses X-Vane/Vane Axial fan design with built-in, ramp-up speed technology to soften sound during startup. Lightweight, high-impact composite fan blade on the outdoor fan system minimizes sound. X-Vane units have an acoustic dBA of 79 (by comparison dial tone on a phone has a dBA of 80).
IAQ equipment supported: Two-inch return air filters encased in tilt-down metal filter frame. Optional economizer control accepts CO2 sensor, single dry bulb temperature sensor, or single enthalpy sensor for IAQ capability. Economizer X uses fault detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: X-Vane fan technology indoor fan system has 75% fewer moving parts than traditional belt drive systems and uses less energy. The new 5/16-inch round copper tube and aluminum plate condenser coils improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. Units have same footprint as 30 years ago, making them ideal for replacement. No special training required.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Up to five-year extended parts warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: Vane Axial fans always spin in the correct direction. Installers should perform a proper startup, including: checking three-phase compressors to ensure that they are phased correctly and measuring temperatures/pressures at startup to ensure the compressor is pumping. If the installer cannot check the cooling operation at startup (i.e., winter startup), then the cooling function should be disabled until the installer can return and complete proper startup.
Contact: International Comfort Products, 317-481-5744; www.godayandnight.com.
eProduct: 182
![First Co. WSV6 Heat Pump](/ext/resources/2022/05-May/First-Co-WSV6-Heat-Pump.jpg)
Serviceability features: Very accessible from the front of the unit to all major components. Sight glass to read status on the multifunctional circuit board. Toolless filter rack installation
Noise-reduction features: Fully insulated with 1-inch thick insulation and deep tunnel discharge for quiet operation.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Small cabinet design to fit in most applications either new construction or replacement.
Warranty information: Five-year warranty on all parts.
Special installation requirements: Unit is ordered with either a left-hand return or right-hand return.
Contact: First Co., 214-388-5751, ext. 1166; www.firstco.com.
eProduct: 183
![Friedrich FreshAire PTAC](/ext/resources/2022/05-May/Friedrich-FreshAire-PTAC.jpg)
Serviceability features: Standard 42- by 16-inch chassis built for ease of installation and serviceability. Easy to remove indoor blower section for cleaning and motor service. Easily accessible/cleanable MERV 8 make-up air filter. Easy access to all working components for both cleaning and service.
Noise-reduction features: Inverter technology eliminates noisy on/off cycles and operates at quieter levels than other conventional PTAC units. Additional noise isolation is achieved with specially placed gaskets and sound isolation compressor grommets.
IAQ equipment supported: FreshAire IAQ solutions are new for 2022. This suite of indoor air quality accessories are designed for use with Friedrich air conditioners, all with one dedicated purpose: healthy indoor air. FreshAire IAQ solutions incorporate ASHRAE-recommended protocol to address indoor air quality and airborne transmissions. This suite of products expands upon Friedrich’s current award-winning, patented FreshAire make-up system to now include industry-leading air quality technologies such as UV germicidal light and bipolar ionization.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The PTAC offers the integrated FreshAire system that delivers up to 52 cfm of conditioned fresh air (MUA) into the space. The fresh air is filtered through a MERV 8 filter per ASHRAE 62.1-2013 compliance. Now with FreshAire IAQ, the system delivers healthy clean air into the space.
Warranty information: Two-year parts and five-year limited warranty.
Special installation requirements: Standard 42- by 16-inch PTAC that fits into most PTAC wall sleeves.
Contact: Friedrich Air Conditioning, 800-541-6645; www.friedrich.com.
eProduct: 184
![Friedrich VRP Studio Heat Pump](/ext/resources/2022/05-May/Friedrich-VRP-Studio-Heat-Pump.jpg)
Serviceability features: Compact and packaged. Designed to be easily removed from the closet for major service. Minor service and maintenance can be completed in place.
Noise-reduction features: Ultra quiet, closet-installed application. BLDC compressor and motors help mitigate overall sound and eliminate nuisance relay sound.
IAQ equipment supported: New for 2022 is VRP Studio with FreshAire® IAQ accessories. FreshAire IAQ is a suite of indoor air quality accessories for use with Friedrich VRP, all with one dedicated purpose - healthy indoor air. FreshAire IAQ solutions incorporate ASHRAE-recommended protocol to address indoor air quality and airborne transmissions. This suite of products include industry-leading air quality technologies such as active dehumidification, integrated make-up air (MUA), MERV 13 filtration, UV germicidal light, and bipolar ionization.
Thermostat compatibility: Friedrich and approved thermostats
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Small footprint, compact variable refrigerant packaged system with optional hot-gas reheat. Integrated make-up air, filtered with MERV 8 reusable filters enables ASHRAE 62.1-2013 compliant outside air delivery.
Warranty information: One-year parts, five-year sealed system.
Special installation requirements: External wall opening with wall sleeve and louver are required for proper installation. Indoor closet and access panel are required for installation, service, and maintenance.
Contact: Friedrich Air Conditioning, 210-546-0565; www.friedrich.com.
eProduct: 185
![Fujitsu Airstage J-IV Heat Pump](/ext/resources/2022/05-May/Fujitsu-Airstage-J-IV-Heat-Pump.jpg)
Serviceability features: Designed with easily removable panels for service and maintenance.
Noise-reduction features: Airstage J-IV systems feature low indoor and outdoor units operating sound levels. Indoor units can be as low as 21 dB (similar to a soft whisper) and outdoor units can be as low as 50 dB.
IAQ equipment supported: Several of the 11 different indoor unit types have options for integration of filtered outside air. In addition, the J-IV system can be configured with dedicated outside air units with air filters.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Expanded heating operation range - more than 50% of rated capacity down to -15°F. Allows up to 150% Indoor unit connectable capacity ratio. Connect up to 9, 12, 15 indoor units to each 3-, 4-, 5-ton outdoor unit, respectively. Choose from 11 indoor unit styles ranging from 4,000 to 60,000 Btuh. Ability to reduce electrical circuit breaker sizes when installed. Built-in base pan heaters designed for reliable drain management.
Warranty information: Standard limited warranty of five-year parts and seven-year compressor. When registered system is installed by licensed contractor, according to law, codes, good trade practices, and product documentation, it is extended to 10/10.
Special installation requirements: Installation of the J-IV system is described in the installation manual.
Contact: Fujitsu General America Inc., 888-888-3424; www.fujitsugeneral.com.
eProduct: 186
![Greenheck RV Rooftop Unit](/ext/resources/2022/05-May/Greenheck-RV-Rooftop-Unit.jpg)
Dedicated outdoor air system (DOAS) or packaged rooftop
Serviceability features: Web-user interface for remote monitoring and easy startup. Hinged access doors for easy access to filters, fans, energy recovery wheel, compressors, and controls. Optional lightweight, segmented energy recovery wheel for easy cleaning. Dirty-filter switches, rotation sensors, airflow monitoring, and microprocessor available.
Noise-reduction features: Units are provided with actual radiated sound data tested in an AMCA-certified lab at full capacity with five planes of actual sound data. Two-inch R13 foam insulated unit and base. Compressor isolation with optional inverter scroll compressor. Optional EC motor(s) for head pressure control on condenser fan(s).
IAQ equipment supported: Optional UV light and/or bipolar ionization for air disinfection. Two-inch MERV 8 outdoor air and exhaust filters. Two- or 4-inch filters ranging from MERV 8 to MERV 14 supply filters. Optional outdoor, supply, and exhaust airflow monitoring. Optional CO2 sensor.
Thermostat compatibility: Compatible with most thermostats when using a BMS. Manufactured thermostat provided with controls by factory when selected.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Inverter compressor from 3 to 70 tons. Air-source heat pump from 5 to 30 tons. High-turndown furnace up to 16:1 turndown. Factory-programmed microprocessor. Built-in furnace commissioning guide. Web user interface allowing the unit to be viewed and controlled from a web browser. Horizontal duct connections for installation flexibility. Web-based selections.
Warranty information: Standard one-year unit warranty with two- to five-year extended options. Optional five-year extended compressor warranty. Standard 25-year stainless steel heat exchanger warranty.
Special installation requirements: None
Contact: Greenheck, 715-359-6171; www.greenheck.com.
eProduct: 187
![Heil PGR5 Rooftop Unit](/ext/resources/2022/05-May/Heil-PGR5-Rooftop-Unit.jpg)
Serviceability features: Installed easily on rooftop or ground level. Three panels allow easy access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Includes two-stage Copeland Scroll® compressor, designed to operate most of the time in the quieter, lower stage. Also includes a two-stage heating system that offers similar comfort benefits in the heating mode. Outdoor fan is sized and optimized for minimal noise.
IAQ equipment supported: Dehumidification mode (airflow reduction) standard on all models. Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Units feature two-stage heating and cooling operation, stainless steel tubular heat exchangers, field-convertible airflow, and high-efficiency ECM indoor blower motors. With cooling efficiencies up to 16 SEER and 12.5 EER, the PGR5 packaged units are Energy Star qualified.
Warranty information: Ten-year limited warranty on heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.goheil.com.
eProduct: 188
![Heil RGH 181-303 Rooftop Unit](/ext/resources/2022/05-May/Heil-RGH-181-303-Rooftop-Unit.jpg)
Serviceability features: IGC solid-state control for on-board diagnostics with LED error code designation, burner control logic, and energy-saving indoor fan motor delay. All connections and troubleshooting points located in one convenient place, the easy-access master terminal board. Units feature through-the-base utility connections capability. Access panels have easy-grip handles and no-strip screw feature.
Noise-reduction features: Fully insulated cabinet with isolated scroll compressors and rigidly mounted indoor fan system.
IAQ equipment supported: Two-inch return air filters. Optional economizer control accepts CO2 sensor for IAQ capability. Duct-mounted CO2 sensor accessor available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Features two-stage cooling with independent circuits and controls. Dedicated vertical or horizontal airflow duct configuration models. High- and low-pressure switches. Scroll compressor has internal line-break overload protection. Factory-installed options include high-static indoor fan, economizers, variable-frequency drive two-speed fan, and hot gas reheat system.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized steel heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.goheil.com.
eProduct: 189
![ICP CHS-180 240 Heat Pump](/ext/resources/2022/05-May/ICP-CHS-180-240-Heat-Pump.jpg)
Serviceability features: Comfort Alert™ diagnostic board includes LED screen with fault code, fault code retention logic, phase protection, built-in time guard anti-short cycle, and low volt compressor contractor protector. Easy-access control box arrangement. Simple safety circuit troubleshooting with newly designed terminal board. Simplified control box arrangement. High- and low-pressure switches.
Noise-reduction features: To minimize sound at maximum performance, the compressor includes vibration isolation and overload protection.
IAQ equipment supported: When installed with an air handler — as a complete split system — this unit is compatible with a variety of IAQ products including filters and humidifiers. Field-installed economizer with multiple sensors and CO2 controls. Furnished air filters with easy replacement capability.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Superior two-stage cooling. Fully hermetic scroll compressor, crankcase heater, and suction line accumulators. Filter drier standard. Full perimeter base rail with built-in rigging adapters and fork truck slots for easy transport. Galvanized steel cabinet with pre-painted exterior/primer-coated interior. Durable round copper tube aluminum plate fin condenser coils.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.icpcommercial.com.
eProduct: 190
![ICP RGV 036-072 Rooftop Unit](/ext/resources/2022/05-May/ICP-RGV-036-072-Rooftop-Unit.jpg)
With X-Vane™ fan technology
Serviceability features: Newly designed control board provides convenient access to all connections/troubleshooting points. Intuitive switch and rotary dial arrangement make it easy to set up/adjust the speed of the X-Vane™ fan technology. Induced draft gas heat exchanger design. Cabinet size has worry-free fit for existing curb footprints. Easy access handles and no-strip screw system.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor/outdoor fan systems. Indoor fan uses X-Vane/Vane Axial fan design with built-in, ramp-up speed technology to soften sound during startup. Lightweight, high-impact composite fan blade on the outdoor fan system minimizes sound. X-Vane units have an acoustic dBA of 79 (by comparison the dial tone on your phone has a dBA of 80).
IAQ equipment supported: Factory and field fresh air economizers with capability for demand control ventilation. Economizer X uses fault detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation. Units available in a variety of gas heat sizes to match specific climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: X-Vane fan technology indoor fan system has 75% fewer moving parts than traditional belt drive systems and uses less energy. The new 5/16-inch round copper tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. Units have same footprint as 30 years ago, making them ideal for replacement. No special training required.
Warranty information: Fifteen-year limited warranty on optional stainless steel heat exchanger; 10-year limited warranty on aluminized heat exchanger; five-year limited warranty on compressor; one-year limited warranty on all other parts. Up to five-year extended parts warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: Vane Axial fans always spin in the correct direction. Installers should perform a proper startup, including: checking three-phase compressors to ensure that they are phased correctly and measuring temperatures/pressures at startup to ensure the compressor is pumping. If the installer cannot check the cooling operation at startup (i.e., winter startup), then the cooling function should be disabled until the installer can return and complete proper startup.
Contact: International Comfort Products, 317-481-5744; www.icpcommercial.com.
eProduct: 191
![Johnson Controls Choice Heat Pump](/ext/resources/2022/05-May/Johnson-Controls-Choice-Heat-Pump.jpg)
Serviceability features: The lightweight design and direct replacement footprint of the Choice heat pump rooftop offers ease of installation and flexibility for both new product and retrofit applications. In fact, units fit nearly 70% of the competitive installed base, minimizing the need for costly transition curbs. It includes independent circuits to help avoid full unit shutdowns. Single-side access to all serviceable items provide ease of service.
Noise-reduction features: Not applicable.
IAQ equipment supported: Choice RTUs feature a convertible filter rack from to 2 or 4 inches with factory options up to MERV 13 pleated filters to meet LEED requirements. The systems feature a broad range of outdoor air options, including low leak damper economizers, constant volume powered exhaust, and modulating powered exhaust.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Choice heat pump RTUs exceed DOE 2018 part-load cooling efficiencies by 15% and meet DOE 2023 efficiencies for both heating and cooling. Unit weight is up to 20% less than other Johnson Controls models, reducing the need for structural reinforcements.
Warranty information: Standard one-year parts warranty and five-year compressor and electric heat limited warranties.
Special installation requirements: None.
Contact: Johnson Controls, 414-344-8594; johnsoncontrols.com/choice.
eProduct: 192
![Johnson Controls Premier Air Conditioner](/ext/resources/2022/05-May/Johnson-Controls-Premier-Air-Conditioner.jpg)
Serviceability features: Premier rooftop units are engineered for simplified serviceability to lower the life cycle costs of the unit. The new RTUToolkit app for Android and iOS allows contractors to simply scan a unique QR code on each rooftop, which enables on-demand access to unit-specific details, technical literature, and direct connection to technical support. Optional features include a mobile access portal gateway that offers a Wi-Fi interface, allowing for technicians to interface with the units from their car.
Noise-reduction features: Sound attenuator and compressor sound blanket options minimize sound outputs.
IAQ equipment supported: Indoor air quality is maximized with the Premier units through optional features such as ultraviolet lights, humidifiers, hot gas reheat coils, and final filters.
Thermostat compatibility: Not applicable.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: The Premier platform is designed to provide building owners best-in-class efficiency levels that significantly reduce operational costs. The systems deliver up to 50% higher-than-required results depending on the local code and additional options are available to meet the Consortium for Energy Efficiency 2019 highest tier ratings. The units also feature an optional high-end graphical user interface, which features a full-color touchscreen that provides quick access to system status, performance metrics, and schedule parameters.
Warranty information: Standard one-year parts and either a 6-month or one-year promotional labor warranty when started by a certified contractor.
Special installation requirements: Premier rooftop units offer flexibility in airflow path configuration, making installation in different scenarios easier. To help reduce the cost of crane required to set the unit, 60- to 80-ton cabinets can be supplied as a split ship unit. Split ship units are intended to be put back together in the field.
Contact: Johnson Controls, 414-344-8594; www.johnsoncontrols.com/premier.
eProduct: 193
![KeepRite PHR5 Heat Pump](/ext/resources/2022/05-May/KeepRite-PHR5-Heat-Pump.jpg)
Serviceability features: Installs easily on rooftop or ground level. Easy three-panel access for maintenance and installation. Easily converts to down discharge applications.
Noise-reduction features: Outdoor fan sized and optimized for minimal noise.
IAQ equipment supported: Accessory filter racks support 2-inch filters.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Energy Star qualified unit achieves up to 15.5 SEER/12.5 EER electric cooling and up to 8.5 HSPF electric heating. Unit features field-convertible airflow, high- and low-pressure switches for added compressor reliability, and high-efficiency ECM indoor blower motor. Dehumidification mode (airflow reduction) on all models. Advanced dehumidification is an additional option.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. See warranty certificate for complete details and restrictions.
Special installation requirements: Roof curbs available as field-installed accessories.
Contact: International Comfort Products, 317-481-5744; www.gokeeprite.com.
eProduct: 194
![KeepRite RAV 036-072 Air Conditioner](/ext/resources/2022/05-May/KeepRite-RAV-036-072-Air-Conditioner.jpg)
With X-Vane™ fan technology
Serviceability features: Newly designed control board provides convenient access to all connections/troubleshooting points. Intuitive switch and rotary dial arrangement make it easy to set up/adjust the speed of the X-Vane fan technology. Cabinet size has worry-free fit for existing curb footprints. Easy access handles and no-strip screw system.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor/outdoor fan systems. Indoor fan uses X-Vane/Vane Axial fan design with built-in, ramp-up speed technology to soften sound during startup. Lightweight, high-impact composite fan blade on the outdoor fan system minimizes sound. X-Vane units have an acoustic dBA of 79 (by comparison, the dial tone on your phone has a dBA of 80.)
IAQ equipment supported: Factory and field fresh air economizers with capability for demand control ventilation. Economizer X uses fault detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation. Units available in a variety of gas heat sizes to match specific climate zones and applications.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: X-Vane fan technology indoor fan system has 75% fewer moving parts than traditional belt drive systems and uses less energy. The new 5/16-inch round copper tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. Units have same footprint as 30 years ago, making them ideal for replacement. No special training required.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: Vane Axial fans always spin in the correct direction. Installers should perform a proper startup, including: checking three-phase compressors to ensure that they are phased correctly and measuring temperatures/pressures at startup to ensure the compressor is pumping. If the installer cannot check the cooling operation at startup (i.e., winter startup), then the cooling function should be disabled until the installer can return and complete proper startup.
Contact: International Comfort Products, 317-481-5744; www.gokeeprite.com.
eProduct: 195
![Lennox Commercial ML14XC1 Merit Air Conditioner](/ext/resources/2022/05-May/Lennox-Commercial-ML14XC1-Merit-Air-Conditioner.jpg)
Serviceability features: Includes the exclusive Lennox Quantum™ Coil Technology, making it easier to service while enhancing performance ratings. Quantum coil technology is designed to deliver on improved comfort and energy savings. With years of rigorous design and testing under the most extreme conditions, Quantum Coil Technology — featuring a proprietary aluminum alloy exclusive to Lennox — is here to deliver superior performance and peace of mind.
Noise-reduction features: The unit provides an optional compressor sound cover, a muffler in the discharge line, and low gas pulses during compression that reduce overall operation sound levels.
IAQ equipment supported: Not applicable.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The louvered, heavy-gauge steel panels and cabinets featuring PermaGuard® provide superior corrosion resistance. The units also include the exclusive Lennox Quantum Coil Technology, making service easier and enhancing performance ratings.
Warranty information: Five-year limited compressor and one-year limited all other covered components.
Special installation requirements: Manufacturer did not specify.
Contact: Lennox Commercial, 972-333-8094; www.lennoxcommercial.com.
eProduct: 196
![Lennox Commercial Model L Rooftop Unit](/ext/resources/2022/05-May/Lennox-Commercial-Model-L-Rooftop-Unit.jpg)
Serviceability features: The Lennox® CORE service app brings guided setup menus for install, test and balance, network integration, detail runtimes, and service history to the palm of one’s hand. Each Model L unit comes standard with toolless filter access, isolated compressor compartment, and accessible gas compartment, which reduces service time. Each of these features allow technicians to quickly perform service and maintenance on every Model L rooftop unit.
Noise-reduction features: Units all feature a soft-start inverter-driven, variable-speed compressor, as well as fully variable indoor and outdoor fans, which greatly reduce the noise levels during part-load operation and startup.
IAQ equipment supported: Units provide Ultimate IAQ with the ability to remove 99% of the virus that causes COVID-19 from the air. The Model L rooftop unit can help commercial businesses improve the health of their building with factory-installed UV-C lights, needlepoint bipolar ionization, high-efficiency MERV filters, and modulating hot gas reheat to provide superior indoor air quality and year round comfort.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The Lennox CORE unit controller and mobile service app provide a unique interface. The built-in wireless gateway provides quick and easy connection to the mobile app, as well as optional wireless zone sensors. Real-time data readouts make servicing Lennox rooftop units easier than ever before. Model L units are enabled with an enhanced dehumidification mode, which is designed to provide additional dehumidification when both cooling and dehumidification demands are present.
Warranty information: Three-year Lennox CORE unit controller. Ten-year aluminized heat exchangers. Fifteen-year stainless steel heat exchangers. Five-year compressors. Five-year high-performance economizers and variable-frequency drives (inverters) when installed in all applications.
Special installation requirements: The CORE service app replaces a traditional built-in user interface on the Lennox CORE unit controller and provides guided setup menus for install, test and balance, and network integration. The app also facilitates seamless commissioning of wireless sensors and sensor networks compatible with the CORE control system.
Contact: Lennox Commercial, 972-333-8094; www.lennoxcommercial.com.
eProduct: 197
![LG Electronics Inverter Scroll Heat Pump Chiller](/ext/resources/2022/05-May/LG-Electronics-Inverter-Scroll-Heat-Pump-Chiller.jpg)
(ISHPC), ACHH017H(V)BAB, ACHH020H(V)BAB, ACHH033H(V)BAB, ACHH040H(V)BAB, ACHH050H(V)BAB, ACHH060H(V)BAB: (H-460V and V-208-230V)
Serviceability features: With an independent modular system design that reduces the size of each independent refrigerant circuit, the ISHPC is internally redundant, reducing the impact of compressor downtime. Compared to staged systems, the ISHPC matches the required capacity as the load changes, while optimizing electrical consumption, thanks to the system’s variable-speed design.
Noise-reduction features: Chiller performance is certified per AHRI Standard 550/590 and sound levels per AHRI Standard 370, demonstrating class leadership for integrated part-load value (IPLV), sound level, and low ambient heating performance.
IAQ equipment supported: The ISHPC gives engineers the opportunity to specify chilled and hot water for independent dedicated outdoor air systems. The heat pump chiller was designed to be used in a four-pipe application with external valves and controls. The variable-capacity performance of the ISHPC will promote its use in this type of application.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The category-leading innovation of the ISHPC resides in four critical areas: 1) the use of inverter technology for precise and efficient response to load demand; 2) low ambient/high performance heating; 3) modularity of design; and 4) inventory-ready availability. Performing in both comfort and process cooling applications, LG VRF systems allow the ISHPC to operate in low ambient cooling (to 5°F) applications without the need for costly options or system additions to the basic configuration.
Warranty information: One-year all parts and three-year compressor limited parts only warranty. Available to purchase are extended limited parts only warranties that can extend the parts only coverage to 5,6,7,8,9 and 10 additional years. There is not a labor coverage warranty available from the LG at this time.
Special installation requirements: The modularity of design allows chiller plants to be assembled per individual project requirements. Engineers are afforded a cost-effective, properly sized solution compared to the challenges associated with fixed-capacity, fixed-frame chillers.
Contact: LG Electronics, 562-243-4925; www.lghvac.com.
eProduct: 198
![Mitsubishi P-Series PKA Indoor Units](/ext/resources/2022/05-May/Mitsubishi-P-Series-PKA-Indoor-Units.jpg)
Serviceability features: Units feature a sleek, compact design ideal for light commercial spaces including churches, classrooms, daycare centers, small offices, or equipment rooms. Engineered for simplified service, the PKA unit’s internal components and filter are easily accessible.
Noise-reduction features: Designed to provide peace of mind to building owners and tenants, the PKA units operate at nearly whisper-quiet sound levels as low as 34 dBA.
IAQ equipment supported: Heat pump systems improve IAQ through filtration and the integration of ventilation and humidity management equipment. The PKA units are available in selectable high sensible or high latent modes. High latent mode offers enhanced moisture removal in the conditioned space. High sensible mode suits spaces where enhanced moisture removal is not required and the unit runs constantly.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: The PKA units are compatible with the P-Series PUY, PUZ, and PUZ Hyper-Heating INVERTER® (H2i®) outdoor units. With sound levels down to 34 dBA and increased efficiency ratings, the units are ideal for server rooms, daycare centers, classrooms, churches, small offices, and more. The PKA units are compatible with many controller options, including third-party controllers like Nest, for easier operation. The units feature a modern design, auto fan mode, and airflow direction control.
Warranty information: Five-year parts and seven-year compressor to original owner. Ten-year parts and compressor to original owner, if system is installed and registered within 90 days of installation. Twelve-year parts and compressor to original owner residing in the home, if system installed by Diamond Contractor® and registered within 90 days of installation.
Special installation requirements: Manufacturer did not specify.
Contact: Mitsubishi Electric Trane HVAC US (METUS), 800-433-4822; www.mitsubishicomfort.com.
eProduct: 199
![Modine Chilled Water Cooling Cassette](/ext/resources/2022/05-May/Modine-Chilled-Water-Cooling-Cassette.jpg)
Serviceability features: The cassette has a variety of optional factory-installed features, including fresh air intakes that ventilate and recirculate room air and electromechanical or microprocessor-based controls. The microprocessor controller includes an infrared transmitter that enables room conditions to be maintained at a user-defined setpoint. This unit can also utilize the Modine Controls System with Carel® Programmable controller with optional BACnet or LonWorks compatibility.
Noise-reduction features: Low blower speeds, rigid panel and cabinet construction, and sound-absorbent insulation reduces noise to a minimum.
IAQ equipment supported: Bipolar ionization is supported with this product.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Designed to effectively create independently controlled temperature zones, cassettes are ideal for classrooms, offices, laboratories, conference rooms, or any environment where space is at a premium and low noise is essential. This versatility eliminates compromising architecture or design, and cost savings are often realized during building updates, as existing piping and/or wiring can frequently be reused. This product also utilizes a hot water coil for heating and is available with electric heat.
Warranty information: One-year warranty for coils and sheet metal. Other parts and components have a two-year warranty. The warranty is for the replacement of parts for defects in materials and workmanship only.
Special installation requirements: None.
Contact: Modine Manufacturing, 800-828-4328; www.modinehvac.com.
eProduct: 200
![Nortek Air Solutions FANWALL Air Handler](/ext/resources/2022/05-May/Nortek-Air-Solutions-FANWALL-Air-Handler.jpg)
For retrofit applications and new construction
Serviceability features: Breathe new life into existing air handlers with FANWALL retrofit. Each fan can pass through most single-width doors, and each cube can be knocked-down for tight installations. Reduce maintenance costs with no belts or sheaves to change or bearings to grease. Save space with FANWALL arrays that can be applied in both vertical and horizontal airflow arrangements and save up to 50% in space and cabinetry.
Noise-reduction features: The acoustical benefit of FANWALL arrays is the low-frequency sound reduction of its smaller more efficient fans. Each backward inclined airfoil fan is custom designed and manufactured to the job’s design criteria. The optimum use of smaller, more energy-efficient direct-drive fans improves energy efficiency. The patented Coplanar Silencer® that attenuates sound within each cube often eliminates the need for sound attenuators and their associated static pressure penalty and costly concrete inertia pads.
IAQ equipment supported: Building owners who upgrade to a FANWALL array can increase airflow to applications where sufficient airflow was previously a challenge. An array can easily replace (within the same footprint) a single or dual fan system with an array of smaller more efficient fans. The FANWALL array produces a uniform piston of air that better utilizes the face area of filters and coils for increased life and capacity.
Thermostat compatibility: Building automation controls or motor control center.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: In many cases, access limitations are a barrier to a fan or air handler replacement because replacement cannot be accomplished without the time and expense of a major tear-out and reconstruction project. A FANWALL system can minimize this and other barriers. Individual cubes can be navigated into tight spaces to avoid major demolition and reconstruction and provide flexibility in staging projects with significant access barriers.
Warranty information: Twelve-month warranty from startup or 18 months from shipment. Extended warranties are also available.
Special installation requirements: The modular design allows individual cubes to be navigated through a standard 3-foot door and assembled inside the existing air handler cabinet. This eliminates the need and associated cost of having a crane on-site.
Contact: Nortek Air Solutions, 636.561.7300; www.nortekair.com.
eProduct: 201
![Rheem Renaissance Air Conditioner](/ext/resources/2022/05-May/Rheem-Renaissance-Air-Conditioner.jpg)
RGEG2T RACG2T
Serviceability features: PlusOne® Service Smart features allow contractors access to internal components, saving time during install, service, and preventative maintenance. These include Qwik-Slide blower assembly and patent-pending Qwik-Slide Velocifin heat exchanger slide-out for easy service of internal components; Qwik-Clean drain pan patent-pending design slides out for cleaning, features a standard overflow switch; and CoreCommand™ features a dual seven-segment LED display with enhanced diagnostics, fault code history, and input/output options to meet building needs.
Noise-reduction features: ECM motors, multiple indoor fan speeds, Copeland UltraTech™ compressor.
IAQ equipment supported: MERV 8, MERV 13, and field-installed UV-C light kits are available through Rheem.
Thermostat compatibility: Compatible with most thermostats. Offered with ClearControl™, a standard DDC controller with Modbus interface or optional BACnet or LonWorks interfaces.
Replacement parts compatibility: Some shared parts and some unique parts. Shares replacement parts with other models.
Additional features: Application flexibility: improved footprint for direct replacement of most other manufacturer’s products without a new roof curb adapter; two return options and convertible airflow; innovative technology for increased efficiency; system features indoor and outdoor intertwined microchannel coils; and patented Velocifin™ gas heat exchanger increases heat transfer. Enhanced serviceability: ServiceSmart™ features like the Qwik-Slide blower, Qwik-Slide heat exchanger, and Qwik-Clean drain pan reduce time spent performing industry standard service and maintenance.
Warranty information: Standard one-year parts, one-year compressor, 10-year standard heat exchanger, 20-year stainless steel heat exchanger.
Special installation requirements: None
Contact: Rheem Mfg.; www.rheem.com.
eProduct: 202
![Samsung Heat Pump](/ext/resources/2022/05-May/Samsung-Heat-Pump.jpg)
Serviceability features: Serviceability is greatly improved with a simplified chassis design with fewer panels and screws, along with an integral inverter check function that eliminates the need for a separate tool to validate inverter operation. The new DVM S2 features high-performance subcooling control, which allows for reduction of the main liquid pipe diameter from the outdoor unit to the first HR MCU or Y-joint to reduce overall system charge by an average of 30%.
Noise-reduction features: Not applicable.
IAQ equipment supported: Not applicable.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: The DVM S2 features artificial intelligence (AI) with deep neural network algorithms to optimize system operation with high- and low-pressure control, defrost cycle activation and operation, and low refrigerant monitoring. New AI technology allows the equipment to operate at exact target pressures and temperatures based on the actual application to save energy.
Warranty information: Ten-year parts, 10-year compressor, one-year limited labor warranty. Product registration required. Conditions apply.
Special installation requirements: None
Contact: Samsung HVAC America, 888-699-6067; www.samsunghvac.com.
eProduct: 203
![Spacepak Solstice Heat Pump](/ext/resources/2022/05-May/Spacepak-Solstice-Heat-Pump.jpg)
Mono-block air-to-water heat pump SIM-060
Serviceability features: User-friendly heat pump features touchscreen control with simple wiring/piping configurations.
Noise-reduction features: Low amp draw with ultra quiet operation. Modulating fans and inverter compressor match load and minimize noise.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Manufacturer did not specify.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: SpacePak’s SIM-060 air-to-water-heat pump provides cooling at low ambient temperatures as well as an abundance of heat for shoulder seasons. The variable-speed inverter compressor and modulating fans match system loads for optimal energy efficiency. The SIM-060 keeps all refrigerant outside the occupied space.
Warranty information: Parts are warrantied for a period of two years to the original system owner. The compressor is warrantied for a period of five years to the original system owner. If the system is installed in a residential single-family home by a SpacePak-certified contractor, the parts will be warrantied for five years and compressor for a period of 10 years. See warranty statement for complete details.
Special installation requirements: Follows normal hydronic practices for installation. No refrigerant certification is required.
Contact: SpacePak Inc., 413-568-9571; www.spacepak.com.
eProduct: 204
![TempMaster Omni Rooftop Unit](/ext/resources/2022/05-May/TempMaster-Omni-Rooftop-Unit.jpg)
Serviceability features: The lightweight design and direct replacement footprint of the TempMaster® Omni™ Choice heat pump rooftop unit offers ease of installation and flexibility for both new product and retrofit applications. In fact, units fit nearly 70% of the competitive installed base, minimizing the need for costly transition curbs. It includes independent circuits to help avoid full unit shutdowns. Single-side access to all serviceable items provide ease of service.
Noise-reduction features: Not applicable.
IAQ equipment supported: Choice RTUs feature a convertible filter rack from 2 or 4 inches, with factory options up to MERV 13 pleated filters to meet LEED requirements. The systems feature a broad range of outdoor air options, including low leak damper economizers, constant volume powered exhaust, and modulating powered exhaust.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Choice heat pump rooftops exceed DOE 2018 part-load cooling efficiencies by 15% and meet DOE 2023 efficiencies for both heating and cooling. Unit weight is up to 20% less than other TempMaster models, reducing the need for structural reinforcements.
Warranty information: Standard one-year parts and five-year compressor and electric heat limited warranties.
Special installation requirements: No.
Contact: Johnson Controls, 414-344-8594; www.tempmaster-hvac.com/packaged-rooftop-units/15275tchoiceac_tem_ds/tempmaster-omni-choice-rooftop-units.
eProduct: 205
![TempMaster Omni Premier Air Conditioner](/ext/resources/2022/05-May/TempMaster-Omni-Premier-Air-Conditioner.jpg)
Serviceability features: Premier rooftop units are engineered for simplified serviceability to lower the life cycle costs of the unit. The new RTUToolkit app for Android and iOS allows contractors to simply scan a unique QR code on each rooftop, which enables on-demand access to unit-specific details, technical literature, and direct connection to technical support. Optional features include a mobile access portal gateway that offers a Wi-Fi interface, allowing for technicians to interface with the units from their car.
Noise-reduction features: Sound attenuator and compressor sound blanket options minimize sound outputs.
IAQ equipment supported: Indoor air quality is maximized with the Premier units through optional features such as ultraviolet lights, humidifiers, hot gas reheat coils, and final filters.
Thermostat compatibility: Not applicable.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: The Omni Premier platform is designed to provide building owners best-in-class efficiency levels that significantly reduce operational costs. The systems deliver up to 50% higher-than-required results depending on the local code and additional options are available to meet the Consortium for Energy Efficiency 2019 highest tier ratings. The units also feature an optional high-end graphical user interface, which features a full-color touchscreen that provides quick access to system status, performance metrics and schedule parameters.
Warranty information: Standard one-year parts and either a six-month or one-year promotional labor warranty when started by a certified contractor.
Special installation requirements: Premier rooftop units offer flexibility in airflow path configuration, making installation in different scenarios easier. To help reduce the cost of crane required to set the unit, 60- to 80-ton cabinets can be supplied as a split ship unit. Split ship units are intended to be put back together in the field.
Contact: Johnson Controls, 414-344-8594; www.tempmaster-hvac.com/omnipremier.
eProduct: 206
![Tempstar RAH-073 Air Conditioner](/ext/resources/2022/05-May/Tempstar-RAH-073-Air-Conditioner.jpg)
Serviceability features: Central terminal board facilitates simple safety circuit troubleshooting and simplified control box arrangement. Toolless filter access door with large panels and easy-grip handles provides quick access to the blower, blower motor, control box, and compressor. Features no-strip screw system with superior holding power.
Noise-reduction features: Fully insulated cabinet reduces noise at maximum performance.
IAQ equipment supported: Two-inch return air filters encased in tilt-down metal filter frame. Optional economizer control accepts CO2 sensor for IAQ capability. Accessory duct-mounted CO2 sensor available for field installation to provide demand-controlled ventilation capability (DCV).
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: One-piece two-stage electric cooling with a low profile and efficient scroll compressor. Field convertible from vertical to horizontal airflow; no special kit required. TXV refrigerant metering device to precisely control refrigerant flow. Through-the-bottom power entry capability. Standard, medium, and high static fan motor options.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Extended warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: None.
Contact: International Comfort Products, 317-481-5744; www.gotempstar.com.
eProduct: 207
![TempStar RAW 036-060 Air Conditioner](/ext/resources/2022/05-May/TempStar-RAW-036-060-Air-Conditioner.jpg)
With X-Vane™ fan technology
Serviceability features: Beltless direct-drive X-Vane™ fan technology uses Vane Axial fan design, reliable two-stage scroll compressor, and ECM motors. No need to adjust belts or pulleys. Upgraded control board with intuitive indoor fan adjustment. Naturally draining heat exchanger. High- and low-pressure switches. Easy-access handles and no-strip screw system. Cabinet sized to fit existing roof curbs.
Noise-reduction features: Fully insulated cabinet, isolated scroll compressors, and balanced indoor/outdoor fan systems. Indoor fan uses X-Vane/Vane Axial fan design with built-in, ramp-up speed technology to soften sound during startup. Lightweight, high-impact composite fan blade on the outdoor fan system minimizes sound. X-Vane units have an acoustic dBA of 79 (by comparison, dial tone on a phone has a dBA of 80).
IAQ equipment supported: Two-inch return air filters encased in tilt-down metal filter frame. Optional economizer control accepts CO2 sensor, single dry bulb temperature sensor, or single enthalpy sensor for IAQ capability. Economizer X uses fault detection diagnostic controls to ensure operation and control ventilation air at multi-speed motor operation.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: X-Vane fan technology indoor fan system has 75% fewer moving parts than traditional belt drive systems and uses less energy. The new 5/16-inch round copper tube and aluminum plate condenser coils help improve efficiency and reduce refrigerant charge. Simple fan adjustment is made with a reference DC volt chart and switch/rotary dial. Units have same footprint as 30 years ago, making them ideal for replacement. No special training required.
Warranty information: Five-year limited warranty on compressor; one-year limited warranty on all other parts. Up to five-year extended parts warranty available. See warranty certificate for complete details and restrictions.
Special installation requirements: Vane Axial fans always spin in the correct direction. Installers should perform a proper startup, including: checking three-phase compressors to ensure that they are phased correctly and measuring temperatures/pressures at startup to ensure the compressor is pumping. If the installer cannot check the cooling operation at startup (i.e., winter startup), then the cooling function should be disabled until the installer can return and complete proper startup.
Contact: International Comfort Products, 317-481-5744; www.gotempstar.com.
eProduct: 208
![Trane Ascend Chiller](/ext/resources/2022/05-May/Trane-Ascend-Chiller.jpg)
Serviceability features: Compressor and condenser fans require no periodic maintenance and are designed for exceptionally long operational life. Transverse “open V” design allows easier cleaning of the condenser coils to keep coils and chiller properly functioning. Maintenance-free motor is exceptionally reliable, ensuring dependable operation.
Noise-reduction features: Quiet operation is designed into every ACR air-cooled chiller, and different levels of InvisiSound® acoustic reduction treatments are available to provide the flexibility to meet specific application needs. For the quietest Ascend chiller available, the optional InvisiSound ultimate package produces some of the industry’s lowest published sound levels.
IAQ equipment supported: Not applicable.
Thermostat compatibility: Compatible with most thermostats. Through Symbio® 800, this unit can also connect remotely or wired to the building automation system via BACnet, Modbus, or LonTalk.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Available up to 550 tons, the ACR is ideal for mission critical facilities by offering high full load efficiency for reduced generator sizes; integrated free cooling for amazing energy savings; and rapid restart technology, which minimizes downtime. At the core of its performance is integration of variable speed with variable volume ratio compression to optimize efficiency, driven by a permanent magnet motor. ACR reduces demand distortion with harmonic filtering to aid in compliance with IEEE 519.
Warranty information: Standard 12-month parts from startup or 18 months from shipment, whichever comes first. A variety of extended warranties for parts and labor, as well as optional delayed startup warranties are available.
Special installation requirements: The broad range of available factory options such as integrated free cooling and wireless connectivity significantly reduces the need for time-consuming on-site assembly. With free cooling additional equipment eliminated and additional complexity and cost avoided. Higher tonnage enable lower $/ton solution. Factory-installed Symbio 800 unit controller integrates seamlessly and securely, leveraging secure remote IP connectivity, optional Air-Fi® wireless, and open standard communication protocols for easier controls integration.
Contact: Trane; www.trane.com/commercial/north-america/us/en/products-systems/chillers/air-cooled-chillers/stealth.html.
eProduct: 209
![Trane IntelliPak Rooftop Unit](/ext/resources/2022/05-May/Trane-IntelliPak-Rooftop-Unit.jpg)
Serviceability features: The new Symbio® 800 controller simplifies building connectivity by providing remote monitoring, advanced monitoring tools, easier troubleshooting, and energy management capabilities through Trane Connect™. The 7-inch touchscreen display with an intuitive interface makes system adjustments easy. Designed with low-maintenance eDrive™ direct-drive plenum fans, filter monitoring, and diagnostic tools to make maintenance easier. Optional hinged access doors provide easy and fast access to critical sections of the unit.
Noise-reduction features: Not applicable.
IAQ equipment supported: Filtration options include pre-evaporator and final filter rating up to MERV 14. HEPA filters are also available. Optional Traq™ fresh air management system controls the amount of outdoor air intake to accurately meet minimum fresh air requirements.
Thermostat compatibility: Simplified integration with all common standard building communication protocols, including BACnet MS/TP, BACnet /IP, LonTalk (optional), and Modbus.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Improved energy efficiency, with three efficiency tiers and up to 18.5 IEER on select configurations meet DOE 2023 requirements.
Warranty information: Standard warranty for a period of 12 months from initial startup or 18 months from date of shipment, whichever is less. Ten-year limited warranty on optional full modulation gas heat exchanger. Five-year limited warranty for optional AMCA 1A Ultra Low Leak airfoil blade economizer assemblies and the AMCA 1A Ultra Low Leak economizer actuator. Extended warranties are available for compressors and heat exchangers of combination gas-electric air conditioning units.
Special installation requirements: Manufacturer did not specify.
Contact: Trane; www.trane.com/commercial/north-america/us/en/products-systems/packaged-units-and-split-systems/rooftop-units/intellipak.html.
eProduct: 210
![Whalen Closetline Heat Pump](/ext/resources/2022/05-May/Whalen-Closetline-Heat-Pump.jpg)
CAS Series packaged water-source heat pump
Serviceability features: Compact cabinet design with quick access for ease of service. Horizontal units can be serviced through the unit bottom to virtually eliminate removing ceiling-mounted units for service.
Noise-reduction features: Provided as standard, the unit has a dual-level vibration isolation system. A heavy-gauge mounting plate is isolated from the cabinet via a dense neoprene pad to minimize vibration transfer. The compressor is then isolated from the mounting plate with standard rubber in shear isolators to enhance the dual-level vibration isolation. The compressor is located in a well-insulated compartment, separated from the airstream to minimize sound transmission.
IAQ equipment supported: Manufacturer did not specify.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Shares replacement parts with other models.
Additional features: Hot gas reheat is used for humidity control and for occupant comfort. By redirecting exhaust heat from the compressor to the reheat coil, the system can operate to remove unwanted moisture. The integrated reheat coil is used to add sensible heat to the airstream to maintain the temperature setpoint. Efficient hot gas reheat system eliminates the need for a separate unit to dehumidify the air, thereby reducing overall energy usage.
Warranty information: Standard one-year warranty on compressor and parts. Extended five-year warranty is optional.
Special installation requirements: Installation must meet local codes. See product documentation for recommended clearances.
Contact: The Whalen Co., 410-822-9200; www.whalencompany.com.
eProduct: 211
![YORK Sun Choice Heat Pump](/ext/resources/2022/05-May/YORK-Sun-Choice-Heat-Pump.jpg)
Serviceability features: The lightweight design and direct replacement footprint of the YORK® Sun Choice heat pump rooftop unit offers ease of installation and flexibility for both new product and retrofit applications. In fact, units fit nearly 70% of the competitive installed base, minimizing the need for costly transition curbs. It includes independent circuits to help avoid full unit shutdowns. Single-side access to all serviceable items provide ease of service.
Noise-reduction features: Not applicable.
IAQ equipment supported: Choice RTUs feature a convertible filter rack from 2 or 4 inches with factory options up to MERV 13 pleated filters to meet LEED requirements. The systems feature a broad range of outdoor air options, including low leak damper economizers, constant volume powered exhaust, and modulating powered exhaust.
Thermostat compatibility: Compatible with most thermostats.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: Heat pump rooftops exceed DOE 2018 part-load cooling efficiencies by 15% and meet DOE 2023 efficiencies for both heating and cooling. Unit weight is up to 20% less than other YORK models, reducing the need for structural reinforcements.
Warranty information: Standard one-year parts warranty and five-year compressor and electric heat limited warranties.
Special installation requirements: None.
Contact: Johnson Controls, 414-344-8594; york.com/sunchoice.
eProduct: 212
![YORK Sun Premier Air Conditioner](/ext/resources/2022/05-May/YORK-Sun-Premier-Air-Conditioner.jpg)
Serviceability features: Premier rooftop units are engineered for simplified serviceability to lower the life cycle costs of the unit. The new RTUToolkit app for Android and iOS allows contractors to simply scan a unique QR code on each rooftop, which enables on-demand access to unit-specific details, technical literature, and direct-connection to technical support. Optional features include a mobile access portal gateway that offers a Wi-Fi interface, allowing for technicians to interface with the units from their car.
Noise-reduction features: Sound attenuator and compressor sound blanket options minimize sound outputs.
IAQ equipment supported: Indoor air quality is maximized with the Premier units through optional features such as ultraviolet lights, humidifiers, hot gas reheat coils, and final filters.
Thermostat compatibility: Not applicable.
Replacement parts compatibility: Does not share replacement parts with other models.
Additional features: The Sun Premier platform is designed to provide building owners best-in-class efficiency levels that significantly reduce operational costs. The systems deliver up to 50% higher-than-required results depending on the local code and additional options are available to meet the Consortium for Energy Efficiency 2019 highest tier ratings. The units also feature an optional high-end graphical user interface, which features a full-color touchscreen that provides quick access to system status, performance metrics and schedule parameters.
Warranty information: Standard one-year parts and either a six-month or one-year promotional labor warranty when started by a certified contractor.
Special installation requirements: Premier rooftop units offer flexibility in airflow path configuration, making installation in different scenarios easier. To help reduce the cost of crane required to set the unit, 60- to 80-ton cabinets can be supplied as a split ship unit. Split ship units are intended to be put back together in the field.
Contact: Johnson Controls, 414-344-8594; www.york.com/sunpremier.
eProduct: 213
![YORK-YVAA-Chiller](/ext/resources/2022/05-May/YORK-YVAA-Chiller.jpg)
Serviceability features: An efficient motor design provides a wide operating range, while refrigerant cooling and thermal protection increase compressor reliability. Standard features include a control center that provides automatic control of compressors, condenser fans, evaporator pump, and heater among others. Microchannel parallel flow aluminum alloy tubes are also easy to clean, and the unit is supported by the largest service and parts organization in the industry.
Noise-reduction features: The standard chiller configuration is equipped with low sound fans. There are several sound attenuation options available to further reduce sound at its source thereby meeting local sound level regulations. The chiller also features the SilentNight control option, providing a control input to limit sound output of the chiller based on time of day. This feature is programmable at the chiller panel or can be controlled remotely via a signal from a BAS system.
IAQ equipment supported: Not applicable.
Thermostat compatibility: Requires a special thermostat.
Replacement parts compatibility: Some shared parts and some unique parts.
Additional features: Proven globally, the YVAA chiller features a patented, liquid-cooled variable speed drive that is designed to improve reliability and performance with a customizable, highly optimized design. The chiller is highlighted by advanced technologies including
series flow evaporators, microchannel condenser coils, and EC fans to create higher levels of full and part load efficiency. The chiller now features increased operating efficiency, a reduced footprint, and integration with low-GWP refrigerants.
Warranty information: There are options for parts warranty and extended warranty as requested.
Special installation requirements: No specific special install requirements that are unique to chillers of this capacity.
Contact: Johnson Controls, 717-771-6364; johnsoncontrols.com.
eProduct: 214
