Lithium ion is probably the most advanced technology available for the packs of rechargeable batteries you purchased this holiday season. The batteries also power the vast majority of consumer devices, electric vehicles, and grid storage systems.

Despite their ubiquity, lithium-ion batteries have disadvantages. Metals used in the batteries are becoming expensive, and one crucial metal, cobalt, is relatively rare and has had recent media focus on questionable mining practices in some regions. Plus, the batteries can overheat and, when damaged, occasionally catch fire.

With its deep expertise in materials research, materials design, and energy storage technologies, Berkeley Lab is working on better battery alternatives. Gerbrand Ceder, a battery researcher in the Materials Science Division, details four battery technologies being studied by Berkeley Lab scientists that could make a big difference in the future.

Cobalt- and Nickel-Free Batteries

The reservoirs of a lithium-ion battery, the anode and the cathode, store lithium. When the battery is in use, lithium ions move to the cathode from the anode with the aid of a liquid electrolyte, typically an organic solvent, generating an electric current. When the battery charges, the reverse occurs.

Materials used to store lithium in lithium-ion batteries typically contain cobalt and nickel. Cobalt is scarce and expensive and has been linked with questionable practices in regions where it is mined.

The technology would solve these problems by eliminating cobalt and reducing or eliminating nickel. Iron or manganese, both of which are inexpensive, would ideally be used instead, said Ceder, who is also a UC Berkeley professor in materials science and engineering.

Possible uses: In consumer electronics and vehicles.

When available: Five to six years.

Multi-Valent Batteries

Instead of using lithium ions, which are “single valent,” this technology would use materials with ions that carry more charge, like magnesium, calcium, or possibly aluminum. These so-called “multi-valent batteries” could therefore be much smaller and more powerful than lithium-ion batteries.

Possible uses: In portable electronics and electric vehicles “if we can make it work,” said Ceder.

When available: This technology is “the most ambitious but therefore probably also the most difficult,” Ceder said. It’s at least 10 years away.

Sodium-Ion Batteries

These batteries would replace the lithium in lithium-ion batteries with sodium. A sodium-ion battery would operate exactly the same as a lithium one, except instead of moving lithium ions, it would move sodium ions. Sodium is much cheaper than lithium, and the materials that would be used to store sodium could also be cheaper than those to store lithium, which are primarily cobalt and nickel-based oxides. Eventually, these batteries could cost less than half of lithium-ion batteries, Ceder said.

Possible uses: For electrical power grids to store excess power, often from solar and wind, for later use.

When available: The technology is “almost to the point where it can work, but the question is whether it will get market traction,” Ceder said. “With market traction, the technology might be three to four years away.”

Solid-State Batteries

This technology would replace the highly flammable liquid electrolytes of some lithium-ion batteries with an inflammable solid material. The primary benefit would be improved safety, but it might be possible to use other storage materials and increase the energy content, Ceder said. In addition to being safer, such batteries could reduce costs and weight by eliminating the need for cooling and other safety devices.

Possible uses: In both electric vehicles to reduce costs and increase range and in consumer devices.

When available: At least four or five years away.
